BGY887BO/FC1
Optical receiver module
Product specification
Supersedes data of 1998 Feb 02
File under Discrete Semiconductors, SC16
1998 Mar 13
Philips Semiconductors
Product specification
Optical receiver module
FEATURES
•
Excellent linearity
•
Extremely low noise
•
Excellent flatness
•
Standard CATV outline
•
Rugged construction
•
Gold metallization ensures excellent reliability
•
FC/APC connector (JDS version).
APPLICATIONS
•
CATV systems operating over a frequency range of
40 to 860 MHz.
DESCRIPTION
Hybrid high dynamic range optical receiver module in a
SOT115R package operating at a voltage supply of 24 V
(DC). The module contains a monomode optical input
suitable for wavelengths from 1290 to 1600 nm, a terminal
to monitor the pin diode current and an electrical output
with an impedance of 75
Ω.
The optical fibre is terminated by an FC/APC connector
(JDS version) and partly reinforced by a 3 mm diameter
Kevlar buffer.
Side view
handbook, halfpage
BGY887BO/FC1
PINNING - SOT115R
PIN
1
2
3
5
7
8
9
DESCRIPTION
monitor current
common
common
+V
B
common
common
output
1
2
3
5
7
8
9
MBK045
Fig.1 Simplified outline
QUICK REFERENCE DATA
SYMBOL
f
S
22
d
2
F
I
tot
PARAMETER
frequency range
output return losses
optical input return losses
second order distortion
equivalent noise input
total current consumption (DC)
f = 324.25 MHz
f = 40 MHz
V
B
= 24 V
CAUTION
This product is supplied in anti-static packing to prevent damage caused by electrostatic discharge during transport
and handling. For further information, refer to Philips specs.: SNW-EQ-608, SNW-FQ-302A, and SNW-FQ-302B.
HANDLING
Fibreglass optical coupling: maximum tensile strength = 5 N; minimum bending radius = 35 mm.
1998 Mar 13
2
f = 40 to 860 MHz
CONDITIONS
MIN.
40
11
40
−
−
175
MAX.
860
−
−
−70
7
205
UNIT
MHz
dB
dB
dBc
pA/√Hz
mA
Philips Semiconductors
Product specification
Optical receiver module
LIMITING VALUES
In accordance with the Absolute Maximum Rating System (IEC 134).
SYMBOL
f
T
stg
T
mb
P
in
ESD
PARAMETER
frequency range
storage temperature range
operating mounting-base temperature
optical input power
ESD sensitivity
continuous
human body model;
R = 1.5 kΩ; C = 100 pF
CONDITIONS
BGY887BO/FC1
MIN.
40
−40
−20
−
500
MAX.
860
+85
+85
5
−
UNIT
MHz
°C
°C
mW
V
CHARACTERISTICS
Bandwidth 40 to 860 MHz; V
B
= 24 V; T
mb
= 30
°C;
Z
S
= Z
L
= 75
Ω.
SYMBOL
S
FL
S
22
OBR
C
IL
C
d
2
d
3
F
s
λ
λ
L
I
tot
Notes
1. Two laser test; each laser with 40% modulation index:
f
p
= 135 MHz; P
p
= 0.5 mW;
f
q
= 189.25 MHz; P
q
= 0.5 mW;
measured at f
p
+ f
q
= 324.25 MHz.
2. Three laser test; each laser with 40% modulation
index:
f
p
= 326.25 MHz; P
p
= 0.33 mW;
f
q
= 333.25 MHz; P
q
= 0.33 mW;
f
r
= 335.25 MHz; P
r
= 0.33 mW;
measured at f
p
+ f
q
−
f
r
= 324.25 MHz.
3. The module normally operates at V
B
= 24 V, but is
able to withstand supply transients up to 30 V.
responsivity
flatness of frequency response
output return losses
optical input return losses
connector optical return losses
connector optical insertion losses
second order distortion
third order distortion
equivalent noise input
spectral sensitivity
optical wavelength
length of optical fibre
total current consumption
buffered fibre; SM type; 9/125
µm;
Kevlar buffer: 3 mm
note 3
note 1
note 2
f
1
= 40 MHz
λ
= 1310
±20
nm
λ
= 1550
±20
nm
f = 40 to 860 MHz
PARAMETER
CONDITIONS
λ
= 1300 nm
−
11
40
70
−
−
−
−
0.85
0.9
1290
817
175
MIN.
750
MAX.
−
±0.5
−
−
−
0.5
−70
−80
7
−
−
1600
917
205
UNIT
V/W
dB
dB
dB
dB
dB
dB
dB
pA/√Hz
A/W
A/W
nm
mm
mA
handbook, halfpage
Pin 1
10 kΩ
current
1 kΩ
MLB151
Fig.2 Monitor current pin.
1998 Mar 13
3
Philips Semiconductors
Product specification
Optical receiver module
PACKAGE OUTLINE
Rectangular single-ended package; aluminium flange;
2 vertical mounting holes; 2 x 6-32 UNC and 2 extra horizontal mounting holes;
optical input with connector; 7 gold-plated in-line leads
y1
M
B
E
S2
Z
P
D
BGY887BO/FC1
SOT115R
N
N1
N2
N3
M
M1 M
2
M3
A2
1
A
L
S1
F
S
c
d
B
U2
Q
y
M
B
P
W
e
e1
q2
q1
y
M
B
y
M
B
b
w
M
2
3
5
7
8
9
U1
q
connector
0
5
scale
10 mm
q2
10.2
S
4.2
S1
S2
U1
U2
max.
8
W
w
y
0.1
Q
max.
2.4
y1
0.2
Z
max.
12
16.7 4.95
44.75
16.1 4.55
DIMENSIONS (mm are the original dimensions)
UNIT
A2
A
max. max.
9.1
b
c
D
d
E
max. max. max.
e
e1
F
L
min.
8.8
M
2.5
M1
1.6
M2
0.9
M3
3
N
N1
N2
6-32 0.25
UNC
N3
5
1
∅
P
4.15
3.85
q
q1
mm 20.8
0.51
0.25 27.2 2.54 13.75 2.54 5.08 12.7
0.38
917 15.3 10.7
817 8.7 8.7
38.1 25.4
OUTLINE
VERSION
SOT115R
REFERENCES
IEC
JEDEC
EIAJ
EUROPEAN
PROJECTION
ISSUE DATE
98-03-06
1998 Mar 13
4
Philips Semiconductors
Product specification
Optical receiver module
DEFINITIONS
Data Sheet Status
Objective specification
Preliminary specification
Product specification
Limiting values
BGY887BO/FC1
This data sheet contains target or goal specifications for product development.
This data sheet contains preliminary data; supplementary data may be published later.
This data sheet contains final product specifications.
Limiting values given are in accordance with the Absolute Maximum Rating System (IEC 134). Stress above one or
more of the limiting values may cause permanent damage to the device. These are stress ratings only and operation
of the device at these or at any other conditions above those given in the Characteristics sections of the specification
is not implied. Exposure to limiting values for extended periods may affect device reliability.
Application information
Where application information is given, it is advisory and does not form part of the specification.
LIFE SUPPORT APPLICATIONS
These products are not designed for use in life support appliances, devices, or systems where malfunction of these
products can reasonably be expected to result in personal injury. Philips customers using or selling these products for
use in such applications do so at their own risk and agree to fully indemnify Philips for any damages resulting from such
improper use or sale.
1998 Mar 13
5
