Compact Technology
PR1001 thru PR1007
REVERSE VOLTAGE
- 50
to
1000
Volts
FORWARD CURRENT
- 1.0
Amperes
FAST RECOVERY RECTIFIERS
FEATURES
Fast switching for high efficiency
Low cost
Diffused junction
Low reverse leakage current
Low forward voltage drop
High current capability
The plastic material carries UL recognition 94V-0
A
DO-41
B
A
C
D
MECHANICAL DATA
Case : JEDEC DO-41 molded plastic
Polarity : Color band denotes cathode
Weight : 0.012 ounces, 0.34 grams
Mounting position : Any
DO-41
Dim.
A
B
C
Min.
25.4
4.20
0.70
Max.
-
5.20
0.90
2.00
2.70
D
All Dimensions in millimeter
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25 ambient temperature unless otherwise specified.
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%
CHARACTERISTICS
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward
Rectified Current
SYMBOL
PR1001 PR1002 PR1003 PR1004 PR1005 PR1006 PR1007
UNIT
V
RRM
V
RMS
V
DC
I
(AV)
50
35
50
100
70
100
200
140
200
400
280
400
1.0
30
1.3
5.0
100
600
420
600
800
560
800
1000
700
1000
V
V
V
A
@T
A
=
55 C
Peak Forward Surge Current
8.3ms single half sine-wave
super imposed on rated load (JEDEC Method)
Maximum forward Voltage at 1.0A DC
Maximum DC Reverse Current
at Rated DC Blocking Voltage
I
FSM
V
F
I
R
T
RR
C
J
R
0JA
A
V
uA
uA
@T
J
=25 C
@T
J
=100 C
Maximum Reverse Recovery Time (Note 1)
Typical Junction
Capacitance (Note 2)
Typical Thermal Resistance (Note 3)
Operating Temperature Range
Storage Temperature Range
150
15
30
-55 to +150
-55 to +150
250
500
ns
pF
C/W
T
J
T
STG
C
C
NOTES : 1.Measured with I
F
=0.5A,I
R
=1A,I
RR
=0.25A.
2.Measured at 1.0MHz and applied reverse voltage of 4.0V DC.
3.Thermal Resistance Junction to Case at 9.5mm Lead Length.PCB Mounted JEDEC Registered Value.
CTC0122 Ver.
2.0
1
of 2
PR1001 thru PR1007
Compact Technology
PR1001 thru PR1007
RATING AND CHARACTERISTIC CURVES
PEAK FORWARD SURGE CURRENT . ( A )
AVERAGE FORWARD CURRENT. ( A )
FIG . 1 - MAXIMUM TYPICAL FORWARD CURRENT
DERATING CURVE
1.0
.75
SINGLE PHASE
HALF WAVE 60Hz
RESISTIVE OR
INDUCTIVE LOAD
0.375" (9.5 mm)
LEAD LENGTH
FIG . 2 - MAXIMUM NON-REPETITIVE FORWARD
SURGE CURRENT
50
40
30
20
10
0
1
.50
8.3ms Single Half Sine
Wave JEDEC Method
.25
00
25
50
75
100
125
150
175
2
AMBIENT TEMPERATURE . (
O
C )
INSTANTANEOUS FORWARD CURRENT . ( A )
4
6 8 10
20
40 60 80 100
NUMBER OF CYCLES AT 60Hz
FIG 3 . - TYPICAL FORWARD
CHARACTERISTICS
20
10
Pulse Width=300
1% Duty Cycle
s
FIG . 4 - TYPICAL HUNCTION CAPACITANCE
100
HUNCTION CAPACITANCE . (pF)
60
40
3.0
1.0
20
0.3
0.1
Tj=25
O
C
10
1
2
4
6
10
20
40 60
REVERSE VOLTAGE . ( V )
100
.03
.01
.4
.6
.8
1.0 1.2
1.4 1.6
FORWARD VOLTAGE . (V )
1.8
FIG . 1 -REVERSE RECOVERY TIME CHARACTERISTIC
NONINDUCTIVE
AND TEST CIRCUIT DIAGRAM
50
NONINDUCTIVE
+0.5A
10
trr
(+ )
50Vdc
(approx)
(-)
DUT
PULSE
GENERATOR
( NOTE 2 )
0
-0.25A
NONINDUCTIVE
OSCILLOSCOPE
(NOTE 2 )
-1.0A
1cm
SET TIME BASE FOR
5/ 10ns / cm
NOTES: 1 . RISE TIME = 7nsmax. INPUT
IMPEDANCE= 1 MEGOHM 22pf
2 . RISE
TIME = 10ns max.SOURSE
IMPEDANCE = 50ohmsf
CTC0122 Ver.
2.0
2
of 2
PR1001 thru PR1007
