LTC3410BESC6-1.8#TRMPBF

Description
Conv DC-DC 2.5V to 5.5V Synchronous Step Down Single-Out 1.8V 0.3A Automotive 6-Pin SC-70 T/R
File Size231KB,16 Pages
ManufacturerADI
Websitehttps://www.analog.com
Download Datasheet Parametric View All

LTC3410BESC6-1.8#TRMPBF Overview

Conv DC-DC 2.5V to 5.5V Synchronous Step Down Single-Out 1.8V 0.3A Automotive 6-Pin SC-70 T/R

LTC3410BESC6-1.8#TRMPBF Parametric

Parameter NameAttribute value
EU restricts the use of certain hazardous substancesCompliant
ECCN (US)EAR99
Part StatusActive
HTS8542.39.00.01
TypeSynchronous Step Down
Output TypeFixed
Switching Frequency (kHz)310(Typ)
Switching RegulatorYes
Number of Outputs1
Output Voltage (V)1.8
Maximum Output Current (A)0.3
Minimum Input Voltage (V)2.5
Maximum Input Voltage (V)5.5
Operating Supply Voltage (V)2.5 to 5.5
Line Regulation0.4%/V
Load Regulation0.5%(Typ)
Efficiency (%)96
Minimum Operating Temperature (°C)-40
Maximum Operating Temperature (°C)85
Supplier Temperature GradeExtended
PackagingTape and Reel
Pin Count6
Standard Package NameSOT-323
Supplier PackageSC-70
MountingSurface Mount
Package Height1(Max)
Package Length2.2(Max)
Package Width1.35(Max)
PCB changed6
Lead ShapeGull-wing
LTC3410B
2.25MHz, 300mA
Synchronous Step-Down
Regulator in SC70
FEATURES
DESCRIPTIO
High Efficiency: Up to 96%
300mA Output Current at V
IN
= 3V
380mA Minimum Peak Switch Current
2.5V to 5.5V Input Voltage Range
2.25MHz Constant Frequency Operation
No Schottky Diode Required
Low Dropout Operation: 100% Duty Cycle
Stable with Ceramic Capacitors
0.8V Reference Allows Low Output Voltages
Shutdown Mode Draws < 1µA Supply Current
±2%
Output Voltage Accuracy
Current Mode Operation for Excellent Line and
Load Transient Response
Overtemperature Protected
Available in Low Profile SC70 Package
The LTC
®
3410B is a high efficiency monolithic synchro-
nous buck regulator using a constant frequency, current
mode architecture. The device is available in adjustable
and fixed output voltage versions. Supply current during
operation is only 200µA, dropping to <1µA in shutdown.
The 2.5V to 5.5V input voltage range makes the LTC3410B
ideally suited for single Li-Ion battery-powered applica-
tions. 100% duty cycle provides low dropout operation,
extending battery life in portable systems. PWM pulse
skipping mode operation provides very low output ripple
voltage for noise sensitive applications.
Switching frequency is internally set at 2.25MHz, allowing
the use of small surface mount inductors and capacitors.
The LTC3410B is specifically designed to work well with
ceramic output capacitors, achieving very low output
voltage ripple and a small PCB footprint.
The internal synchronous switch increases efficiency and
eliminates the need for an external Schottky diode. Low
output voltages are easily supported with the 0.8V feed-
back reference voltage. The LTC3410B is available in a
tiny, low profile SC70 package.
, LT, LTC and LTM are registered trademarks of Linear Technology Corporation. All
other trademarks are the property of their respective owners. Protected by U.S. Patents,
including 5481178, 5994885, 6580258, 6304066, 6127815, 6498466, 6611131.
APPLICATIO S
Cellular Telephones
Personal Information Appliances
Wireless and DSL Modems
Digital Still Cameras
MP3 Players
Portable Instruments
TYPICAL APPLICATIO
V
IN
2.7V
TO 5.5V
V
IN
RUN
V
FB
GND
SW
Efficiency and Power Loss
vs Output Current
100
90
1
EFFICIENCY
0.1
4.7µH
C
IN
2.2µF
CER
LTC3410B
10pF
C
OUT
2.2µF
CER
V
OUT
1.2V
EFFICIENCY (%)
80
70
60
50
40
30
20
20
0
1
232k
464k
3410 TA01
U
POWER LOSS (W)
POWER LOSS
0.01
0.001
V
IN
= 2.7V
V
IN
= 3.6V
V
IN
= 4.2V
10
100
OUTPUT CURRENT (mA)
0.0001
1000
3410 TA01b
U
U
3410bfa
1
