Pushbutton Switches
Momentary Pushbutton Switches with LED
PB9 Series
LED Positions
SPDT Contact
Configuration
Bottom View
P.C.B. Mounting Holes
CAP TYPES
CAP STYLE
PAPERBOARD
NS0
NL0
NS
&
NL
Stand Cap
NS1
NL1
NS2
NL2
Non LED
One-LED
Two-LED
Note:
write area (Paperboard only for cap type TS & TL)
TS
&
TL
Transparent Cap
TS_
LED CHARACTERISTICS
TL_
CUTAWAY
Blue
3.5
20
120
600
470
Parameters
Forward Voltage
Forward Current
Permissible Loss
Luminous Intensity
Peak Wave Length
Reverse Voltage
Reverse Current V
R
=5V
Soldering Temperature
Symbol (Unit)
V
F
(V)
I
F
(mA)
P
D
(mW)
I
v
(mcd)
λP(nm)
V
R
(V)
(uA)
(°C)
Red
2.0
20
80
60
635
Yellow
2.1
20
80
50
585
5
100
Green
2.2
20
80
60
568
The electrical specifications shown are
determined at a basic temperature of
25°C. If the source voltage exceeds the
rated of LED, a ballast resistor has to
be connected in series with the LED.
Attention: LED are electrostatic sensi-
tive devices
260 for 5 seconds
How to order:
PB9
NS0
NS1
NS2
NL0
NL1
NL2
TS0
TS1
TS2
TL0
TL1
TL2
1
2
3
4
General Specifications:
LED COLORS:
Without LED
One-LED:
Red
Yellow
Green
Blue
Two-LED (Left / Right):
Red / Red
Red / Yellow
Red / Green
Red / Blue
Yellow / Red
Yellow / Yellow
Yellow / Green
Yellow / Blue
Green / Red
Green / Yellow
Green / Green
Green / Blue
Blue / Red
GE
GF
GG
Blue / Yellow
Blue / Green
Blue / Blue
LED TERMINAL &
ELECTRODE DIRECTION:
+ o o - Bend (One-LED)
o + - o Standard (One-LED)
o - + o (One-LED)
+ - - + Standard (Two-LED)
- + + - (Two-LED)
- + - + (Two-LED)
+ - + - (Two-LED)
Standard: No Code
+ : anode
- : cathode
o : none this pin
1
CAP TYPE & STYLE:
Small Cap without LED
Small Cap with One-LED
Small Cap with Two-LED
Large Cap without LED
Large Cap with One-LED
Large Cap with Two-LED
Transparent Small Cap without LED
Transparent Small Cap with One-LED
Transparent Small Cap with Two-LED
Transparent Large Cap without LED
Transparent Large Cap with One-LED
Transparent Large Cap with Two-LED
CAP COLORS
(Only for NS & NL Cap):
Red
Yellow
Green
White
Black
Orange
Blue
Grey
00
0C
0E
0F
0G
CC
CE
CF
CG
EC
EE
EF
EG
FC
FE
FF
FG
GC
3
4
0
no code
2
no code
4
5
6
ELECTRICAL & MECHANICAL SPECIFICATIONS:
» Circuit: SPDT
» Current Rating: 12 mA
» Voltage Rating: 24 VDC
» Contact Resistance: 50 mΩ max. (initial)
» Insulation Resistance: 100MΩ min.
» Operating Force: 170±50 gf
» Total Travel: 2.5±0.5 mm
» Operating Life: 1,000,000 cycles min.
» Soldering: 260 °C for 3 seconds
» Operating Temperature: -10 °C ~ +60 °C
» Function: Momentary
MATERIALS
» Cap: Acrylonitrile Butadine Styrene (ABS)
» Case: Polyamide (PA)
» Fixed Support: Stainless steel wire
» Terminals: Phosphor bronze (PBS) with gold plating
» Moving Contact: Phosphor bronze (PBS) with
gold plating
» Spring: Piano wire
» LED: 3mm Diameter LED lamp
2
C
E
F
B
A
D
G
H
sales@greatecs.com
www.greatecs.com
