LT1300CN8#PBF datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > LT1300CN8#PBF

LT1300CN8#PBF: DescriptionConv DC-DC 1.8V to 10V Step Up Single-Out 3.3V/5V 0.22A 8-Pin PDIP N Tube; File Size207KB，8 Pages; ManufacturerADI; Websitehttps://www.analog.com

Download Datasheet Parametric Compare View All

LT1300CN8#PBF Overview

Conv DC-DC 1.8V to 10V Step Up Single-Out 3.3V/5V 0.22A 8-Pin PDIP N Tube

LT1300CN8#PBF Parametric

Parameter Name	Attribute value
EU restricts the use of certain hazardous substances	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8542.39.00.01
Type	Step Up
Output Type	Fixed
Switching Frequency (kHz)	185
Switching Regulator	Yes
Number of Outputs	1
Output Voltage (V)	5\|3.3
Maximum Output Current (A)	0.22
Minimum Input Voltage (V)	1.8
Maximum Input Voltage (V)	10
Operating Supply Voltage (V)	1.8 to 10
Typical Quiescent Current (uA)	120
Line Regulation	0.15%/V
Efficiency (%)	88
Minimum Operating Temperature (°C)	0
Maximum Operating Temperature (°C)	70
Supplier Temperature Grade	Commercial
Packaging	Tube
Supplier Package	PDIP N
Pin Count	8
Standard Package Name	DIP
Mounting	Through Hole
Package Height	3.3
Package Length	10.16(Max)
Package Width	6.48
PCB changed	8
Lead Shape	Through Hole

Preview

Download Datasheet

View All

LT1300

Micropower High Efficiency

3.3/5V Step-Up DC/DC Converter

FEATURES

DESCRIPTION

The LT1300 is a micropower step-up DC/DC converter that

utilizes Burst Mode™ operation. The device can deliver 5V

or 3.3V from a two-cell battery input. It features program-

mable 5V or 3.3V output via a logic-controlled input, no-

load quiescent current of 120µA and a shutdown pin which

reduces supply current to 10µA. The on-chip power switch

has a low 170mV saturation voltage at a switch current of

1A, a four-fold reduction over prior designs. A 155kHz

internal oscillator allows the use of extremely small sur-

face mount inductors and capacitors. Operation is guaran-

teed at 1.8V input. This allows more energy to be extracted

from the battery increasing operating life. The I

LIM

pin can

be used to program peak switch current with a single

resistor allowing the use of less expensive and smaller

inductors and capacitors in lighter load applications. The

LT1300 is available in an 8-lead SOIC package, minimizing

board space requirements. For a 5V/12V Selectable Out-

put Converter see the LT1301. For increased output cur-

rent see the LT1302.

Burst Mode is a trademark of Linear Technology Corporation.

Up to 220mA Output Current at 5V from 2V Supply

Supply Voltage as Low as 1.8V

Up to 88% Efficiency

Small Inductor –10µH

120µA Quiescent Current

Shutdown to 10µA

Programmable 3.3V or 5V Output

LIM

Pin Programs Peak Switch Current

Low V

CESAT

Switch: 170mV at 1A Typical

Uses Inexpensive Surface Mount Inductors

8-Lead DIP or SOIC Package

APPLICATIONS

Palmtop Computers

Portable Instruments

Bar-Code Scanners

DC/DC Converter Module Replacements

Battery Backup Supplies

Personal Digital Assistants

PCMCIA Cards

TYPICAL APPLICATIONS

Two-Cell to 3.3V/5V Step-Up Converter

10µH

5V/3.3V 2

SELECT

LT1300

SHDN

PGND

LIM

GND

N/C

SENSE

EFFICIENCY (%)

5V Output Efficiency

5V/3.3V

OUTPUT

= 4.0V

= 3.0V

= 2.5V

= 2.0V

2×

CELL

100µF

SHUTDOWN

100µF

L1 = COILCRAFT DO1608-103

OR SUMIDA CD54-100

C1 = AVX TPSD107M010R0100

OR SANYO OS-CON 16SA100M

D1 = MBRS130LT3

OR 1N5817

LT1300 TA1

100

LOAD CURRENT (mA)

500

LT1300 TA2

LT1300CN8#PBF Related Products

	LT1300CN8#PBF	LT1300CS8#PBF	LT1300CS8#TRPBF	LT1300CS8
Description	Conv DC-DC 1.8V to 10V Step Up Single-Out 3.3V/5V 0.22A 8-Pin PDIP N Tube	Conv DC-DC 1.8V to 10V Step Up Single-Out 3.3V/5V 0.22A 8-Pin SOIC N Tube	Conv DC-DC 1.8V to 10V Step Up Single-Out 3.3V/5V 0.22A 8-Pin SOIC N T/R	Conv DC-DC 1.8V to 10V Step Up Single-Out 3.3V/5V 0.22A 8-Pin SOIC N
EU restricts the use of certain hazardous substances	Compliant	Compliant	Compliant	Not Compliant
ECCN (US)	EAR99	EAR99	EAR99	EAR99
Part Status	Active	Active	Active	Unconfirmed
Type	Step Up	Step Up	Step Up	Step Up
Output Type	Fixed	Fixed	Fixed	Fixed
Switching Frequency (kHz)	185	185	185	185
Switching Regulator	Yes	Yes	Yes	Yes
Number of Outputs	1	1	1	1
Output Voltage (V)	5\|3.3	3.3\|5	3.3\|5	3.3\|5
Maximum Output Current (A)	0.22	0.22	0.22	0.22
Minimum Input Voltage (V)	1.8	1.8	1.8	1.8
Maximum Input Voltage (V)	10	10	10	10
Operating Supply Voltage (V)	1.8 to 10	1.8 to 10	1.8 to 10	1.8 to 10
Typical Quiescent Current (uA)	120	120	120	120
Line Regulation	0.15%/V	0.15%/V	0.15%/V	0.15%/V
Efficiency (%)	88	88	88	88
Maximum Operating Temperature (°C)	70	70	70	70
Supplier Temperature Grade	Commercial	Commercial	Commercial	Commercial
Supplier Package	PDIP N	SOIC N	SOIC N	SOIC N
Pin Count	8	8	8	8
Standard Package Name	DIP	SOP	SOP	SOP
Mounting	Through Hole	Surface Mount	Surface Mount	Surface Mount
Package Height	3.3	1.5(Max)	1.5(Max)	1.5(Max)
Package Length	10.16(Max)	5(Max)	5(Max)	5(Max)
Package Width	6.48	3.99(Max)	3.99(Max)	3.99(Max)
PCB changed	8	8	8	8
Lead Shape	Through Hole	Gull-wing	Gull-wing	Gull-wing
HTS	8542.39.00.01	8542.39.00.01	-	8542.39.00.01
Packaging	Tube	Tube	Tape and Reel	-
