Internal
Connectors
Specifications
Insulation Resistance:
Withstanding Voltage:
Contact Resistance:
Voltage Rating:
Current Rating:
Operating Temp. Range:
Series BoardFit3.0 - Power Connectors
180° and 90° Male Header 3.00mm Pitch
(Single Row)
TH
Part Number
(Details)
1,000MΩ min.
1,500V ACrms for 1 minute
10mΩ
250V AC/DC
5A AC/DC
–25°C to +105°C
P3BP
Series
Pin Count
- 12
S
-
T*
-
LL - T
Materials and Finish
Insulator:
Contact:
Nylon46, UL94V-0 rated
Brass, Tin Plated
S = Single Row
# of contacts (2 to 12)
T1 = 180° TH
T9 = 90° TH
Features
For wire-to-wire and wire-to-board applications
Fully insulated terminals
Low engagement terminals
Locking function
Mating / Termination Area:
LL = Tin / Tin
T = Tube Packaging
Outline Dimensions 90° Single Row
PCB Layout
Outline Dimensions 180° Single Row
PCB Layout
Part Number
P3BP-2S-T*-LL-T
P3BP-3S-T*-LL-T
P3BP-4S-T*-LL-T
P3BP-5S-T*-LL-T
P3BP-6S-T*-LL-T
P3BP-7S-T*-LL-T
Pin Count
2
3
4
5
6
7
A
9.65
12.65
15.65
18.65
21.65
24.65
B
3.00
6.00
9.00
12.00
15.00
18.00
C
-
-
4.70
7.70
10.70
10.70
Part Number
P3BP-8S-T*-LL-T
P3BP-9S-T*-LL-T
P3BP-10S-T*-LL-T
P3BP-11S-T*-LL-T
P3BP-12S-T*-LL-T
No. of Leads
8
9
10
11
12
A
27.65
30.65
33.65
36.65
39.65
B
21.00
24.00
27.00
30.00
33.00
C
16.70
19.70
22.70
27.70
28.70
D-72
Connectors
SPECIFICATIONS AND DRAWINGS ARE SUBJECT TO ALTERATION WITHOUT PRIOR NOTICE - DIMENSIONS IN MILLIMETER
Trading Division
Series BoardFit3.0 - Power Connectors
180° and 90° Male Header 3.00mm Pitch
(Dual Row) TH
Specifications
Insulation Resistance:
Withstanding Voltage:
Contact Resistance:
Voltage Rating:
Current Rating:
Operating Temp. Range:
1,000MΩ min.
1,500V ACrms for 1 minute
10mΩ
250V AC/DC
5A AC/DC
–25°C to +105°C
Internal
Connectors
Part Number
(Details)
P3BP
Series
Pin Count
- 24
D
-
T*
-
LL - T
Materials and Finish
Insulator:
Contact:
Nylon46, UL94V-0 rated
Brass, Tin Plated
D = Dual Row
# of contacts (2 to 24)
T1 = 180° TH
T9 = 90° TH
Features
For wire-to-wire and wire-to-board applications
Fully insulated terminals
Low engagement terminals
Locking function
Plating: Mating / Termination Area
LL = Tin / Tin
T = Tube Packaging
Outline Dimensions 90° Dual Row
PCB Layout
Outline Dimensions 180° Dual Row
PCB Layout
Part Number
P3BP-2D-T*-LL-T
P3BP-4D-T*-LL-T
P3BP-6D-T*-LL-T
P3BP-8D-T*-LL-T
P3BP-10D-T*-LL-T
P3BP-12D-T*-LL-T
Trading Division
Pin Count
2
4
6
8
10
12
A
6.70
9.70
12.70
15.70
18.70
21.70
-
B
C
2.70
3.00
3.00
7.70
10.70
13.70
Part Number
P3BP-14D-T*-LL-T
P3BP-16D-T*-LL-T
P3BP-18D-T*-LL-T
P3BP-20D-T*-LL-T
P3BP-22D-T*-LL-T
P3BP-24D-T*-LL-T
Pin Count
14
16
18
20
22
24
A
24.70
27.70
30.70
33.70
36.70
39.70
B
18.00
21.00
24.00
27.00
30.00
33.00
C
16.70
19.70
22.70
25.70
28.70
31.70
3.00
6.00
9.00
12.00
15.00
SPECIFICATIONS AND DRAWINGS ARE SUBJECT TO ALTERATION WITHOUT PRIOR NOTICE - DIMENSIONS IN MILLIMETER
Connectors
D-73
B-t-B and B-t-C, Power Connectors
Internal
Connectors
Specifications
Insulation Resistance:
Withstanding Voltage:
Contact Resistance:
Voltage Rating:
Current Rating:
Operating Temp. Range:
Series BoardFit3.0 - Power Connectors
180° and 90° Male Header 3.00mm Pitch
(Dual Row)
SMT
Part Number
(Details)
1,000MΩ min.
1,500V ACrms for 1 minute
10mΩ
250V AC/DC
5A AC/DC
–25°C to +105°C
P3BP
Series
Pin Count
- 24
D
-
S*
-
LL - T
Materials and Finish
Insulator:
Contact:
Nylon46, UL94V-0 rated
Brass, Tin Plated
D = Dual Row
# of contacts (2 to 24)
S1 = 180° SMT
S9 = 90° SMT
Features
For wire-to-wire and wire-to-board applications
Fully insulated terminals
Low engagement terminals
Locking function
Mating / Termination Area:
LL = Tin / Tin
T = Tube Packaging
Outline Dimensions 90° Dual Row
PCB Layout
Outline Dimensions 180° Dual Row
PCB Layout
Part Number
P3BP-2D-S*-LL-T
P3BP-4D-S*-LL-T
P3BP-6D-S*-LL-T
P3BP-8D-S*-LL-T
P3BP-10D-S*-LL-T
P3BP-12D-S*-LL-T
Pin Count
2
4
6
8
10
12
A
6.70
9.70
12.70
15.70
18.70
21.70
B
-
3.00
6.00
9.00
12.00
15.00
Part Number
P3BP-14D-S*-LL-T
P3BP-16D-S*-LL-T
P3BP-18D-S*-LL-T
P3BP-20D-S*-LL-T
P3BP-22D-S*-LL-T
P3BP-24D-S*-LL-T
Pin Count
14
16
18
20
22
24
A
24.70
27.70
30.70
33.70
36.70
39.70
B
18.00
21.00
24.00
27.00
30.00
33.00
D-74
Connectors
SPECIFICATIONS AND DRAWINGS ARE SUBJECT TO ALTERATION WITHOUT PRIOR NOTICE - DIMENSIONS IN MILLIMETER
Trading Division
Series BoardFit3.0 - Power Connectors
180° Male Cable Power Connector 3.00mm Pitch
(Single & Dual Row)
Specifications
Insulation Resistance:
Withstanding Voltage:
Contact Resistance:
1,000MΩ min.
1,500V ACrms for 1 minute
20mΩ (single row)
10mΩ (dual row)
Voltage Rating:
250V AC/DC
Current Rating:
5A AC/DC
Operating Temp. Range: –25°C to +105°C
Internal
Connectors
Part Number
(Details)
P3CP
Series
Pin Count
- 12
*
- C1
-
LL - B
S = Single Row (2 to 12)
D = Dual Row (2 to 24)
C1 = 180° Crimp
Plating: Mating / Termination Area
LL = Tin / Tin
B = Bulk Packaging
Materials and Finish
Insulator:
Nylon66, UL94V-0 rated
Contact:
Phosphor Bronze, Tin Plated
Crimp Terminal: Phosphor Bronze, Tin Plated
Features
For wire-to-wire and wire-to-board applications
Fully insulated terminals
Low engagement terminals
Locking function
Part Number for Crimp Contacts
P3CP-Contact
(wire gauge = AWG 20-24)
Outline Dimensions 180° Single Row
Outline Dimensions 180° Dual Row
B-t-B and B-t-C, Power Connectors
Outline Dimensions Crimp Contacts
Single Row
Part Number
P3CP-2S-C1-LL-B
P3CP-3S-C1-LL-B
P3CP-4S-C1-LL-B
P3CP-5S-C1-LL-B
P3CP-6S-C1-LL-B
P3CP-7S-C1-LL-B
P3CP-8S-C1-LL-B
P3CP-9S-C1-LL-B
P3CP-10S-C1-LL-B
P3CP-11S-C1-LL-B
P3CP-12S-C1-LL-B
Pin Count
2
3
4
5
6
7
8
9
10
11
12
A
3.00
6.00
9.00
12.00
15.00
18.00
21.00
24.00
27.00
30.00
33.00
B
6.85
9.85
12.85
15.85
18.85
21.85
24.85
27.85
30.85
33.85
36.85
Dual Row
Part Number
P3CP-2D-C1-LL-B
P3CP-4D-C1-LL-B
P3CP-6D-C1-LL-B
P3CP-8D-C1-LL-B
P3CP-10D-C1-LL-B
P3CP-12D-C1-LL-B
P3CP-14D-C1-LL-B
P3CP-16D-C1-LL-B
P3CP-18D-C1-LL-B
P3CP-20D-C1-LL-B
P3CP-22D-C1-LL-B
P3CP-24D-C1-LL-B
Pin Count
2
4
6
8
10
12
14
16
18
20
22
24
A
-
3.00
6.00
9.00
12.00
15.00
18.00
21.00
24.00
27.00
30.00
33.00
B
3.85
6.85
9.85
12.85
15.85
18.85
21.85
24.85
27.85
30.85
33.85
36.85
Connectors
Trading Division
SPECIFICATIONS AND DRAWINGS ARE SUBJECT TO ALTERATION WITHOUT PRIOR NOTICE - DIMENSIONS IN MILLIMETER
D-75
Internal
Connectors
Specifications
Insulation Resistance:
Withstanding Voltage:
Contact Resistance:
Series BoardFit3.0 - Power Connectors
180° Female Cable Power Connector 3.00mm Pitch
(Single & Dual Row)
Part Number
(Details)
1,000MΩ min.
1,500V ACrms for 1 minute
20mΩ (single row)
10mΩ (dual row)
Voltage Rating:
250V AC/DC
Current Rating:
5A AC/DC
Operating Temp. Range: –25°C to +105°C
P3CS
Series
Pin Count
- 12
*
- C1
-
LL - B
S = Single Row (2 to 12)
D = Dual Row (2 to 24)
C1 = 180° Crimp
Plating: Mating / Termination Area
LL = Tin / Tin
B = Bulk Packaging
Materials and Finish
Nylon66, UL94V-0 rated
Single (Brass, Tin Plated)
Dual (Phosphor Bronze, Tin Plated)
Crimp Terminal: Phosphor Bronze, Tin Plated
Insulator:
Contact:
Features
For wire-to-wire and wire-to-board applications
Fully insulated terminals
Low engagement terminals
Locking function
Part Number for Crimp Contacts
P3CS-Contact
(wire gauge = AWG 20-24)
Outline Dimensions 180° Single Row
Outline Dimensions 180° Dual Row
Outline Dimensions Crimp Contacts
Single Row
Part Number
P3CS-2S-C1-LL-B
P3CS-3S-C1-LL-B
P3CS-4S-C1-LL-B
P3CS-5S-C1-LL-B
P3CS-6S-C1-LL-B
P3CS-7S-C1-LL-B
P3CS-8S-C1-LL-B
P3CS-9S-C1-LL-B
P3CS-10S-C1-LL-B
P3CS-11S-C1-LL-B
P3CS-12S-C1-LL-B
Pin Count
2
3
4
5
6
7
8
9
10
11
12
A
3.00
6.00
9.00
12.00
15.00
18.00
21.00
24.00
27.00
30.00
33.00
B
6.85
9.85
12.85
15.85
18.85
21.85
24.85
27.85
30.85
33.85
36.85
Dual Row
Part Number
P3CS-2D-C1-LL-B
P3CS-4D-C1-LL-B
P3CS-6D-C1-LL-B
P3CS-8D-C1-LL-B
P3CS-10D-C1-LL-B
P3CS-12D-C1-LL-B
P3CS-14D-C1-LL-B
P3CS-16D-C1-LL-B
P3CS-18D-C1-LL-B
P3CS-20D-C1-LL-B
P3CS-22D-C1-LL-B
P3CS-24D-C1-LL-B
Pin Count
2
4
6
8
10
12
14
16
18
20
22
24
A
-
3.00
6.00
9.00
12.00
15.00
18.00
21.00
24.00
27.00
30.00
33.00
B
3.85
6.85
9.85
12.85
15.85
18.85
21.85
24.85
27.85
30.85
33.85
36.85
Trading Division
D-76
Connectors
SPECIFICATIONS AND DRAWINGS ARE SUBJECT TO ALTERATION WITHOUT PRIOR NOTICE - DIMENSIONS IN MILLIMETER
