LTC1799HS5#TRM datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > LTC1799HS5#TRM

LTC1799HS5#TRM: DescriptionSilicon Oscillator - 0.001MHz to 33MHz CMOS/Squarewave Automotive 5-Pin TSOT-23 T/R; File Size146KB，12 Pages; ManufacturerADI; Websitehttps://www.analog.com

Download Datasheet Parametric Compare View All

LTC1799HS5#TRM Overview

Silicon Oscillator - 0.001MHz to 33MHz CMOS/Squarewave Automotive 5-Pin TSOT-23 T/R

LTC1799HS5#TRM Parametric

Parameter Name	Attribute value
EU restricts the use of certain hazardous substances	Not Compliant
ECCN (US)	EAR99
Part Status	LTB
HTS	8542.39.00.01
SVHC	Yes
SVHC Exceeds Threshold	Yes
Type	Silicon Oscillator
Number of Outputs	1
Manual Reset	No
User Programming Method	Resistor
Standard Frequency Range (MHz)	0.001 to 33
Maximum Frequency Accuracy	±2.5%
Typical Frequency Temperature Coefficient	±0.004%/°C
Typical Frequency Line Regulation	0.05%/V
Maximum Symmetry (%)	55
Output Level	Squarewave\|CMOS
Output Signal Type	Single-Ended
Minimum Operating Supply Voltage (V)	2.7
Maximum Operating Supply Voltage (V)	5.5
Typical Operating Supply Voltage (V)	5\|3.3
Maximum Supply Current (mA)	2.4
Maximum Cycle to Cycle Jitter	0.4%(Typ)
Minimum Operating Temperature (°C)	-40
Maximum Operating Temperature (°C)	125
Supplier Temperature Grade	Automotive
Packaging	Tape and Reel
Standard Package Name	SOT-23
Pin Count	5
Supplier Package	TSOT-23
Mounting	Surface Mount
Package Height	0.9(Max)
Package Length	2.9
Package Width	1.75(Max)
PCB changed	5
Lead Shape	Gull-wing

Preview

Download Datasheet

View All

FEATURES

■

LTC1799

1kHz to 33MHz

Resistor Set SOT-23 Oscillator

DESCRIPTIO

The LTC

1799 is a precision oscillator that is easy to use

and occupies very little PC board space. The oscillator

frequency is programmed by a single external resistor

SET

). The LTC1799 has been designed for high accuracy

operation (≤1.5% frequency error) without the need for

external trim components.

The LTC1799 operates with a single 2.7V to 5.5V power

supply and provides a rail-to-rail, 50% duty cycle square

wave output. The CMOS output driver ensures fast rise/fall

times and rail-to-rail switching. The frequency-setting

resistor can vary from 3k to 1M to select a master

oscillator frequency between 100kHz and 33MHz (5V

supply). The three-state DIV input determines whether the

master clock is divided by 1, 10 or 100 before driving the

output, providing three frequency ranges spanning 1kHz

to 33MHz (5V supply). The LTC1799 features a proprietary

feedback loop that linearizes the relationship between

SET

and frequency, eliminating the need for tables to

calculate frequency. The oscillator can be easily pro-

grammed using the simple formula outlined below:

⎧

100, DIV Pin

⎛

10k

⎞

⎪

OSC

10MHz

•

⎜

⎟

, N

⎨

10, DIV Pin

Open

⎝

•

SET

⎠

⎪

1, DIV Pin

GND

⎩

One External Resistor Sets the Frequency

Fast Start-Up Time: < 1ms

1kHz to 33MHz Frequency Range

Frequency Error

≤1.5%

5kHz to 20MHz

= 25°C)

Frequency Error

≤

2% 5kHz to 20MHz

= 0°C to 70°C)

±40ppm/°C

Temperature Stability

0.05%/V Supply Stability

50%

±1%

Duty Cycle 1kHz to 2MHz

50%

±5%

Duty Cycle 2MHz to 20MHz

1mA Typical Supply Current

100Ω CMOS Output Driver

Operates from a Single 2.7V to 5.5V Supply

Low Profile (1mm) SOT-23 (ThinSOT™ Package)

APPLICATIO S

■

Low Cost Precision Oscillator

Charge Pump Driver

Switching Power Supply Clock Reference

Clocking Switched Capacitor Filters

Fixed Crystal Oscillator Replacement

Ceramic Oscillator Replacement

Small Footprint Replacement for Econ Oscillators

, LTC and LT are registered trademarks of Linear Technology Corporation.

All other trademarks are the property of their respective owners.

ThinSOT is a trademark of Linear Technology Corporation.

Protected by U.S. Patents including 6342817 and 6614313.

TYPICAL APPLICATIO

Typical Distribution of Frequency Error,

= 25°C (5kHz

≤

OSC

≤

20MHz, V

= 5V)

Basic Connection

0.1µF

≤

SET

≤

1kHz

≤

OSC

≤

33MHz

÷100

÷10

GND

SET

DIV

1799 TA01

UNITS (%)

OUT

LTC1799

OPEN

÷1

TSOT-23 Actual Size

–1.25

–0.75

–0.25 0 0.25

0.75

FREQUENCY ERROR (%)

1.25

1799 TA02

sn1799 1799fbs
