Specification Control Drawing
100G1121
Issue 8
15th November 2012
Page 1 of 2
Page 2 is for internal use only
TWO CONDUCTOR CABLE, HALOGEN FREE INSULATION, SHIELDED AND HALOGEN FREE JACKETED,
750/1300 VOLT AC, 105°C
The complete requirements for procuring the wire described herein shall consist of this document.
Shield -
Tin Coated Copper, Optimised
Component wire -
100G0111
Jacket - Black
Zerohal®
Part
Description
C9
Nominal
Shield
Cross Equivalent Size
Sectional
AWG
(mm)
Area
Size
(mm²)
0.15
0.25
0.40
0.50
0.60
0.75
1.00
1.20
1.50
2.00
2.50
3.00
4.00
26
24
22
-
20
-
18
16
15
14
13
12
-
0.10
0.10
0.13
0.13
0.13
0.13
0.13
0.13
0.13
0.13
0.13
0.13
0.13
C10
C11
Jacket
Thickness
(mm)
Min.
0.22
0.22
0.22
0.22
0.22
0.22
0.22
0.22
0.22
0.22
0.22
0.22
0.22
C12
C13
C14
Overall Diameter Maximum
(mm)
Weight
(kg/km)
Nom.
3.09
3.30
3.81
3.99
4.19
4.44
4.65
5.00
5.30
5.88
6.29
6.72
7.33
Nom.
0.30
0.30
0.30
0.30
0.30
0.30
0.30
0.30
0.30
0.30
0.30
0.30
0.30
Max.
3.23
3.45
3.96
4.14
4.35
4.63
4.83
5.22
5.46
6.03
6.44
6.87
7.48
15.9
18.9
26.5
30.3
33.3
37.4
42.2
50.0
56.6
68.7
81.4
94.9
124
100G1121-0.15-*/*-*
100G1121-0.25-*/*-*
100G1121-0.40-*/*-*
100G1121-0.50-*/*-*
100G1121-0.60-*/*-*
100G1121-0.75-*/*-*
100G1121-1.00-*/*-*
100G1121-1.20-*/*-*
100G1121-1.50-*/*-*
100G1121-2.00-*/*-*
100G1121-2.50-*/*-*
100G1121-3.00-*/*-*
100G1121-4.00-*/*-*
'Zerohal' is a registered trademark of Tyco Electronics Corporation
COLOUR CODE:
The '*' in the part description shall be replaced by a standard colour code designator
in accordance with Mil Std 681.
e.g. 100G1121-1.00-2/6-0, cores red and blue, jacket black
PERFORMANCE
REQUIREMENTS
To be tested to and meet the requirements of the issue in effect of TE Specification WCD2015,
except that the minimum jacket elongation at break shall be 125%.
This product will have components available in the full colour range and may be marked
or unmarked in accordance with the order.
Standard outer jacket black but other colours available on request.
