PBLS4005D

Description
40 V PNP BISS loadswitch
CategoryDiscrete semiconductor    The transistor
File Size139KB,15 Pages
ManufacturerNXP
Websitehttps://www.nxp.com
Environmental Compliance
Download Datasheet Parametric Compare View All

PBLS4005D Overview

40 V PNP BISS loadswitch

PBLS4005D Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
MakerNXP
Parts packaging codeSC-74
package instructionPLASTIC, SC-74, 6 PIN
Contacts6
Reach Compliance Codecompliant
ECCN codeEAR99
Other featuresBUILT IN BIAS RESISTOR RATIO 1
Maximum collector current (IC)0.1 A
Collector-emitter maximum voltage50 V
ConfigurationSEPARATE, 2 ELEMENTS WITH BUILT-IN RESISTOR
Minimum DC current gain (hFE)150
JESD-30 codeR-PDSO-G6
JESD-609 codee3
Humidity sensitivity level1
Number of components2
Number of terminals6
Maximum operating temperature150 °C
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formSMALL OUTLINE
Peak Reflow Temperature (Celsius)260
Polarity/channel typePNP
Maximum power dissipation(Abs)0.6 W
Certification statusNot Qualified
surface mountYES
Terminal surfaceTin (Sn)
Terminal formGULL WING
Terminal locationDUAL
Maximum time at peak reflow temperature30
transistor applicationsSWITCHING
Transistor component materialsSILICON
Nominal transition frequency (fT)150 MHz
Base Number Matches1
PBLS4005D
40 V PNP BISS loadswitch
Rev. 03 — 6 January 2009
Product data sheet
1. Product profile
1.1 General description
PNP low V
CEsat
Breakthrough In Small Signal (BISS) transistor and NPN Resistor-
Equipped Transistor (RET) in a SOT457 (SC-74) small Surface-Mounted Device (SMD)
plastic package.
1.2 Features
I
I
I
I
I
Low V
CEsat
(BISS) and resistor-equipped transistor in one package
Low threshold voltage (< 1 V) compared to MOSFET
Low drive power required
Space-saving solution
Reduction of component count
1.3 Applications
I
I
I
I
Supply line switches
Battery charger switches
High-side switches for LEDs, drivers and backlights
Portable equipment
1.4 Quick reference data
Table 1.
Symbol
V
CEO
I
C
R
CEsat
Quick reference data
Parameter
collector-emitter voltage
collector current
collector-emitter saturation
resistance
collector-emitter voltage
output current
bias resistor 1 (input)
bias resistor ratio
I
C
=
−500
mA;
I
B
=
−50
mA
open base
Conditions
open base
[1]
[2]
Min
-
-
-
Typ
-
-
240
Max
−40
−1
340
Unit
V
A
mΩ
TR1; PNP low V
CEsat
transistor
TR2; NPN resistor-equipped transistor
V
CEO
I
O
R1
R2/R1
[1]
[2]
-
-
33
0.8
-
-
47
1
50
100
61
1.2
V
mA
kΩ
Device mounted on a ceramic Printed-Circuit Board (PCB), Al
2
O
3
, standard footprint.
Pulse test: t
p
300
µs; δ ≤
0.02.
