multiplying parallel-input, current-output DACs. These
DACs operate from a single 2.7V to 5.5V supply and are all
guaranteed monotonic over temperature. The LTC2753A-16
provides 16-bit performance (±1LSB INL and DNL) over
temperature without any adjustments. These SoftSpan™
DACs offer six output ranges—two unipolar and four
bipolar—that can be programmed through the parallel
interface, or pinstrapped for operation in a single range.
The LTC2753 DACs use a bidirectional input/output parallel
interface that allows readback of any on-chip register. A
power-on reset circuit resets the DAC outputs to 0V when
power is initially applied. A logic low on the
CLR
pin asyn-
chronously clears the DACs to 0V in any output range.
The parts are specified over commercial and industrial
temperature ranges.
, LT LTC and LTM are registered trademarks of Linear Technology Corporation.
,
SoftSpan is a trademark of Linear Technology Corporation. All other trademarks are the
property of their respective owners.
■
■
■
■
■
■
■
■
■
■
Six Programmable Output Ranges
Unipolar: 0V to 5V, 0V to 10V
Bipolar: ±5V, ±10V, ±2.5V, –2.5V to 7.5V
Maximum 16-Bit INL Error: ±1 LSB over Temperature
Low 1μA (Maximum) Supply Current
Guaranteed Monotonic over Temperature
Low Glitch Impulse 1nV•s
2.7V to 5.5V Single Supply Operation
2μs Settling Time to ±1 LSB
Parallel Interface with Readback of All Registers
Asynchronous
CLR
Pin Clears DAC Outputs to 0V in
Any Output Range
Power-On Reset to 0V
48-Pin 7mm × 7mm QFN Package
APPLICATIONS
■
■
■
■
High Resolution Offset and Gain Adjustment
Process Control and Industrial Automation
Automatic Test Equipment
Data Acquisition Systems
TYPICAL APPLICATION
Dual 16-Bit V
OUT
DAC with Software-Selectable Ranges
V
REF
5V
R
OFSA
47
R
IN
2
LTC2753-16
46 R
FBA
15pF
45 I
OUT1A
DAC A
R2
REFA 48
REFB 39
4 I
OUT2A
44 R
VOSA
43 R
VOSB
LTC2753-16 Integral Nonlinearity (INL)
V
DD
= 5V
0.8
V
REF
= 5V
±10V
RANGE
0.6
1.0
+
1/2 LT1469
R1
R
COM
1
–
150pF
INL (LSB)
DAC B
42 I
OUT1B
R
OFSB
40
SPAN I/O
DATA I/O
3
16
I/O PORT
I/O PORT
15pF
41 R
FBB
–
+
32 I
OUT2B
+
1/2 LT1469
V
OUTB
2753 TA01
–
1/2 LT1469
V
OUTA
0.4
0.2
0.0
–0.2
–0.4
–0.6
–0.8
–1.0
0
16384
32768
CODE
49152
25°C
90°C
–45°C
65535
2753 TA01b
2753f
1
LTC2753
ABSOLUTE MAXIMUM RATINGS
(Notes 1, 2)
I
OUT1X
, I
OUT2X
, R
COM
to GND .................................±0.3V
R
VOSX
, R
FBX
, R
OFSX
, R
IN
, REF
X
to GND ...................±15V
V
DD
to GND .................................................. –0.3V to 7V
Digital Inputs and Digital I/O
to GND ..........................–0.3V to V
DD
+0.3V (max 7V)
Operating Temperature Range
LTC2753C..................................................... 0°C to 70°C
LTC2753I .................................................. –40°C to 85°C
Maximum Junction Temperature........................... 125°C
Storage Temperature Range................... –65°C to 150°C
PIN CONFIGURATION
REFA
R
OFSA
R
FBA
I
OUT1A
R
VOSA
R
VOSB
I
OUT1B
R
FBB
R
OFSB
REFB
S1
WR
REFA
R
OFSA
R
FBA
I
OUT1A
R
VOSA
R
VOSB
I
OUT1B
R
FBB
R
OFSB
REFB
S1
WR
REFA
R
OFSA
R
FBA
I
OUT1A
R
VOSA
R
VOSB
I
OUT1B
R
FBB
R
OFSB
REFB
S1
WR
48 47 46 45 44 43 42 41 40 39 38 37
36
35
34
33
32
31
30
29
28
27
26
25
UPD
READ
D/S
S0
I
OUT2B
GND
NC
NC
NC
NC
D0
D1
R
COM
R
IN
S2
I
OUT2A
GND
D15
D14
D13
D12
D11
D10
D9
1
2
3
4
5
6
7
8
9
10
11
12
36
35
34
33
32
31
30
29
28
27
26
25
UPD
READ
D/S
S0
I
OUT2B
GND
NC
NC
D0
D1
D2
D3
49
13 14 15 16 17 18 19 20 21 22 23 24
D8
D7
V
DD
NC
A1
A0
GND
CLR
MSPAN
D6
D5
D4
LTC2753-16 UK PACKAGE
48-LEAD (7mm × 7mm) PLASTIC QFN
48 47 46 45 44 43 42 41 40 39 38 37
R
COM
R
IN
S2
I
OUT2A
GND
D11
D10
D9
D8
D7
D6
D5
1
2
3
4
5
6
7
8
9
10
11
12
36
35
34
33
32
31
30
29
28
27
26
25
UPD
READ
D/S
S0
I
OUT2B
GND
NC
NC
NC
NC
NC
NC
R
COM
R
IN
S2
I
OUT2A
GND
D13
D12
D11
D10
D9
D8
D7
1
2
3
4
5
6
7
8
9
10
11
12
48 47 46 45 44 43 42 41 40 39 38 37
49
49
13 14 15 16 17 18 19 20 21 22 23 24
D4
D3
V
DD
NC
A1
A0
GND
CLR
MSPAN
D2
D1
D0
13 14 15 16 17 18 19 20 21 22 23 24
D6
D5
V
DD
NC
A1
A0
GND
CLR
MSPAN
D4
D3
D2
LTC2753-14 UK PACKAGE
48-LEAD (7mm × 7mm) PLASTIC QFN
LTC2753-12 UK PACKAGE
48-LEAD (7mm × 7mm) PLASTIC QFN
T
JMAX
= 125°C,
θ
JA
= 29°C/W
EXPOSED PAD (PIN 49) IS GND, MUST BE SOLDERED TO PCB
T
JMAX
= 125°C,
θ
JA
= 29°C/W
EXPOSED PAD (PIN 49) IS GND, MUST BE SOLDERED TO PCB
T
JMAX
= 125°C,
θ
JA
= 29°C/W
EXPOSED PAD (PIN 49) IS GND, MUST BE SOLDERED TO PCB
ORDER INFORMATION
LEAD FREE FINISH
LTC2753CUK-12#PBF
LTC2753IUK-12#PBF
LTC2753CUK-14#PBF
LTC2753IUK-14#PBF
LTC2753BCUK-16#PBF
LTC2753BIUK-16#PBF
LTC2753ACUK-16#PBF
LTC2753AIUK-16#PBF
TAPE AND REEL
LTC2753CUK-12#TRPBF
LTC2753IUK-12#TRPBF
LTC2753CUK-14#TRPBF
LTC2753IUK-14#TRPBF
LTC2753BCUK-16#TRPBF
LTC2753BIUK-16#TRPBF
LTC2753ACUK-16#TRPBF
LTC2753AIUK-16#TRPBF
PART MARKING*
LTC2753UK-12
LTC2753UK-12
LTC2753UK-14
LTC2753UK-14
LTC2753UK-16
LTC2753UK-16
LTC2753UK-16
LTC2753UK-16
PACKAGE DESCRIPTION
48-Lead (7mm × 7mm) Plastic QFN
48-Lead (7mm × 7mm) Plastic QFN
48-Lead (7mm × 7mm) Plastic QFN
48-Lead (7mm × 7mm) Plastic QFN
48-Lead (7mm × 7mm) Plastic QFN
48-Lead (7mm × 7mm) Plastic QFN
48-Lead (7mm × 7mm) Plastic QFN
48-Lead (7mm × 7mm) Plastic QFN
TEMPERATURE RANGE
0°C to 70°C
–40°C to 85°C
0°C to 70°C
–40°C to 85°C
0°C to 70°C
–40°C to 85°C
0°C to 70°C
–40°C to 85°C
Consult LTC Marketing for parts specified with wider operating temperature ranges. *The temperature grade is identified by a label on the shipping container.
Consult LTC Marketing for information on non-standard lead based finish parts.
For more information on lead free part marking, go to:
http://www.linear.com/leadfree/
For more information on tape and reel specifications, go to:
http://www.linear.com/tapeandreel/
2753f
2
