Information contained herein is deemed to be reliable and accurate as of the issue date. EMCORE reserves the right to change the design or specifications at any time without notice.
1542 22 GHz 1310 nm
Microwave DFB Laser
DATASHEET | AUGUST 2013
MICROWAVE
Absolute Maximum Ratings
Stresses in excess of the absolute maximum ratings can cause permanent damage to the device. These are absolute stress
ratings only. Functional operation of the device is not implied at these or any other conditions in excess of those given in
the operational sections of the data sheet. Exposure to absolute maximum ratings for extended periods can adversely affect
device reliability.
Parameter
Operating Temperature Range of Baseplate
Storage Temperature
RF Input Power
Laser Forward dc Current
Photodiode Reverse Voltage
Laser Reverse Voltage
ESD
TEC Current
Symbol
T
OP
T
STG
P
IN
-
Condition
Continuous
-
60 Seconds
-
-
-
HMB: R = 1500 Ohm, C = 100 pF
Continuous
Min
-40
-40
-
25
200
-
-500
-1.9
Max
+65
+85
+20
120
10
1
500
1.9
Unit
˚C
˚C
dBm
mA
V
V
V
A
V
RPD
-
-
I
TEC
Electrical Characteristics
Parameter
Wavelength
Spectral Width, FWHM
2
, Typ., Max
Optical Power, Typical @ ITH +55 mA
Optical Power Stability vs. Temperature
DC Modulations Gain, Typical
Specifications
1310 to + 30
10
8 (min)
+ 15
0.24
Unit
nm
MHz
dBm
%
-
1. Specifications guaranteed when unit is connected to an optical path with return loss >35 dB.
Information contained herein is deemed to be reliable and accurate as of the issue date. EMCORE reserves the right to change the design or specifications at any time without notice.
1542 22 GHz 1310 nm
Microwave DFB Laser
DATASHEET | AUGUST 2013
MICROWAVE
RF Characteristics
Parameter
1542B
Maximum Frequency
Minimum Frequency
Amplitude Flatness
1&2
Input Return Loss (50Ω)
Input 1 dB Compression
Input Third Order Intercept
3
0.01 GHz - 7.0 GHz
7.0 GHz - 22.0 GHz
Noise Figure (dB)
4
0.01 GHz - 3.0 GHz
3.0 GHz - 7.0 GHz
7.0 GHz - 13.0 GHz
13.0 GHz - 18.0 GHz
18. GHz - 22.0 GHz
44
50
-
-
-
44
50
54
-
-
4.0
7.0
4.0
4.0
+20
+30
+25
44
50
54
59
-
44
50
54
59
61
7
Specifications
1542C
13
0.01
5.0
4.0
5.0
4.0
1542D
18
1542E
22
GHz
GHz
dB p-p
dB
dBm
Unit
1. Specifications guaranteed when unit is connected to an optical path with return loss >35 dB.
Information contained herein is deemed to be reliable and accurate as of the issue date. EMCORE reserves the right to change the design or specifications at any time without notice.
1542 22 GHz 1310 nm
Microwave DFB Laser
DATASHEET | AUGUST 2013
MICROWAVE
Ordering Information
1542n-yy-zz
Frequency (n)
7 GHz
13 GHz
18 GHz
22 GHz
Option Code
B
C
D
E
RF Connector (yy)
SMA Male
SMA Female
Option Code
SM
SF
Optical Connector (zz)
No optical connector, 900m buffered pigtail
FC/APC optical connector, 900m buffered pigtail
SC/APC, optical connector, 900m buffered pigtail
Option Code
PG
FA
SA
Laser Safety
This product meets the appropriate standard in Title 21 of the Code of Federal Regulations (CFR). FDA/CDRH Class 1M laser
product. This device has been classified with the FDA/CDRH under accession number 0220191. All versions of this laser are
Class 1M laser product, tested according to IEC 60825-1:2007 / EN 60825-1:2007. An additional warning for Class 1M laser prod-
ucts. For diverging beams, this warning shall state that viewing the laser output with certain optical instruments (for example,
eye loupes, magnifiers and microscopes) within a distance of 100 mm may pose an eye hazard. For collimated beams, this
warning shall state that viewing the laser output with certain optical instruments designed for use at a distance (for example,
telescopes and binoculars) may pose an eye hazard.
Wavelength = 1.5 µm.
Maximum power = 30 mW.
Caution: Use of controls, adjustments and procedures other than those specified herein may result in hazardous laser radiation exposure.
*IEC is a registered trademark of the International Electrotechnical Commission.
