PJ1117
1 Amp Low Dropout Positive Voltage Regulator
T
he PJ1117 Series of high performance positive voltage
regulators are designed for use in applications requiring
low dropout performance at full rated current,
Additionally, the PJ1117 Series provides excellent regulation
over variations due to changes in line, load and temperature.
Outstanding features include low dropout performance at
rated current, fast transient response. The PJ1117 Series are
three terminal regulators with fixed and adjustable voltage
options available in popular packages.
TO-220
TO-263
FEATURES
Low dropout voltage 1.3 V max.
Full current rating over line and temperature
Fast transient response
±2%Total
output regulation over line, load and
temperature
•
•
•
•
•
Adjust pin current max 120
µ
A over temperature
Line regulation typical 0.015%.
Load regulation typical 0.05%.
Fixed/adjustable output voltage
TO-220, TO-263, TO-252& SOT-223 package
TO-252
Pin: 1.Adj (Com)
2.Out
3.In
S
OT-223
Pin: 1.Adj (Com)
2.Out
3.In
ORDERING INFROMATION
Device
PJ1117CZ-adj / 1.8V
PJ1117CZ-2.5V /2.85V
PJ1117CZ-3.3V
PJ1117CZ-5.0V
PJ1117CM –adj / 1.8V
PJ1117CM-2.5V /2.85V
Operating Temperature
(Ambient)
Package
TO-220
BLOCK DIAGRAM
PJ1117CM-3.3V
PJ1117CM-5.0V
-20 to +85
o
C
PJ1117CW-adj / 1.8V
PJ1117CW-2.5V/2.85V
PJ1117CW-3.3V
PJ1117CW-5.0V
PJ1117CP-adj / 1.8V
PJ1117CP-2.5V/2.85V
PJ1117CP-3.3V
PJ1117CP-5.0V
NOTE: Contact factory for additional voltage option.
TO-263
SOT-223
TO-252
ABSOLUTE MAXIMUM RATING
Parameter
Input Voltage
Power Dissipation
Thermal Resistance Junction to Case
Thermal Resistance Junction to Ambient
Operating Junction Temperature Range
Operating Ambient Temperature Range
Storage Temperature Range
Lead Temperature (Soldering) 10 Sec.
1-6
Symbol
V
IN
P
D
Maximum
7
Internally Limited
2.5
50
0 to +125
-20 to +85
-25 to 150
260
2002.rev.A
o
o
Units
V
W
C /W
θ
JC
θ
JA
T
J
T
A
T
STG
T
LEAD
C
PJ1117
1 Amp Low Dropout Positive Voltage Regulator
ELECTRICAL CHARACTERISTICS
Unless otherwise specified, Adjust V
IN
= 2.75V to 12V and Adjust Io = 10mA to 1.0A
Fixed V
IN
= 4.75V to 12V and Fixed Io = 10mA to 1.0A
(For Fixed 5.0V Output Version ,V
IN
= 7.5V to 12V )
Test Conditions
Parameter
Output Voltage
(1)
Fixed Voltage
Reference Voltage
(1)
Adj Voltage
Line Regulation
(1)
(Vin-Vout=3V)
Load Regulation
(1)
(Vin-Vout=3V)
Dropout Voltage
ΔV
REF
=1%
Current Limit
(Vin-Vout=5V)
Quiescent Current
Fixed Model
Temperature Coefficient
Adjust Pin Current
I
Q
Tc
I
ADJ
25
5V
Ic
L
Over Temp.
12
0.005
55
120
Adjust Pin Current Change
Temperature Stability
Minimum Load Current
Adjust Model
RMS Output Noise
(2)
Ripple Rejection Ratio
(3)
ΔI
ADJ
Ts
Io
V
N
R
A
5V
1.0A
5V
5V
25
Over Temp.
60
500mA Over Temp.
0.2
0.5
5
0.003
72
10
5
%
mA
%Vo
dB
μA
14
mA
％/℃
1.0
V
D
REG
(LOAD)
REG
(LINE)
10mA
V
REF
5V
10mA
Symbol
Vo
V
IN
-V
OUT
5V
I
O
10mA
T
J(4)
25
Over Temp.
25
Over Temp.
25
Over Temp.
25
Over Temp.
25
Min
0.99|Vo|
0.98|Vo|
1.238
1.225
0.015
0.035
0.05
0.2
1
1.1
1.1
1.3
A
0.3
0.4
V
%
1.250
Test Limits
Typ
Vo
Max
1.01|Vo|
1.02|Vo|
1.262
1.275
0.2
V
Units
(1)Low duty cycle pulse testing with Kelvin connections required.
(2)Bandwidth of 10Hz to 10KHz.
(3)120Hz input ripple (C
ADJ
for ADJ) =25μF .
(4)Over Temp.-over specified operating junction temperature range.
2-6
2002.rev.A
PJ1117
1 Amp Low Dropout Positive Voltage Regulator
Typical Application Circuit
(1) C1 NEEDED IF DEVICE IS FAR FROM FILTER CAPACITORS
(1) C1 NEEDED IF DEVICE IS FAR FROM FILTER CAPACITORS
(2) C2 REQUIRED FOR STABILITY
3-6
2002.rev.A
