SPACE-PHY +5V or +3.3V Dual
MIL-STD-1553 Transceiver/Transformer
Connectivity Power Control
Data Sheet
Models: BU-67402FX
SPACE-PHY is a completely integrated Rad Tolerant MIL-STD-1553 physical layer in a single package, including dual
transceivers and transformers, and is designed to connect with IP incorporated in an FPGA or custom MIL-STD-1553
protocol ASIC.
Applications
•
Launch Vehicles
•
Military Satellites
•
Research Satellites
•
International Space Station
•
Commercial Telecommunication Satellite
Need a Custom Solution?
DDC can customize designs for all boards, ranging from simple
modifications of standard products to fully customized solutions
for commercial, military, aerospace, and industrial applications.
For more information:
www.ddc-web.com/BU-67402F
