PC Series
CHASSIS MOUNT, SINGLE AND DOUBLE STAGE EMI/RFI LINE FILTER.
MECHANICAL DIMENSIONS
(Unit: mm)
0.8 TYP.
70.5
- 1.0
50.0
+
28.5
- 0.5
+
FEATURES
The PC series offers superior performance in suppressing
Line-to-Line and Line-to-Ground noise. Designed for easy
mounting, this low profile Chassis mount filter is PDI’s most
popular filter offering current ratings up to 20 Amps at
250VAC. One size package offers both single and double
stage filtering.
3.5x2.0 TYP.
2x 5.00
L
60.0
6.35 TYP. G
L'
APPLICATIONS
Computer & networking equipment, Measuring & control
equipment, Data processing equipment, laboratory instruments,
Switching power supplies, other electronic equipment.
N
N'
TECHNICAL DATA
•
•
•
•
•
Rated Voltage: 250VAC
Rated Current: 1A, 3A, 5A, 6A, 10A, 15A, 20A
Power Line Frequency: 60Hz
Leakage Current: 0.8mA, 250VAC
Hipot Rating (one minute)
Line to Ground: 2250VDC
Line to Line: 1450VDC
•
Temperature Range: -25C to +85C
70.7 MAX.
Specifications subject to change without notice. Dimensions (mm).
145 Algonquin Parkway, Whippany, NJ 07981 • 973-560-0019 • FAX: 973-560-0076
e-mail: filtersales@powerdynamics.com •
www.powerdynamics.com
25
PC Series Example & Ordering Code
PC
05
CURRENT RATING (A):
Q - 1
=
=
=
=
=
=
=
01
)
03
)
05
"
06
)
10
¦
15
"
20
"
TERMINAL:
QUICK CONNECT
=Q
SCHEMATIC:
ONE STAGE
TWO STAGE
=1
=2
PC Series Attenuation Tables
Non-Medical Applications
Insertion loss in dB (50 Ohm circuit)
ONE STAGE
Current
Rating
5A
10A
15A
20A
TWO STAGE
Comm. Mode(L-G) MHz
Diff. mode(L-L) MHz
.15 .5 1 5 10 30 .15 .5 1 5 10 30
17
16
14
7
27
24
19
17
31
28
22
22
42
34
32
32
46
36
33
34
42
40
41
50
7
9
10
7
37
36
32
27
37
35
28
28
46
40
37
36
42
42
38
39
37
38
40
46
Inductance
in mH
1.7
1.2
0.9
0.5
Current
Rating
1A
3A
6A
10A
Inductance
in mH
3.7
1.8
0.7
0.3
Comm. Mode(L-G) MHz
Diff. mode(L-L) MHz
.15 .5 1 5 10 30 .15 .5 1 5 10 30
46
38
21
4
74
68
51
32
73
80
62
50
58
58
66
66
51
53
69
58
27
48
51
48
7
5
15
6
52
53
30
18
46
62
75
54
54
51
55
55
47
44
49
48
32
38
41
41
SCHEMATICS
ONE STAGE
L mH
Cx
0.1 F
x2
L mH
Cx
Cy
2200pF
x2
L'
LOAD
TWO STAGE
L mH
Cy
3300pF
x2
L mH
10M
Cx
L mH
L'
Cx
N'
L mH
LOAD
L
LINE
L
G
N
Cx
0.3 F
x3
LINE
G
N
"
10M
N'
Single stage only
)
Double stage only
¦
Available in single & double stage
26
