LTC1100CSW#PBF: DescriptionINST Amp Single ±8V/16V 16-Pin SOIC W Tube; File Size131KB，8 Pages; ManufacturerADI; Websitehttps://www.analog.com

Download Datasheet Parametric Compare View All

LTC1100CSW#PBF Overview

INST Amp Single ±8V/16V 16-Pin SOIC W Tube

LTC1100CSW#PBF Parametric

Parameter Name	Attribute value
EU restricts the use of certain hazardous substances	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8542.39.00.01
Number of Channels per Chip	1
Minimum CMRR (dB)	85
Minimum CMRR Range (dB)	85 to 95
Minimum PSRR (dB)	105
Maximum Input Offset Voltage (mV)	0.01@±5V
Maximum Operating Supply Voltage (V)	±8\|16
Maximum Supply Voltage Range (V)	15 to 18
Minimum Single Supply Voltage (V)	5
Typical Single Supply Voltage (V)	9\|12\|15
Maximum Single Supply Voltage (V)	16
Minimum Dual Supply Voltage (V)	±2.5
Typical Dual Supply Voltage (V)	±3\|±5
Maximum Dual Supply Voltage (V)	±8
Maximum Input Bias Current (uA)	0.000065@±5V
Maximum Supply Current (mA)	3.3@±5V
Power Supply Type	Single\|Dual
Minimum Operating Temperature (°C)	-40
Maximum Operating Temperature (°C)	85
Supplier Temperature Grade	Commercial
Packaging	Tube
Pin Count	16
Standard Package Name	SOP
Supplier Package	SOIC W
Mounting	Surface Mount
Package Height	2.34(Max)
Package Length	10.49(Max)
Package Width	7.6(Max)
PCB changed	16
Lead Shape	Gull-wing

Preview

Download Datasheet

View All

LTC1100

Precision, Zero-Drift

Instrumentation Amplifier

FEATURES

■

DESCRIPTIO

Offset Voltage: 10µV Max

Offset Voltage Drift: 100nV/°C Max

Bias Current: 65pA Max

Offset Current: 65pA Max

Gain Nonlinearity: 20ppm Max

Gain Error:

±0.075%

Max

CMRR: 90dB

0.1Hz to 10Hz Noise: 1.9µV

P-P

Single 5V Supply Operation

8-Pin MiniDIP

The LTC

1100 is a high precision instrumentation amplifier

using zero-drift techniques to achieve outstanding DC

performance. The input DC offset is typically 1µV while

the DC offset drift is typically 5nV/°C; a very low bias

current of 65pA is also achieved.

The LTC1100 is self-contained; that is, it achieves a differ-

ential gain of 100 without any external gain setting resistor

or trim pot. The gain linearity is 20ppm and the gain drift is

4ppm/°C. The LTC1100 operates from a single 5V supply

up to

±8V.

The output typically swings 300mV from its

power supply rails with a 10k load.

An optional external capacitor can be added from Pin 7 to

Pin 8 to tailor the device’s 18kHz bandwidth and to

eliminate any unwanted noise pickup.

The LTC1100 is also offered in a 16-pin surface mount

package with selectable gains of 10 or 100.

The LTC1100 is manufactured using Linear Technology’s

enhanced LTCMOS

silicon gate process.

, LTC and LT are registered trademarks of Linear Technology Corporation.

LTCMOS is a trademark of Linear Technology Corporation

APPLICATIO S

■

Thermocouple Amplifiers

Strain Gauge Amplifiers

Differential to Single-Ended Converters

TYPICAL APPLICATIO

Single 5V Supply, DC Instrumentation Amplifier

–V

LTC1100

0.01µF

OUT

= 5V

0.1µF

OUT

= 100 [V

– (–V

)]

LTC1100 • TA01

1100fc
