Datasheet> All Categories > Discrete semiconductor> diode> DSS10-0045B

Preview

DSS10-0045B: DescriptionRectifier Diode, Schottky, 1 Phase, 1 Element, 10A, 45V V(RRM), Silicon, TO-220AC, PLASTIC PACKAGE-2; CategoryDiscrete semiconductor diode; File Size37KB，2 Pages; ManufacturerIXYS; Environmental Compliance

Download Datasheet Parametric View All

DSS10-0045B Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	DSS10-0045B	-	-	View	Buy Now

DSS10-0045B Overview

Rectifier Diode, Schottky, 1 Phase, 1 Element, 10A, 45V V(RRM), Silicon, TO-220AC, PLASTIC PACKAGE-2

DSS10-0045B Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	IXYS
Parts packaging code	TO-220AC
package instruction	PLASTIC PACKAGE-2
Contacts	3
Reach Compliance Code	compli
ECCN code	EAR99
Other features	FREE WHEELING DIODE, HIGH RELIABILITY, LOW NOISE
application	POWER
Shell connection	CATHODE
Configuration	SINGLE
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
Maximum forward voltage (VF)	0.47 V
JEDEC-95 code	TO-220AC
JESD-30 code	R-PSFM-T2
Maximum non-repetitive peak forward current	160 A
Number of components	1
Phase	1
Number of terminals	2
Maximum operating temperature	150 °C
Minimum operating temperature	-55 °C
Maximum output current	10 A
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	FLANGE MOUNT
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Maximum power dissipation	75 W
Certification status	Not Qualified
Maximum repetitive peak reverse voltage	45 V
surface mount	NO
technology	SCHOTTKY
Terminal form	THROUGH-HOLE
Terminal location	SINGLE
Maximum time at peak reflow temperature	NOT SPECIFIED
Base Number Matches	1

Preview

Download Datasheet

View All

DSS 10-0045B

Power Schottky Rectifier

I

FAV

= 10 A

V

RRM

= 45 V

V

F

= 0.46 V

V

RSM

V

45

V

RRM

V

45

Type

A

C

TO-220 AC

C

DSS 10-0045B

A

C (TAB)

A = Anode, C = Cathode , TAB = Cathode

Symbol

I

FRMS

I

FAV

I

FSM

E

AS

I

AR

(dv/dt)

cr

T

VJ

T

VJM

T

stg

P

tot

M

d

Weight

Conditions

T

C

= 135°C; rectangular, d = 0.5

T

VJ

= 45°C; t

p

= 10 ms (50 Hz), sine

I

AS

= 13 A; L = 180 µH; T

VJ

= 25°C; non repetitive

V

A

=1.5 • V

RRM

typ.; f=10 kHz; repetitive

Maximum Ratings

35

10

160

24

1.3

1000

-55...+150

150

-55...+150

A

mJ

A

V/µs

°C

W

Nm

g

Features

• International standard package

• Very low V

F

• Extremely low switching losses

• Low I

RM

-values

• Epoxy meets UL 94V-0

Applications

• Rectifiers in switch mode power

supplies (SMPS)

• Free wheeling diode in low voltage

converters

T

C

= 25°C

mounting torque

typical

75

0.4...0.6

2

Advantages

• High reliability circuit operation

• Low voltage peaks for reduced

protection circuits

• Low noise switching

• Low losses

Symbol

I

R

V

F

Conditions

T

VJ

= 25°C V

R

= V

RRM

T

VJ

= 100°C V

R

= V

RRM

I

F

= 10 A;

I

F

= 10 A;

I

F

= 20 A;

T

VJ

= 125°C

T

VJ

= 25°C

T

VJ

= 125 °C

Characteristic Values

typ.

max.

5

50

0.46

0.51

0.64

1.7

0.5

mA

V

K/W

Dimensions see Outlines.pdf

R

thJC

R

thCH

Pulse test:

Pulse Width = 5 ms, Duty Cycle < 2.0 %

Data according to IEC 60747 and per diode unless otherwise specified

338

IXYS reserves the right to change limits, Conditions and dimensions.

1-2
