PBLS1501V

Description
15 V PNP BISS loadswitch
CategoryDiscrete semiconductor    The transistor
File Size82KB,14 Pages
ManufacturerNXP
Websitehttps://www.nxp.com
Environmental Compliance
Download Datasheet Parametric Compare View All

PBLS1501V Overview

15 V PNP BISS loadswitch

PBLS1501V Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
MakerNXP
package instructionPLASTIC PACKAGE-6
Contacts6
Reach Compliance Codecompli
ECCN codeEAR99
Other featuresBUILT-IN BIAS RESISTOR RATIO IS 1
Maximum collector current (IC)0.1 A
Collector-emitter maximum voltage50 V
ConfigurationSEPARATE, 2 ELEMENTS WITH BUILT-IN RESISTOR
Minimum DC current gain (hFE)30
JESD-30 codeR-PDSO-F6
JESD-609 codee3
Humidity sensitivity level1
Number of components2
Number of terminals6
Maximum operating temperature150 °C
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formSMALL OUTLINE
Peak Reflow Temperature (Celsius)260
Polarity/channel typeNPN AND PNP
Maximum power dissipation(Abs)0.3 W
Certification statusNot Qualified
surface mountYES
Terminal surfaceTin (Sn)
Terminal formFLAT
Terminal locationDUAL
Maximum time at peak reflow temperature30
transistor applicationsSWITCHING
Transistor component materialsSILICON
Nominal transition frequency (fT)280 MHz
PBLS1501Y; PBLS1501V
15 V PNP BISS loadswitch
Rev. 02 — 24 August 2009
Product data sheet
1. Product profile
1.1 General description
Low V
CEsat
PNP transistor and NPN resistor-equipped transistor in one package.
Table 1.
Product overview
Package
NXP
PBLS1501Y
PBLS1501V
SOT363
SOT666
JEITA
SC-88
-
Type number
1.2 Features
I
I
I
I
I
Low V
CEsat
(BISS) transistor and resistor-equipped transistor in one package
Low ‘threshold’ voltage (< 1 V) compared to MOSFET
Low drive power required
Space-saving solution
Reduction of component count
1.3 Applications
I
I
I
I
Supply line switches
Battery charger switches
High-side switches for LEDs, drivers and backlights
Portable equipment
1.4 Quick reference data
Table 2.
Symbol
V
CEO
I
C
R
CEsat
Quick reference data
Parameter
collector-emitter voltage
collector-current (DC)
equivalent on-resistance
I
C
= −500
mA;
I
B
= −50
mA
open base
Conditions
open base
Min
-
-
-
Typ
-
-
300
Max
−15
−500
500
Unit
V
mA
mΩ
TR1; PNP: low V
CEsat
transistor
TR2; NPN: resistor-equipped transistor
V
CEO
collector-emitter voltage
-
-
50
V

PBLS1501V Related Products

PBLS1501V PBLS1501Y
Description 15 V PNP BISS loadswitch 15 V PNP BISS loadswitch
Is it Rohs certified? conform to conform to
Maker NXP NXP
package instruction PLASTIC PACKAGE-6 SMALL OUTLINE, R-PDSO-G6
Contacts 6 6
Reach Compliance Code compli compliant
ECCN code EAR99 EAR99
Other features BUILT-IN BIAS RESISTOR RATIO IS 1 BUILT-IN BIAS RESISTOR RATIO IS 1
Maximum collector current (IC) 0.1 A 0.1 A
Collector-emitter maximum voltage 50 V 50 V
Configuration SEPARATE, 2 ELEMENTS WITH BUILT-IN RESISTOR SEPARATE, 2 ELEMENTS WITH BUILT-IN RESISTOR
Minimum DC current gain (hFE) 30 30
JESD-30 code R-PDSO-F6 R-PDSO-G6
JESD-609 code e3 e3
Humidity sensitivity level 1 1
Number of components 2 2
Number of terminals 6 6
Maximum operating temperature 150 °C 150 °C
Package body material PLASTIC/EPOXY PLASTIC/EPOXY
Package shape RECTANGULAR RECTANGULAR
Package form SMALL OUTLINE SMALL OUTLINE
Peak Reflow Temperature (Celsius) 260 260
Polarity/channel type NPN AND PNP NPN AND PNP
Maximum power dissipation(Abs) 0.3 W 0.3 W
Certification status Not Qualified Not Qualified
surface mount YES YES
Terminal surface Tin (Sn) Tin (Sn)
Terminal form FLAT GULL WING
Terminal location DUAL DUAL
Maximum time at peak reflow temperature 30 30
transistor applications SWITCHING SWITCHING
Transistor component materials SILICON SILICON
Nominal transition frequency (fT) 280 MHz 280 MHz
