Isolation voltage 2500Vrms
1ch Gate Driver Providing Galvanic Isolation
BM6105FW-LBZ
General Description
This is the product guarantees long time support in
Industrial market.
The BM6105 is a gate driver with isolation voltage
2500Vrms, I/O delay time of 120ns, and minimum input
pulse width of 60ns, and incorporates the fault signal
output functions, undervoltage lockout (UVLO) function,
and desaturation protection (DESAT) function.
Features
Long Time Support Product for Industrial Applications.
Providing Galvanic Isolation
Miller Clamp Function
Fault signal output function
Ready signal output function
Undervoltage lockout function
Desaturation protection function
Supporting Negative VEE2
Applications
Driving IGBT Gate for Industrial Equipment
Driving MOSFET Gate for Industrial Equipment
Key Specifications
Isolation voltage:
Maximum gate drive voltage:
I/O delay time:
Minimum input pulse width:
Package
SOP16WM
2500Vrms
20V
95ns (Max.)
60ns (Max.)
W(Typ) x D(Typ) x H(Max)
10.34mm x 10.31mm x 2.64mm
Typical Application Circuit
GND1
RDY
VEE2
INA
INB
RDY
FLT
XRST
VCC1
UVLO
S
Q
R
LOGIC
FLT
UVLO
+
-
CLAMP
OUT
VCC2
2V
(VEE2)
LOGIC
NC
GND2
+
-
9V
DESAT
VEE2
1pin
GND1
Figure 1. Typical application circuit
○Product
structure：Silicon integrated circuit
○This
product is not designed protection against radioactive rays
.
www.rohm.com
TSZ02201-0818ABH00020-1-2
© 2014 ROHM Co., Ltd. All rights reserved.
1/27
07.Nov.2014 Rev.002
TSZ22111・14・001
BM6105FW-LBZ
Recommended range of external constants
Pin Name
VCC1
VCC2
Pin Configurations
Symbol
C
VCC1
C
VCC2
Recommended Value
Min
0.1
0.33
Typ
1.0
-
Max
-
-
Unit
μF
μF
VEE2
DESAT
GND2
NC
VCC2
OUT
CLAMP
VEE2
Figure 2. Pin configuration
Pin Descriptions
Pin No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Pin Name
VEE2
DESAT
GND2
NC
VCC2
OUT
CLAMP
VEE2
GND1
INA
INB
RDY
FLT
XRST
VCC1
GND1
GND1
VCC1
XRST
FLT
RDY
INB
INA
GND1
Function
Output-side negative power supply pin
Desaturation protection pin
Output-side ground pin
No connect
Output-side positive power supply pin
Output pin
Miller clamp pin
Output-side negative power supply pin
Input-side ground pin
Control input pin A
Control input pin B
Ready output pin
Fault output pin
Reset input pin
Input-side power supply pin
Input-side ground pin
www.rohm.com
© 2014 ROHM Co., Ltd. All rights reserved.
TSZ22111・15・001
2/27
TSZ02201-0818ABH00020-1-2
07.Nov.2014 Rev.002
BM6105FW-LBZ
Absolute Maximum Ratings
Parameter
Input-side supply voltage
Output-side positive supply voltage
Output-side negative supply voltage
Maximum difference
between output-side positive and negative voltages
INA, INB, XRST pin input voltage
RDY, FLT pin input voltage
DESAT pin input voltage
OUT pin output current (10μs)
OUT, CLAMP pin voltage
RDY, FLT output current
Power dissipation
Operating temperature range
Storage temperature range
Junction temperature
Symbol
V
CC1
V
CC2
V
EE2
V
MAX2
V
IN
V
FLT
V
DESATIN
I
OUTPEAK
V
OUT
I
FLT
P
d
T
opr
T
stg
T
jmax
Limits
-0.3 to +7.0
(Note1)
-0.3 to +24.0
(Note2)
-15.0 to +0.3
(Note3)
30.0
-0.3 to +VCC1+0.3 or 7.0
(Note1)
-0.3 to +VCC1+0.3 or 7.0
(Note1)
-0.3 to VCC2+0.3
(Note2)
5.0
VEE2-0.3V to VCC2+0.3V
10
1.20
(Note4)
-40 to +105
-55 to +150
+150
Unit
V
V
V
V
V
V
V
A
V
mA
W
°C
°C
°C
(Note1) Relative to GND1.
(Note2) Relative to GND2.
(Note3) Should not exceed Pd and Tj=150°C.
(Note4) Derate above Ta=25°C at a rate of 9.6mW/°C. Mounted on a glass epoxy of 114.3 mm
×
76.2 mm
×
1.6 mm.
Caution:
Operating the IC over the absolute maximum ratings may damage the IC. The damage can either be a short circuit between pins or an open circuit
between pins and the internal circuitry. Therefore, it is important to consider circuit protection measures, such as adding a fuse, in case the IC is operated over
the absolute maximum ratings.
Recommended Operating Conditions
Parameter
Input-side supply voltage
Output-side positive supply voltage
Output-side negative supply voltage
Maximum difference
between output-side positive and negative voltages
(Note5) Relative to GND1.
(Note6) Relative to GND2.
Symbol
V
CC1(Note5)
V
CC2(Note6)
V
EE2(Note6)
V
MAX2
Min
4.5
13.3
-12
-
Max
5.5
20.0
0
28.0
Units
V
V
V
V
Insulation Related Characteristics
Parameter
Insulation Resistance (V
IO
=500V)
Insulation Withstand Voltage / 1min
Insulation Test Voltage / 1sec
Symbol
R
S
V
ISO
V
ISO
Characteristic
>10
9
2500
3000
Units
Ω
Vrms
Vrms
www.rohm.com
© 2014 ROHM Co., Ltd. All rights reserved.
TSZ22111・15・001
3/27
TSZ02201-0818ABH00020-1-2
07.Nov.2014 Rev.002
BM6105FW-LBZ
Electrical Characteristics
（Unless
otherwise specified T
a
=-40°C to 105°C, V
CC1
=4.5V to 5.5V, V
CC2
=13.3V to 20V, V
EE2
=-12V to 0V）
Parameter
General
Input side circuit current 1
Input side circuit current 2
Input side circuit current 3
Output side circuit current 1
Output side circuit current 2
Logic block
Logic high level input voltage
Logic low level input voltage
Logic pull-down resistance
Logic pull-up resistance
Logic input mask time
Minimum XRST pulse width
Output
OUT ON resistance (Source)
OUT ON resistance (Sink)
OUT maximum current
CLAMP ON resistance
Low level CLAMP current
Turn ON time
Turn OFF time
Propagation distortion
Rise time
Fall time
CLAMP ON threshold voltage
Common Mode Transient Immunity
R
ONH
R
ONL
I
OUTMAX
R
ONCLP
I
CLAMPL
t
PON
t
POFF
t
PDIST
t
RISE
t
FALL
V
CLPON
CM
0.3
0.2
3.0
0.2
3.0
45
45
-20
-
-
1.8
100
0.8
0.5
4.5
0.5
4.5
70
70
0
50
50
2
-
1.5
0.9
-
0.9
-
95
95
20
100
100
2.2
-
Ω
Ω
A
Ω
A
ns
ns
ns
ns
ns
V
kV/μs
t
POFF
- t
PON
10Ω, 10nF between OUT-VEE2
Guaranteed by design
Relative to VEE2
Guaranteed by design
I
OUT
=40mA
I
OUT
=40mA
Guaranteed by design
I
CLAMP
=40mA
Guaranteed by design
V
INH
V
INL
R
IND
R
INU
t
INMSK
t
XRSTMIN
2.0
0
25
25
-
800
-
-
50
50
-
-
V
CC1
0.8
100
100
60
-
V
V
kΩ
kΩ
ns
ns
INA, INB, XRST
INA, INB, XRST
INA
INB, XRST, RDY, FLT
INA, INB
I
CC11
I
CC12
I
CC13
I
CC21
I
CC22
0.16
0.21
0.26
0.9
0.8
0.32
0.42
0.52
1.8
1.7
0.48
0.63
0.78
2.7
2.5
mA
mA
mA
mA
mA
INA=10kHz, Duty=50%
INA=20kHz, Duty=50%
OUT=L
OUT=H
Symbol
Min
Typ
Max
Unit
Conditions
www.rohm.com
© 2014 ROHM Co., Ltd. All rights reserved.
TSZ22111・15・001
4/27
TSZ02201-0818ABH00020-1-2
07.Nov.2014 Rev.002
BM6105FW-LBZ
Electrical Characteristics - continued
（Unless
otherwise specified T
a
=-40°C to 105°C, V
CC1
=4.5V to 5.5V, V
CC2
=13.3V to 20V, V
EE2
=-12V to 0V）
Parameter
Protection functions
VCC1 UVLO OFF voltage
VCC1 UVLO ON voltage
VCC1 UVLO mask time
VCC2 UVLO OFF voltage
VCC2 UVLO ON voltage
VCC2 UVLO mask time
DESAT source current
DESAT threshold voltage
DESAT filter time
DESAT delay time (OUT)
DESAT delay time (FLT)
DESAT low voltage
Leading edge blanking
RDY output low voltage
FLT output low voltage
V
UVLO1H
V
UVLO1L
t
UVLO1MSK
V
UVLO2H
V
UVLO2L
t
UVLO2MSK
I
DESAT
V
DESAT
t
DESATFIL
t
DESATOUT
t
DESATFLT
V
DESATL
t
DESATLEB
V
RDYL
V
FLTL
3.35
3.25
1.0
11.3
10.3
1.0
450
8.5
0.16
0.31
0.34
-
0.28
-
-
3.50
3.40
2.5
12.3
11.3
2.0
500
9.0
0.25
0.38
0.42
0.1
0.4
0.08
0.08
3.65
3.55
5.0
13.3
12.3
3.0
550
9.5
0.34
0.45
0.50
0.22
0.52
0.15
0.15
V
V
μs
V
V
μs
μA
V
μs
μs
μs
V
μs
V
V
I
DESAT
=1mA
Guaranteed by design
I
RDY
=5mA
I
FLT
=5mA
Symbol
Min
Typ
Max
Unit
Conditions
www.rohm.com
© 2014 ROHM Co., Ltd. All rights reserved.
TSZ22111・15・001
5/27
TSZ02201-0818ABH00020-1-2
07.Nov.2014 Rev.002
