PE01S/D series
1W DC/DC CONVERTER, SIP-Package, High Efficiency
FEATURES
Efficiency up to 88.5%
SIP Package with Industry Standard Pinout
Semi-regulated Output Voltage
Isolation Voltage 1000VDC
Operating Temperature Range –40°C to +85°C
UL/IEC/EN 60950-1 Safety
Single and Dual Outputs
Lead free, RoHs Compliant
>2 MHours MTBF
CSA / NRTL60950-1 safety approval
3 Years Product Warranty
The PE01S/D series are miniature, SIP Package, isolated 1W DC/DC converters with 1,000VDC isolation and very high efficiency .
It offers short circuit protection and allows a wide operating temperature range of –40°C to +85°C. These products provide a typical
load regulation of 2.5% to 5.0% depending on each model. The PE01S/D DC/DC converters are a compromise between a fully
regulated converter and a non-regulated converter . These isolated DC/DC converters are the latest offering from a world leader in
power systems technology and manufacturing
―
Delta Electronics, Inc.
Model List
Model
Number
Input
Voltage
(Range)
VDC
PE01S0505A
PE01S0509A
PE01S0512A
PE01S0515A
PE01D0505A
PE01D0509A
PE01D0512A
PE01D0515A
PE01S1205A
PE01S1209A
PE01S1212A
PE01S1215A
PE01D1205A
PE01D1209A
PE01D1212A
PE01D1215A
PE01S2405A
PE01S2409A
PE01S2412A
PE01S2415A
PE01D2405A
PE01D2409A
PE01D2412A
PE01D2415A
Output
Voltage
VDC
5
9
12
15
±5
±9
±12
±15
5
9
12
15
±5
±9
±12
±15
5
9
12
15
±5
±9
±12
±15
Output Current
Max.
mA
200
110
84
67
±100
±56
±42
±34
200
110
84
67
±100
±56
±42
±34
200
110
84
67
±100
±56
±42
±34
Min.
mA
4
2
1.5
1
±2
±1
±0.8
±0.7
4
2
1.5
1
±2
±1
±0.8
±0.7
4
2
1.5
1
±2
±1
±0.8
±0.7
Input Current
@Max.Load
mA(typ.)
238
228
232
230
237
234
233
236
99
95
95
95
99
98
95
94
50
48
48
48
50
49
48
49
@No Load
mA(typ.)
% (max.)
6.5
5
5.2
5
5.2
4.2
4.6
4.5
5
3.4
3.4
2.7
3.9
2.8
2.9
2.6
3.7
2.5
2.4
2.3
3.7
2.5
2.4
2.3
mA(typ.)
uF
Load
Reflected Max. capacitive Efficiency
Regulation Ripple
Load
(typ.)
@Max.oad
%
84
87
220
87
87.5
84.5
86
100*
86.5
86.5
84
86.5
220
88.5
88
84.5
86
100*
88.5
87.5
84
86.5
220
87.5
87.5
83.5
86
100*
87
87
* For each output
5
(4.5 ~ 5.5)
30
7
12
(10.8 ~ 13.2)
12
4
24
(21.6 ~ 26.4)
11
8
DS_PE01S/D_03152012
E-mail: DCDC@delta.com.tw
http://www.delta.com.tw/dcdc
P1
Input Characteristics
Parameter
Input Surge Voltage (1 sec. max.)
Model
5V Input Models
12V Input Models
24V Input Models
5V Input Models
12V Input Models
24V Input Models
All Models
Min.
-0.7
-0.7
-0.7
4.5
10.8
21.6
---
---
Typ.
Max.
---
9
---
18
---
30
5
5.5
12
13.2
24
26.4
---
0.3
Internal Capacitor
---
450
Unit
VDC
Input Voltage Range
Reverse Polarity Input Current
Input Filter
Internal Power Dissipation
A
mW
Output Characteristics
Parameter
Output Voltage Balance
Line Regulation
Load Regulation
Ripple & Noise (20MHz)
Temperature Coefficient
Short Circuit Protection
Conditions
Dual Output, Balanced Loads
For Vin Change of 1%
Io=20% to 100%
---
---
Min.
---
---
Typ.
±0.1
±1.05
30
±0.01
Max.
±1.0
±1.2
60
±0.02
Unit
%
%
mV
P-P
%/℃
See Model Selection Guide
0.5 Second Max.
General Characteristics
Parameter
I/O Isolation Voltage (rated)
I/O Isolation Resistance
I/O Isolation Capacitance
Switching Frequency
MTBF (calculated)
Safety Approvals
MIL-HDBK-217F@25℃,
Ground Benign
Conditions
60 Seconds
500 VDC
100KHz, 1V
Min.
1000
1000
40
50
2,000,000
Typ.
---
---
60
100
---
Max.
---
---
120
120
---
Unit
VDC
MΩ
pF
KHz
Hours
CSA 60950-1 recognition, IEC/EN 60950-1(CB-scheme)
Recommended Outside Input Fuse
5V Input Models
500mA Slow-Blow Type
12V Input Models
200mA Slow-Blow Type
24V Input Models
100mA Slow-Blow Type
Environmental Specifications
Parameter
Operating Temperature Range
(without Derating)
Case Temperature
Storage Temperature Range
Humidity (non condensing)
Cooling
Lead Temperature
(1.5mm from case for 10Sec.)
Conditions
Ambient
Min.
-40
---
-50
---
Free-Air convection
---
260
℃
Max.
+85
+95
+125
95
Unit
℃
℃
℃
% rel. H
DS_PE01S/D_03152012
E-mail: DCDC@delta.com.tw
http://www.delta.com.tw/dcdc
P2
Power Derating Curve
Output Voltage Tolerance
+20%
+15%
+20%
+15%
+10%
Max.
Output Power (%)
Output Voltage(%)
+10%
+5%
Vnom
Min.
Typ.
+5%
Vnom
-5%
-10%
100%
-5%
-10%
0%
20%
40%
60%
80%
Output Load Current (%)
Notes
1
2
3
4
5
Specifications typical at Ta=+25℃, resistive load, nominal input voltage and rated output current unless otherwise noted.
Ripple & Noise measurement bandwidth is 0-20MHz.
These power converters require a minimum output loading to maintain specified regulation, operation under no-load conditions will
not damage these modules; however they may not meet all specifications listed.
All DC/DC converters should be externally fused at the front end for protection.
Specifications subject to change without notice.
DS_PE01S/D_03152012
E-mail: DCDC@delta.com.tw
http://www.delta.com.tw/dcdc
P3
Mechanical Drawing
Mechanical Dimensions
19.5 [0.77]
Pin Connections
Pin
1
2
0.5 [0.02]
10.2 [0.40]
Single Output
+Vin
-Vin
-Vout
No Pin
+Vout
Dual Output
+Vin
-Vin
-Vout
Common
+Vout
4
5
6
3.2
[0.13]
0.5
[0.02]
2.35
[0.09]
5V & 12V Input :
T=6.1[0.24]
24V Input :
T=7.1[0.28] r
2.54
5.08
2X2.54
[0.10] [0.20] [2X0.10]
18.5 [0.73]
Bottom View
1
2
4
5
6
►All
dimensions in mm (inches)
T
►Tolerance:
X.X±0.25 (X.XX±0.01)
X.XX±0.13 ( X.XXX±0.005)
►
Pins ±0.05(±0.002)
0.25 [0.01]
0.50
[0.02]
Physical Outline
Case Size
(5&12V Input)
Case Size (24V Input)
Case Material
Weight (5&12V Input)
Weight (24V Input)
:
:
:
:
:
19.5x6.1x10.2mm (0.77x0.24x0.40 Inches)
19.5x7.1x10.2mm (0.77x0.28x0.40 Inches)
Non-Conductive Black Plastic (flammability to UL 94V-0 rated)
2.2g
2.6g
1.3 [0.05]
DS_PE01S/D_03152012
E-mail: DCDC@delta.com.tw
http://www.delta.com.tw/dcdc
P4
Part Numbering System
P
Form factor
D-DIP
P-SIP
S-SMD
E
Family series
A~Z
01
Watt
01:1W
02:2W
03:3W
04:4W
06:6W
S
Number of
Outputs
S - Single
D- Dual
05
Input Voltage
03:3.3V
05: 5V
12:12V
24: 24V
48:48V
05
Output Voltage
03:3.3V
05: 5V
12:12V
15: 15V
24: 24V
A
Option Code
A - Std. Functions
WARRANTY
Delta offers a three(3) years limited warranty. Complete warranty information is listed on our web site or is available upon request from Delta.
Information furnished by Delta is believed to be accurate and reliable. However, no responsibility is assumed by Delta for its use, nor for any
infringements of patents or other rights of third parties, which may result from its use. No license is granted by implication or otherwise under
any patent or patent rights of Delta. Delta reserves the right to revise these specifications at any time, without notice.
DS_PE01S/D_03152012
E-mail: DCDC@delta.com.tw
http://www.delta.com.tw/dcdc
P5
