LS38G2-T: DescriptionPUSHBUTTON SWITCH,STRAIGHT,SPST,SURFACE MOUNT TERMINAL; CategoryMechanical and electronic products switch; File Size141KB，1 Pages; ManufacturerCITIZEN; Websitehttp://ce.citizen.co.jp/e/index.html

Download Datasheet Parametric Compare View All

LS38G2-T Overview

PUSHBUTTON SWITCH,STRAIGHT,SPST,SURFACE MOUNT TERMINAL

LS38G2-T Parametric

Parameter Name	Attribute value
Maker	CITIZEN
Reach Compliance Code	unknown
ECCN code	EAR99
Actuator type	PUSHBUTTON
Other features	TAPING
body width	3.0988 mm
body height	1.0922 mm
Body length or diameter	3.302 mm
Maximum contact current (DC)	0.02 A
Contact (DC) maximum rated R load	0.02A@12VDC
Contact resistance	0.1 mΩ
Maximum contact voltage (DC)	12 V
Dielectric withstand voltage	250VAC V
Electrical life	100000 Cycle(s)
Insulation resistance	100000000 Ω
Manufacturer's serial number	LS38G
Installation features	SURFACE MOUNT-STRAIGHT
surface mount	NO
Switch action	VERTICAL
switch function	SPST
Termination type	SOLDER

Preview

Download Datasheet

View All

●●●●●●●●●

タイプ

ＬＳ３８Ｇ　Ｓ½½½½½

Non-illuminated/Vertical Type

LS３８Ｇ

Series

■特徴

Features

1. 小型であるため実用上のレイアウトの

融通性が高く、セット設計が容易に行

えます

2. リフロー炉によるはんだ付けができま

す。

1. The compact size enables high layout

flexibility and easy set design.

2. Reflow solderring is possible using a

reflow furnace.

●電気的・機械的特性

Electro-Mechanical Characteristics

Ｉ½½½

最大定格

Maximum　rating

接触抵抗

Contact　resistance

絶縁抵抗

Insulation　resistance

耐電圧

Withstanding　voltage

バウンス

Bounce

ストローク

Stroke

½動力

Operating　force

動½寿½

Operating　life（times）

０.９０Ｎ（９２½½）

(Ｔ½ ２５℃)

スイッチ½動力

Switch　operating force

１.７６Ｎ（１８０½½）４.２０Ｎ（４２８½½）

ＤＣ１２Ｖ　２０½Ａ

１００½Ω以上　１００½Ω

or more

１００ＭΩ以上

１００ＭΩ or more

ＡＣ２５０Ｖ１分間

ＡＣ２５０Ｖ for one minute

２０½½以下

２０½½ or less

０.１５½½

０.１１½½

０.９０±０.４０Ｎ

１.７６±０.４９Ｎ

４.２０±０.７０Ｎ

２０万回以上

１０万回以上

２００,０００ or more １００,０００ or more １００,０００ or more

●外½寸法図

Outline drawing

■用途

Applications

タクティルスイッチＬＳ３８Ｇシリーズは操½

用スイッチとして次のような½品に½用で

きます。

ＴＶ、ＡＶ機器、車載機器、通信機器、

ファクシミリ、電話機、カーオーディオ等。

1. TACTILE SWITCH, LS38G series, can be

used as afunction control switch in the

following applications.

TV, audio visual instruments, automotive

equipment, telecommunication equipment,

facsimiles, telephone sets, car audio

products etc.

極性ﾏ½ ½

●½品コード

Product　code

ＬＳ３８Ｇ□―□

<シリーズ

Series>

操½荷重

Operating force

１：０.９０Ｎ（　９２gf）

２：１.７６Ｎ（１８０gf）

５：４.２０Ｎ（４２８gf）

梱包½態

Packing mode

回路図

Circuit diagram

Ｔ：テーピング（基本納入½態）

Ｔ：Taping（standard mode)

無記入：バルク包装

Non-coded：Bulk packing

ﾚ½ﾞ½½ﾄ

電極ﾊﾟﾀ½ﾝ

推奨はんだ付けパターン

The following soldering patterns are recommended for

reflow-soldering:

単½

Unit

：
