LTC1380CGN#PBF

Description
Analog Multiplexer Single 8:1 16-Pin SSOP N Tube
File Size217KB,12 Pages
ManufacturerADI
Websitehttps://www.analog.com
Download Datasheet Parametric Compare View All

LTC1380CGN#PBF Overview

Analog Multiplexer Single 8:1 16-Pin SSOP N Tube

LTC1380CGN#PBF Parametric

Parameter NameAttribute value
EU restricts the use of certain hazardous substancesCompliant
ECCN (US)EAR99
Part StatusActive
TypeAnalog Multiplexer
ConfigurationSingle 8:1
Multiplexer Architecture8:1
Number of Channels per Chip1
Number of Inputs per Chip8
Number of Outputs per Chip1
Chip Enable SignalsNo
Maximum Turn-On Time (ns)1130(Typ)@2.7V
Maximum Turn-Off Time (ns)670(Typ)@2.7V
Input Signal TypeSingle
Output Signal TypeSingle
Minimum Single Supply Voltage (V)2.7
Typical Single Supply Voltage (V)3|5|9
Maximum Single Supply Voltage (V)10
Minimum Dual Supply Voltage (V)±1.35
Typical Dual Supply Voltage (V)±3
Maximum Dual Supply Voltage (V)±5
Typical Supply Current (mA)0.01@5V/-0.0001@-5V
Maximum Supply Current (mA)0.02@5V/-0.005@-5V@-40C to 85C
Maximum High Level Output Current (mA)65
Maximum On Resistance (Ohm)400@2.7V
Maximum On Resistance Range (Ohm)400 to 1000
Power Supply TypeSingle|Dual
Maximum Power Dissipation (mW)500
Minimum Operating Temperature (°C)0
Maximum Operating Temperature (°C)70
Supplier Temperature GradeCommercial
PackagingTube
Pin Count16
Standard Package NameSOP
Supplier PackageSSOP N
MountingSurface Mount
Package Height1.5(Max)
Package Length4.98(Max)
Package Width3.99(Max)
PCB changed16
Lead ShapeGull-wing
LTC1380/LTC1393
Single-Ended 8-Channel/
Differential 4-Channel Analog
Multiplexer with SMBus Interface
FEATURES
s
s
s
s
s
s
s
s
s
DESCRIPTION
The LTC
®
1380/LTC1393 are CMOS analog multiplexers with
SMBus
®
compatible digital interfaces. The LTC1380 is a
single-ended 8-channel multiplexer, while the LTC1393 is a
differential 4-channel multiplexer. The SMBus digital inter-
face requires only two wires (SCL and SDA). Both the
LTC1380 and the LTC1393 have four hard-wired SMBus
addresses, selectable with two external address pins. This
allows four devices, each with a unique SMBus address, to
coexist on one system and for four devices to be synchro-
nized with one stop bit.
The supply current is typically 10µA. Both digital interface
pins are SMBus compatible over the full operating supply
voltage range. The LTC1380 analog switches feature a
typical R
ON
of 35Ω (±5V supplies), typical switch leakage of
20pA and guaranteed break-before-make operation. Charge
injection is
±1pC
typical.
The LTC1380/LTC1393 are available in 16-lead SO and GN
packages. Operation is fully specified over the commercial
and industrial temperature ranges.
, LTC and LT are registered trademarks of Linear Technology Corporation.
SMBus is a registered trademark of Intel Corporation.
Micropower Operation: Supply Current = 20µA Max
2-Wire SMBus Interface
Single 2.7V to
±5V
Supply Operation
Expandable to 32 Single or 16 Differential Channels
Guaranteed Break-Before-Make
Low R
ON
: 35Ω Single Ended/70Ω Differential
Low Charge Injection: 20pC Max
Low Leakage:
±5nA
Max
Available in 16-Lead SO and GN Packages
APPLICATIONS
s
s
s
s
s
Data Acquisition Systems
Process Control
Laptop Computers
Signal Multiplexing/Demultiplexing
Analog-to-Digital Conversion Systems
TYPICAL APPLICATION
LTC1380 Single-Ended 8-Channel Multiplexer
5V
On Resistance vs V
S
250
225
T
A
= 25°C
I
D
= 1mA
V
CC
= 2.7V
V
EE
= 0V
SMBus
HOST
1
2
3
4
8 ANALOG
INPUTS
5
6
7
8
S0
S1
S2
S3
S4
S5
S6
S7
ON RESISTANCE (Ω)
V
CC
SCL
SDA
LTC1380
A0
A1
GND
V
EE
D
O
16
15
14
13
12
11
10
9
0.1µF
15k
15k
200
175
150
125
100
75
50
V
CC
= 5V
V
EE
= – 5V
V
CC
= 5V
V
EE
= 0V
SCL
SDA
0.1µF
– 5V
ANALOG OUTPUT
1380/93 TA01
25
0
–5 –4 –3 –2 –1
0 1
V
S
(V)
2
3
4
5
U
U
U
1167 G15
1
