D Subminiature Connector, 9 Contact(s), Female, 0.109 inch Pitch, Solder Terminal, M3, Plug
| Parameter Name | Attribute value |
| Maker | CONEC |
| Reach Compliance Code | compliant |
| ECCN code | EAR99 |
| Other features | WITH GROUNDING BRACKET |
| subject depth | 0.606 inch |
| body length | 1.228 inch |
| Body/casing type | PLUG |
| Connector type | D SUBMINIATURE CONNECTOR |
| Contact to complete cooperation | AU ON NI |
| Contact completed and terminated | TIN OVER NICKEL |
| Contact point gender | FEMALE |
| Contact material | COPPER ALLOY |
| contact mode | STAGGERED |
| Contact resistance | 10 mΩ |
| Contact style | RND PIN-SKT |
| Dielectric withstand voltage | 424VDC V |
| Filter function | YES |
| maximum insertion force | 3.336 N |
| Insulation resistance | 100000000 Ω |
| insulator material | GLASS FILLED POLYESTER |
| Manufacturer's serial number | 24 |
| Plug contact pitch | 0.109 inch |
| Match contact row spacing | 0.112 inch |
| Installation option 1 | M3 |
| Installation option 2 | THREADED |
| Installation method | RIGHT ANGLE |
| Installation type | BOARD |
| PCB row number | 2 |
| Number of rows loaded | 2 |
| Maximum operating temperature | 105 °C |
| Minimum operating temperature | -25 °C |
| PCB contact pattern | STAGGERED |
| PCB contact row spacing | 2.8448 mm |
| Rated current (signal) | 2.5 A |
| Guideline | UL |
| reliability | COMMERCIAL |
| Shell surface | TIN OVER NICKEL |
| Shell material | STEEL |
| Terminal length | 0.13 inch |
| Terminal pitch | 2.7686 mm |
| Termination type | SOLDER |
| Total number of contacts | 9 |
| Evacuation force-minimum value | 3.1692 N |
