LTC1407AIMSE

Description
2-Channel Single ADC 3Msps 14-bit Serial Automotive 10-Pin MSOP EP
CategoryAnalog mixed-signal IC    converter
File Size429KB,24 Pages
ManufacturerADI
Websitehttps://www.analog.com
Download Datasheet Parametric Compare View All

LTC1407AIMSE Overview

2-Channel Single ADC 3Msps 14-bit Serial Automotive 10-Pin MSOP EP

LTC1407AIMSE Parametric

Parameter NameAttribute value
Is it Rohs certified?incompatible
MakerADI
package instructionHTSSOP,
Reach Compliance Codenot_compliant
ECCN codeEAR99
Maximum analog input voltage2.5 V
Minimum analog input voltage
Converter typeADC, PROPRIETARY METHOD
JESD-30 codeS-PDSO-G10
JESD-609 codee0
length3 mm
Maximum linear error (EL)0.0244%
Humidity sensitivity level1
Number of analog input channels2
Number of digits14
Number of functions1
Number of terminals10
Maximum operating temperature85 °C
Minimum operating temperature-40 °C
Output bit codeBINARY
Output formatSERIAL
Package body materialPLASTIC/EPOXY
encapsulated codeHTSSOP
Package shapeSQUARE
Package formSMALL OUTLINE, HEAT SINK/SLUG, THIN PROFILE, SHRINK PITCH
Peak Reflow Temperature (Celsius)235
Certification statusNot Qualified
Sampling rate3 MHz
Sample and hold/Track and holdSAMPLE
Maximum seat height1.1 mm
Nominal supply voltage3 V
surface mountYES
Temperature levelINDUSTRIAL
Terminal surfaceTin/Lead (Sn/Pb)
Terminal formGULL WING
Terminal pitch0.5 mm
Terminal locationDUAL
Maximum time at peak reflow temperature20
width3 mm
FEATURES
LTC1407/LTC1407A
Serial 12-Bit/14-Bit, 3Msps
Simultaneous Sampling
ADCs with Shutdown
DESCRIPTIO
The LTC
®
1407/LTC1407A are 12-bit/14-bit, 3Msps ADCs
with two 1.5Msps simultaneously sampled differential
inputs. The devices draw only 4.7mA from a single 3V
supply and come in a tiny 10-lead MS package. A Sleep
shutdown feature lowers power consumption to 10µW.
The combination of speed, low power and tiny package
makes the LTC1407/LTC1407A suitable for high speed,
portable applications.
The LTC1407/LTC1407A contain two separate differential
inputs that are sampled simultaneously on the rising edge
of the CONV signal. These two sampled inputs are then
converted at a rate of 1.5Msps per channel.
The 80dB common mode rejection allows users to elimi-
nate ground loops and common mode noise by measuring
signals differentially from the source.
The devices convert 0V to 2.5V unipolar inputs differen-
tially. The absolute voltage swing for CH0
+
, CH0
, CH1
+
and CH1
extends from ground to the supply voltage.
The serial interface sends out the two conversion results in
32 clocks for compatibility with standard serial interfaces.
, LT, LTC and LTM are registered trademarks of Linear Technology Corporation.
All other trademarks are the property of their respective owners.
Protected by U.S. Patents, including 6084440, 6522187.
3Msps Sampling ADC with Two Simultaneous
Differential Inputs
1.5Msps Throughput per Channel
Low Power Dissipation: 14mW (Typ)
3V Single Supply Operation
2.5V Internal Bandgap Reference with External
Overdrive
3-Wire Serial Interface
Sleep (10µW) Shutdown Mode
Nap (3mW) Shutdown Mode
80dB Common Mode Rejection at 100kHz
0V to 2.5V Unipolar Input Range
Tiny 10-Lead MS Package
APPLICATIO S
Telecommunications
Data Acquisition Systems
Uninterrupted Power Supplies
Multiphase Motor Control
I & Q Demodulation
Industrial Control
BLOCK DIAGRA
CH0
+
10µF
3V
7
1
V
DD
LTC1407A
14-BIT LATCH
+
S&H
CH0
2
MUX
3Msps
14-BIT ADC
8
SDO
THD, 2nd, 3rd (dB)
14-BIT LATCH
CH1
+
4
+
S&H
THREE-
STATE
SERIAL
OUTPUT
PORT
CH1
5
V
REF
GND
2.5V
REFERENCE
10
TIMING
LOGIC
9
CONV
3
10µF
6
11
SCK
EXPOSED PAD
1407A BD
U
W
U
THD, 2nd and 3rd
vs Input Frequency
–44
–50
–56
–62
–68
–74
–80
–86
–92
–98
–104
0.1
1
10
FREQUENCY (MHz)
100
1407 G02
THD
2nd
3rd
1407fa
1
