LTC1662CMS8

Description
DAC 2-CH 10-bit 8-Pin MSOP
File Size213KB,16 Pages
ManufacturerADI
Websitehttps://www.analog.com
Download Datasheet Parametric Compare View All

LTC1662CMS8 Overview

DAC 2-CH 10-bit 8-Pin MSOP

LTC1662CMS8 Parametric

Parameter NameAttribute value
EU restricts the use of certain hazardous substancesNot Compliant
ECCN (US)EAR99
Part StatusUnconfirmed
SVHCYes
SVHC Exceeds ThresholdYes
Converter TypeGeneral Purpose
Resolution10bit
Number of DAC Channels2
Number of Outputs per Chip2
Maximum Settling Time (us)750(Typ)
Digital Interface TypeSerial (3-Wire)
Output TypeVoltage
Output PolarityUnipolar
Voltage ReferenceExternal
Minimum Single Supply Voltage (V)2.7
Typical Single Supply Voltage (V)3.3|5
Maximum Single Supply Voltage (V)5.5
Power Supply TypeSingle
Integral Nonlinearity Error±4LSB
Full Scale Error±8LSB
Digital Supply SupportNo
Minimum Operating Temperature (°C)0
Maximum Operating Temperature (°C)70
Supplier Temperature GradeCommercial
Pin Count8
Standard Package NameMSOP
Supplier PackageMSOP
MountingSurface Mount
Package Height0.86
Package Length3
Package Width3
PCB changed8
Lead ShapeGull-wing
LTC1662
Ultralow Power, Dual
10-Bit DAC in MSOP
Features
n
n
Description
The LTC
®
1662 is an ultralow power, fully buffered voltage
output, dual 10-bit digital-to-analog converter (DAC). Each
DAC channel draws just 1.7µA (typ) total supply-plus-
reference operating current, yet is capable of supplying
DC output currents in excess of 1mA and reliably driving
capacitive loads of up to 1000pF A programmable sleep
.
mode further reduces total operating current to 0.05µA.
Linear Technology’s proprietary, inherently monotonic
architecture provides excellent linearity and an exception-
ally small external form factor. The double-buffered input
logic provides simultaneous update capability and can be
used to write to the DACs without interrupting sleep mode.
With its tiny operating current and exceptionally small
size, the LTC1662 is ideal for use in the most power-
constrained products. For most designs, there is no
perceptible impact on the power budget; the LTC1662
draws many times less current than even a trimpot,
while providing buffered, low impedance (0.5Ω typical,
V
CC
= 5V) rail-to-rail outputs.
The LTC1662 is pin and software compatible with the
LTC1661 dual, 60µA 10-bit DAC. It is available in 8-pin
MSOP and PDIP packages and is specified over the in-
dustrial temperature range.
n
n
n
n
n
n
n
Ultralow Power: 1.5µA (Typ) I
CC
per DAC Plus
0.05µA Sleep Mode for Extended Battery Life
Tiny: Two 10-Bit DACs in an 8-Lead MSOP—
Half the Size of an SO-8
Wide 2.7V to 5.5V Supply Range
Double Buffered for Simultaneous DAC Updates
Rail-to-Rail Voltage Outputs Drive 1000pF
Reference Range Includes Supply for Ratiometric
0V to V
CC
Output
Reference Input Impedance Is Code-Independent
(7.1MΩ Typ)—Eliminates External Buffers
3-Wire Serial Interface with Schmitt Trigger Inputs
Differential Nonlinearity: ±0.75LSB Max
applications
n
n
n
n
n
Mobile Communications
Portable Battery-Powered Instruments
Remote or Inaccessible Adjustments
Digitally Controlled Amplifiers and Attenuators
Factory or Field Calibration
L,
LT, LTC, LTM, Linear Technology and the Linear logo are registered trademarks of Linear
Technology Corporation. All other trademarks are the property of their respective owners.
Block Diagram
V
OUT A
8
GND
7
V
CC
6
V
OUT B
5
5.0
LATCH
LATCH
LATCH
10-BIT
DAC A
LATCH
10-BIT
DAC B
I
CC
+ I
REF
(µA)
4.5
4.0
3.5
3.0
2.5
2.0
1.5
1.0
SHIFT REGISTER
0.5 V
REF
= V
CC
CODE = 1023
0
–55 –35 –15 5 25 45 65 85 105 125
TEMPERATURE (°C)
3
SDI
4
REF
1662 BD
1662 TA01b
Total Supply-Plus-Reference
Operating Current
5.5V
4.5V
3.6V
V
CC
= 2.7V
CONTROL
LOGIC
ADDRESS
DECODER
1
CS/LD
2
SCK
1662fa
1

LTC1662CMS8 Related Products

LTC1662CMS8 LTC1662IMS8 LTC1662IN8
Description DAC 2-CH 10-bit 8-Pin MSOP DAC 2-CH 10-bit 8-Pin MSOP DAC 2-CH 10-bit 8-Pin PDIP N
EU restricts the use of certain hazardous substances Not Compliant Not Compliant Not Compliant
ECCN (US) EAR99 EAR99 EAR99
Part Status Unconfirmed Unconfirmed Unconfirmed
SVHC Yes Yes Yes
SVHC Exceeds Threshold Yes Yes Yes
Converter Type General Purpose General Purpose General Purpose
Resolution 10bit 10bit 10bit
Number of DAC Channels 2 2 2
Number of Outputs per Chip 2 2 2
Maximum Settling Time (us) 750(Typ) 750(Typ) 750(Typ)
Digital Interface Type Serial (3-Wire) Serial (3-Wire) Serial (3-Wire)
Output Type Voltage Voltage Voltage
Output Polarity Unipolar Unipolar Unipolar
Voltage Reference External External External
Minimum Single Supply Voltage (V) 2.7 2.7 2.7
Typical Single Supply Voltage (V) 3.3|5 3.3|5 3.3|5
Maximum Single Supply Voltage (V) 5.5 5.5 5.5
Power Supply Type Single Single Single
Integral Nonlinearity Error ±4LSB ±4LSB ±4LSB
Full Scale Error ±8LSB ±8LSB ±8LSB
Digital Supply Support No No No
Minimum Operating Temperature (°C) - -40 -40
Maximum Operating Temperature (°C) 70 85 85
Supplier Temperature Grade Commercial Industrial Industrial
Pin Count 8 8 8
Standard Package Name MSOP MSOP DIP
Supplier Package MSOP MSOP PDIP N
Mounting Surface Mount Surface Mount Through Hole
Package Height 0.86 0.86 3.3
Package Length 3 3 10.16(Max)
Package Width 3 3 6.48
PCB changed 8 8 8
Lead Shape Gull-wing Gull-wing Through Hole
HTS - 8542.39.00.01 8542.39.00.01
