SEMICONDUCTOR

TECHNICAL DATA

1A THREE TERMINAL NEGATIVE VOLTAGE REGULATORS

-5V, -6V, -8V, -9V, -10V, -12V, -15V, -18V, -20V, -24V.

KIA7905F~KIA7924F

BIPOLAR LINEAR INTEGRATED CIRCUIT

FEATURES

Suitable for C-MOS, TTL, and the other digital IC power supply.

Internal thermal overload protecting.

Internal short circuit current limiting.

Output current in excess of 1.0A.

DIM

MILLIMETERS

6.60 + 0.2

6.10 + 0.2

5.0 + 0.2

1.10 + 0.2

2.70 + 0.2

_ 0.1

2.30 +

1.00 MAX

2.30 + 0.2

0.50 + 0.1

2.00 + 0.20

_ 0.10

0.50 +

0.91 + 0.10

0.90 + 0.1

1.00 + 0.10

0.95 MAX

1. GND

2. INPUT

3. OUTPUT

MAXIMUM RATINGS (Ta=25

CHARACTERISTIC

KIA7905F

Input Voltage

KIA7915F

KIA7918F

KIA7924F

Power Dissipation (Tc=25

)

SYMBOL

RATING

-35

-40

opr

stg

1.3

-30 150

-30 75

-55 150

UNIT

DPAK

Power Dissipation (Without Heatsink)

Operating Junction Temperature

Operating Temperature

Storage Temperature

2002. 9. 24

Revision No : 2

1/14
