for advanced portable application processor-based sys-
tems. The device contains four synchronous step-down
DC/DC converters for core, memory, I/O, and system on-
chip (SoC) rails and three 300mA LDO regulators for low
noise analog supplies. The LTC3676-1 has a ±1.5A buck
regulator configured to support DDR termination plus a
VTTR reference output. An I
2
C serial port may be used to
control regulator enables, power-down sequencing, output
voltage levels, dynamic voltage scaling, operating modes,
and status reporting.
Regulator start-up is sequenced by connecting outputs to
enable pins in the desired order or via the I
2
C port. System
power-on, power-off, and reset functions are controlled
by pushbutton interfaces, pin inputs, or I
2
C.
The LTC3676 supports i.MX, PXA and OMAP processors
with eight independent rails at appropriate power levels.
Other features include interface signals such as the VSTB
pin that toggles between programmed run and standby
output voltages on up to four rails simultaneously. The
device is available in a 40-lead 6mm × 6mm QFN and
48-lead exposed pad LQFP packages.
All registered trademarks and trademarks are the property of their respective owners.
n
Quad I
2
C Adjustable High Efficiency Step Down
DC/DC Converters: 2.5A, 2.5A, 1.5A, 1.5A
Three 300mA LDO Regulators (Two Adjustable)
DDR Power Solution with V
TT
and VTTR Reference
Pushbutton ON/OFF Control with System Reset
Independent Enable Pin-Strap or I
2
C Sequencing
Programmable Autonomous Power-Down Control
Dynamic Voltage Scaling
Power Good and Reset Functions
Selectable 2.25MHz or 1.125MHz Switching Frequency
Always Alive 25mA LDO Regulator
12µA Standby Current
Low Profile 40-Lead 6mm × 6mm QFN and 48-Lead
Exposed Pad LQFP Packages
AEC-Q100 Qualified for Automotive Application
APPLICATIONS
n
n
n
n
n
n
Supports Freescale i.MX6, ARM Cortex, and Other
Application Processors
Handheld Instruments and Scanners
Portable Industrial and Medical Devices
Automotive Infotainment
High End Consumer Devices
Multi-Rail Systems
TYPICAL APPLICATION
V
IN
2.7V TO 5.5V
Start-Up Sequence
1.5µH
V
ARM
1.38V
47µF 2.5A
V
SOC
1.38V
47µF 1.5A
V
DDR
(V
DDQ
)
1.5V
47µF 2.5A
V
TT
1/2 V
DDQ
47µF 1.5A
VTTR (1/2 V
DDQ
)
WAKE
2
3676 TA01a
V
RTC
3V
25mA
V
DD(HIGH)
2.97V
300mA
V
LDO3
1.8V
300mA
3V
300mA
LDO1
1µF
V
IN
SW3
WAKE
5V/DIV
V
DD(HIGH)
V
LDO3
1V/DIV
V
ARM
AND V
SOC
V
DDR
1V/DIV
V
TT
AND V
TTR
LTC3676-1
LDO2
SW2
1.5µH
1µF
LDO3
1µF
LDO4
1µF
6
ENABLES VTTR
PWR_ON WAKE
ON
PGOOD
I
2
C
GND
SW1
1.5µH
SW4
1.5µH
1ms/DIV
3676 TA01b
TO µPROCESSOR
Rev. H
Document Feedback
For more information
www.analog.com
1
LTC3676/LTC3676-1
ABSOLUTE MAXIMUM RATINGS
(Note 1)
V
IN
, DV
DD
..................................................... –0.3V to 6V
PV
IN1
, PV
IN2
, PV
IN3
, PV
IN4
, V
IN_L2
,
V
IN_L3
, V
IN_L4
.................................. –0.3V to V
IN
+ 0.3V
LDO1, FB_L1, LDO2, FB_L2, LDO3, LDO4, FB_L4,
FB_B1, FB_B2, FB_B3, FB_B4, PGOOD, VSTB, EN_B1,
EN_B2, EN_B3, EN_B4, EN_L2, EN_L3, EN_L4,
ON,
WAKE,
RSTO,
PWR_ON,
IRQ,
VTTR,
VDDQIN ....................................................... –0.3V to 6V
SDA, SCL ......................................–0.3V to DV
DD
+ 0.3V
Operating Junction Temperature Range
(Notes 2, 3) ............................................ –40°C to 150°C
Storage Temperature Range .................. –65°C to 150°C
PIN CONFIGURATION
LTC3676
PGOOD
RSTO
SW1
TOP VIEW
EN_B1
EN_B2
WAKE
PV
IN1
PV
IN2
SW2
IRQ
LTC3676-1
PGOOD
RSTO
SW1
TOP VIEW
EN_B1
EN_B2
WAKE
PV
IN1
PV
IN2
SW2
30 EN_L2
29
ON
28 LDO1
27 V
IN
41
GND
26 FB_L1
25 FB_B2
24 FB_B1
23 FB_B4
22 FB_B3
21 PWR_ON
11 12 13 14 15 16 17 18 19 20
SW4
SDA
SCL
PV
IN4
PV
IN3
DV
DD
EN_B4
EN_B3
VSTB
SW3
IRQ
40 39 38 37 36 35 34 33 32 31
FB_L2 1
V
IN_L2
2
LDO2 3
LDO3 4
V
IN_L3
5
LDO4 6
V
IN_L4
7
FB_L4 8
EN_L4 9
EN_L3 10
11 12 13 14 15 16 17 18 19 20
SW4
SDA
SCL
PV
IN4
PV
IN3
DV
DD
EN_B4
EN_B3
VSTB
SW3
41
GND
30 EN_L2
29
ON
28 LDO1
27 V
IN
26 FB_L1
25 FB_B2
24 FB_B1
23 FB_B4
22 FB_B3
21 PWR_ON
FB_L2 1
V
IN_L2
2
LDO2 3
LDO3 4
V
IN_L3
5
LDO4 6
V
IN_L4
7
VDDQIN 8
VTTR 9
EN_L3 10
40 39 38 37 36 35 34 33 32 31
UJ PACKAGE
40-LEAD (6mm
×
6mm) PLASTIC QFN
T
JMAX
= 150°C,
θ
JA
= 33°C/W,
θ
JC
= 2°C/W
EXPOSED PAD (PIN 41) IS GND, MUST BE SOLDERED TO PCB
UJ PACKAGE
40-LEAD (6mm
×
6mm) PLASTIC QFN
T
JMAX
= 150°C,
θ
JA
= 33°C/W,
θ
JC
= 2°C/W
EXPOSED PAD (PIN 41) IS GND, MUST BE SOLDERED TO PCB
LTC3676
TOP VIEW
NC
SW1
PGOOD
RST0
EN_B1
PV
IN1
PV
IN2
EN_B2
WAKE
IRQ
SW2
NC
LTC3676-1
TOP VIEW
NC
SW1
PGOOD
RST0
EN_B1
PV
IN1
PV
IN2
EN_B2
WAKE
IRQ
SW2
NC
NC 1
FB_L2 2
VIN_L2 3
LDO2 4
LDO3 5
VIN_L3 6
LD04 7
VIN_L4 8
VDDQIN 9
VTTR 10
EN_L3 11
NC 12
48
47
46
45
44
43
42
41
40
39
38
37
48
47
46
45
44
43
42
41
40
39
38
37
NC 1
FB_L2 2
VIN_L2 3
LDO2 4
LDO3 5
VIN_L3 6
LD04 7
VIN_L4 8
FB_L4 9
EN_L4 10
EN_L3 11
NC 12
49
GND
36
35
34
33
32
31
30
29
28
27
26
25
NC
EN_L2
ON
LDO1
V
IN
FB_L1
FB_B2
FB_B1
FB_B4
FB_B3
PWR_ON
NC
49
GND
36
35
34
33
32
31
30
29
28
27
26
25
NC
EN_L2
ON
LDO1
V
IN
FB_L1
FB_B2
FB_B1
FB_B4
FB_B3
PWR_ON
NC
NC 13
SW4 14
DVDD 15
SDA 16
SCL 17
PV
IN4
18
PV
IN3
19
EN_B4 20
EN_B3 21
VSTB 22
SW3 23
NC 24
LXE PACKAGE
48-LEAD (7mm
×
7mm) PLASTIC LQFP
T
JMAX
= 150°C,
θ
JA
= 19°C/W,
θ
JC
= 3°C/W
EXPOSED PAD (PIN 49) IS GND, MUST BE SOLDERED TO PCB
LXE PACKAGE
48-LEAD (7mm
×
7mm) PLASTIC LQFP
T
JMAX
= 150°C,
θ
JA
= 19°C/W,
θ
JC
= 3°C/W
EXPOSED PAD (PIN 49) IS GND, MUST BE SOLDERED TO PCB
Rev. H
2
For more information
www.analog.com
NC 13
SW4 14
DVDD 15
SDA 16
SCL 17
PV
IN4
18
PV
IN3
19
EN_B4 20
EN_B3 21
VSTB 22
SW3 23
NC 24
LTC3676/LTC3676-1
ORDER INFORMATION
LEAD FREE FINISH
LTC3676EUJ#PBF
LTC3676IUJ#PBF
LTC3676HUJ#PBF
LTC3676EUJ-1#PBF
LTC3676IUJ-1#PBF
LTC3676HUJ-1#PBF
AUTOMOTIVE PRODUCTS**
LTC3676EUJ#WPBF
LTC3676IUJ#WPBF
LTC3676HUJ#WPBF
LTC3676EUJ#WTRPBF
LTC3676IUJ#WTRPBF
LTC3676HUJ#WTRPBF
LTC3676UJ
LTC3676UJ
LTC3676UJ
40-Lead (6mm
6mm) Plastic QFN
40-Lead (6mm
6mm) Plastic QFN
40-Lead (6mm
6mm) Plastic QFN
–40°C to 125°C
–40°C to 125°C
–40°C to 150°C
TAPE AND REEL
LTC3676EUJ#TRPBF
LTC3676IUJ#TRPBF
LTC3676HUJ#TRPBF
LTC3676EUJ-1#TRPBF
LTC3676IUJ-1#TRPBF
LTC3676HUJ-1#TRPBF
PART MARKING*
LTC3676UJ
LTC3676UJ
LTC3676UJ
LTC3676UJ-1
LTC3676UJ-1
LTC3676UJ-1
PACKAGE DESCRIPTION
40-Lead (6mm
6mm) Plastic QFN
40-Lead (6mm
6mm) Plastic QFN
40-Lead (6mm
6mm) Plastic QFN
40-Lead (6mm
6mm) Plastic QFN
40-Lead (6mm
6mm) Plastic QFN
40-Lead (6mm
6mm) Plastic QFN
TEMPERATURE RANGE
–40°C to 125°C
–40°C to 125°C
–40°C to 150°C
–40°C to 125°C
–40°C to 125°C
–40°C to 150°C
LEAD FREE FINISH
LTC3676ELXE#PBF
LTC3676ILXE#PBF
LTC3676HLXE#PBF
LTC3676ELXE-1#PBF
LTC3676ILXE-1#PBF
LTC3676HLXE-1#PBF
AUTOMOTIVE PRODUCTS**
LTC3676ELXE#WPBF
LTC3676ILXE#WPBF
LTC3676HLXE#WPBF
TRAY
LTC3676ELXE#PBF
LTC3676ILXE#PBF
LTC3676HLXE#PBF
LTC3676ELXE-1#PBF
LTC3676ILXE-1#PBF
LTC3676HLXE-1#PBF
LTC3676ELXE#WPBF
LTC3676ILXE#WPBF
LTC3676HLXE#WPBF
PART MARKING*
LTC3676LXE
LTC3676LXE
LTC3676LXE
LTC3676LXE-1
LTC3676LXE-1
LTC3676LXE-1
LTC3676LXE
LTC3676LXE
LTC3676LXE
PACKAGE DESCRIPTION
48-Lead (7mm
7mm) Plastic eLQFP
48-Lead (7mm
7mm) Plastic eLQFP
48-Lead (7mm
7mm) Plastic eLQFP
48-Lead (7mm
7mm) Plastic eLQFP
48-Lead (7mm
7mm) Plastic eLQFP
48-Lead (7mm
7mm) Plastic eLQFP
48-Lead (7mm
7mm) Plastic eLQFP
48-Lead (7mm
7mm) Plastic eLQFP
48-Lead (7mm
7mm) Plastic eLQFP
TEMPERATURE RANGE
–40°C to 125°C
–40°C to 125°C
–40°C to 150°C
–40°C to 125°C
–40°C to 125°C
–40°C to 150°C
–40°C to 125°C
–40°C to 125°C
–40°C to 150°C
Contact the factory for parts specified with wider operating temperature ranges. *The temperature grade is identified by a label on the shipping container.
Tape and reel specifications.
Some packages are available in 500 unit reels through designated sales channels with #TRMPBF suffix.
**Versions
of this part are available with controlled manufacturing to support the quality and reliability requirements of automotive applications. These
models are designated with a #W suffix. Only the automotive grade products shown are available for use in automotive applications. Contact your
local Analog Devices account representative for specific product ordering information and to obtain the specific Automotive Reliability reports for
these models.
Rev. H
For more information
www.analog.com
3
LTC3676/LTC3676-1
The
l
denotes the specifications which apply over the specified operating
junction temperature range, otherwise specifications are at T
A
= 25°C (Note 2). V
IN
= PV
IN1
= PV
IN2
= PV
IN3
= PV
IN4
= V
IN_L2
= V
IN_L3
=
V
IN_L4
= DV
DD
= 3.8V. All regulators disabled unless otherwise noted.
PARAMETER
Operating Input Supply Voltage, V
IN
V
IN
Standby Current
Undervoltage Fault Rising (Note 7)
Undervoltage Fault Falling
Undervoltage Warning
CNTRL[4:2] = 000 (POR Default)
CNTRL[4:2] = 001
CNTRL[4:2] = 010
CNTRL[4:2] = 011
CNTRL[4:2] = 100
CNTRL[4:2] = 101
CNTRL[4:2] = 110
CNTRL[4:2] = 111
l
ELECTRICAL CHARACTERISTICS
CONDITIONS
l
MIN
2.7
l
l
l
TYP
12
MAX
5.5
21
2.65
UNITS
V
µA
V
V
V
V
V
V
V
V
V
V
PWR_ON = 0V
2.35
2.55
2.45
2.7
2.8
2.9
3.0
3.1
3.2
3.3
3.4
Step-Down Switching Regulators 1, 2, 3 and 4
Output Voltage Range
Burst Mode V
IN
Quiescent Current
Pulse-Skipping Mode V
IN
Quiescent Current
Forced Continuous V
IN
Quiescent Current
®
V
FB
23
120
170
–0.05
100
625
0.8
PV
IN
50
200
300
0.05
V
µA
µA
µA
µA
%
Ω
V/ms
V
FB_BX
= 850mV (Note 5)
V
FB_BX
= 850mV (Note 5)
V
FB_BX
= 0V (Note 5)
V
FB_BX
= 850mV
V
FB
= 0V
Regulator Disabled
(Note 6)
DVBxA[4:0] = DVBxB[4:0] = 11111,
V
IN
= 2.7V to 5.5V
DVBxA[4:0] = DVBxB[4:0] = 11001,
V
IN
= 2.7V to 5.5V
DVBxA[4:0] = DVBxB[4:0] = 00000,
V
IN
= 2.7V to 5.5V
BUCKx[2] = 0
BUCKx[2] = 1
l
l
l
Feedback Pin Input Current
Maximum Duty Cycle
SW Pull-Down Resistance
Feedback Reference Soft-Start Rate
High Feedback Regulation Voltage (V
FB
)
Default Feedback Regulation Voltage (V
FB
)
Low Feedback Regulation Voltage (V
FB
)
Feedback LSB Step Size
Switching Frequency
1.5A Step-Down Switching Regulators 1 and 2
PMOS Current Limit
PMOS On-Resistance
NMOS On-Resistance
2.5A Step-Down Switching Regulators 3 and 4
PMOS Current Limit
PMOS On-Resistance
NMOS On-Resistance
l
l
l
l
788
714
404
800
725
412.5
12.5
812
736
421
mV
mV
mV
mV
l
l
1.7
0.85
2.0
2.25
1.125
2.7
1.35
MHz
MHz
A
l
160
80
l
mΩ
mΩ
A
3.0
120
70
mΩ
mΩ
VTTR + 10
0.51•VDDQIN
10
mV
mV
mA
mA
V/ms
Ω
Rev. H
Step-Down Switching Regulator 1 and VTTR (LTC3676-1)
Buck 1 Feedback Regulation Voltage
VTTR Output Voltage
VTTR Maximum Output Current
I
VIN
VTTR Enabled
LDO Regulators 2, 3 and 4
Feedback Reference Soft-Start Rate
Output Pull-Down Resistance
Regulator Disabled
10
625
VDDQIN = 1.5V
VDDQIN = 1.5V
l
l
l
VTTR – 10
0.49•VDDQIN
–10
VTTR
0.5•VDDQIN
1
4
For more information
www.analog.com
LTC3676/LTC3676-1
The
l
denotes the specifications which apply over the specified operating
junction temperature range, otherwise specifications are at T
A
= 25°C (Note 2). V
IN
= PV
IN1
= PV
IN2
= PV
IN3
= PV
IN4
= V
IN_L2
= V
IN_L3
=
V
IN_L4
= DV
DD
= 3.8V. All regulators disabled unless otherwise noted.
At present, hybrid vehicles mainly use nickel-metal hydride battery technology, but some technical performances of nickel-metal hydride batteries, such as energy density and charge and discharge speed...
Many chips have a bootloader at the start address when they leave the factory, such as 0x0~0x1000. However, after we burn it once, the bootloader at this location is erased.
Let me briefly talk about ...
DM6437 development board, can load out file at first. Later, after loading, it shows disable edma. After loading, click run and nothing happens. Please answer[/color][/align][align=left][color=#000]Af...
IntroductionCrest factor reduction (CFR) is a technique for reducing the peak-to-average ratio (PAR) of an orthogonal frequency division multiplexing (OFDM) waveform. An OFDM signal is made up in the ...
[b]「ADI Analog University」Basic Accelerometer Sensor[/b][size=5][color=rgb(0, 0, 0)][font=Helvetica, Arial, sans-serif][font=Helvetica, Arial, sans-serif][color=#000080](One copy of information per da...
I am currently working on a pxa270 platform, Windows CE 5.0 system. Right now, I can only do simple hibernation, suspension, etc. Has anyone implemented a slightly more complex function, such as reduc...
From being a global leader to losing the market, Korean battery manufacturers have always wanted to regain the lost market and dignity, but facing Chinese battery manufacturers represented by CAT...[Details]
A parallel inverter consists of two thyristors (T1 and T2), a capacitor, a center-tapped transformer, and an inductor. The thyristors provide a current path, while the inductor L maintains a consta...[Details]
As more and more consumers purchase new energy vehicles, the safety of electric vehicles has become a major concern. This has been particularly prominent following a series of electric vehicle fire...[Details]
"Have you set your calendar reminder?"
On August 24, Nvidia Robotics' official account posted a photo of a black gift box on a social media platform, with an attached greeting card sig...[Details]
In recent years, many people have switched to new energy vehicles, and this type of vehicle has indeed been highly sought after and is considered the future direction of automobile development, and...[Details]
Today's security industry has entered the era of massive networking. Many enterprises, especially financial institutions, have established multi-level video surveillance networking platforms. Lever...[Details]
1 Introduction
In the mid-1960s, American scientist Maas conducted extensive experimental research on the charging process of open-cell batteries and proposed an acceptable charging curve for ...[Details]
On August 21st, Zhiyuan Robotics revealed at its first partner conference that it expects shipments to reach thousands of units this year and tens of thousands next year. The company hopes to reach...[Details]
On August 22, the National Energy Administration released the latest data, showing that by the end of July 2025, China's total number of electric vehicle charging infrastructure will reach 16.696 m...[Details]
The automotive industry in 2025 is undergoing a thorough intelligent reshuffle.
Geely wants to make changes in the field of AI cockpits: in the future, there will be no traditional smart...[Details]
1 Source of creativity
With the further development of electronic technology, electronic pets have gradually entered people's family life. At present, there are two main categories of relative...[Details]
Have you ever heard stories about "crazy appliances"? Think of microwaves that turn on automatically or ovens that preheat without any human input? With radios and electromagnetic interfaces ubiqui...[Details]
With the development of science, the use of variable frequency technology is becoming more and more widespread, and it is used in both industrial equipment and household appliances. Inverter air co...[Details]
The MCX E series is the most reliability- and safety-focused series in NXP's extensive MCX product portfolio.
With the launch of this series, NXP has further enriched its 5V-compatible MCU pr...[Details]
Teletrac Navman has launched the Multi IQ dashcam, a cloud-based solution designed for large commercial vehicle operators. It connects up to five cameras to cover the vehicle's interior, sides, and...[Details]
Power technology
京公网安备 11010802033920号
EEWORLD
