BH8220KS datasheet, PDF - EEWORLD Datasheet

BH8220KS: DescriptionSingle chip analog signal processor for facsimiles; CategoryWireless rf/communication Telecom circuit; File Size203KB，9 Pages; ManufacturerROHM Semiconductor; Websitehttps://www.rohm.com/; Environmental Compliance

Download Datasheet Parametric View All

BH8220KS Overview

Single chip analog signal processor for facsimiles

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Parts packaging code	QFP
package instruction	SQFP-56
Contacts	56
Reach Compliance Code	compli
JESD-30 code	S-PQFP-G56
JESD-609 code	e3/e2
length	10 mm
Number of functions	1
Number of terminals	56
Maximum operating temperature	75 °C
Minimum operating temperature	-25 °C
Package body material	PLASTIC/EPOXY
encapsulated code	QFP
Package shape	SQUARE
Package form	FLATPACK
Peak Reflow Temperature (Celsius)	260
Certification status	Not Qualified
Maximum seat height	2.3 mm
Maximum slew rate	14 mA
Nominal supply voltage	5 V
surface mount	YES
Telecom integrated circuit types	TELECOM CIRCUIT
Temperature level	COMMERCIAL EXTENDED
Terminal surface	TIN/TIN COPPER
Terminal form	GULL WING
Terminal pitch	0.65 mm
Terminal location	QUAD
Maximum time at peak reflow temperature	10
width	10 mm
Base Number Matches	1

Communication ICs

Single chip analog signal processor for

facsimiles

BH8220KS

The BH8220KS is a single-chip analog signal processing IC developed for facsimiles with telephone answering ma-

chines.

FApplications

Facsimiles and facsimiles with telephone answering machines

FFeatures

1) Cross-point mixer with nine inputs and eight outputs.

2) Internal electronic volume.

3) Internal ALC and VOX circuits.

4) Accommodates no-ringing reception.

FAbsolute

maximum ratings (Ta = 25_C)

FRecommended

operating conditions (Ta = 25_C)

343
