WWW.PHIHONG.COM
150W Power Factor Corrected Switchers
PSF-151 Low Profile Single and Dual Outputs
C
Features
2nd Generation Design
3.3/5 Volts Available
Power Factor Correction
Applications
Networking
Compact Equipment
Safety Approvals Pending
cUL 1950, 3rd Edition
CE (Low Voltage Directive)
Mechanical Characteristics
Dimensions: Length: 203mm (8in)
Width: 106.7mm (4.2in)
Output Specifications
Model
PFC Version
PSF151-033C
PSF151-050C
PSF151-120C
PSF151-150C
PSF151-240C
PSF151-480C
PSF151-201C
PSF151-203C
PSF151-211C
PSF151-213C
Fan(
All Models
)
DC Outputs
Voltage
3.3V
5V
12V
15V
24V
48V
5V
12V
5V
3.3V
3.3V
12V
3.3V
5V
12V
Min.
0A
0A
0A
0A
0A
0A
2A
0A
2A
0A
2A
0A
2A
0A
0A
Load
Conv. 30CFM
20A
20A
8.2A
6.6A
4A
2A
20A
4.6A
20A
6.6A
20A
4.6A
20A
6.6A
0.5A
30A
30A
12.5A
10A
6A
3.1A
30A
7A
30A
10A
30A
7A
30A
10A
1A
Ripple
(1)
P-P
50mV
50mV
120mV
150mV
240mV
480mV
50mV
120mV
50mV
50mV
50mV
120mV
50mV
50mV
120mV
US
Dedicated Fan Output
Through Channel Air Flow
Process Control
Industrial Microcomputers
TUV EN60950
Height: 38mm (1.5in)
Weight: 0.88Kg (2Ib)
Regulation
Line
+0.5%
+0.5%
+0.5%
+0.5%
+0.5%
+0.5%
+0.5%
+0.5%
+0.5%
+0.5%
+0.5%
+0.5%
+0.5%
+0.5%
+1%
Load
+5%
+5%
+3%
+3%
+3%
+3%
+3%
+3%
+3%
+3%
+3%
+3%
+3%
+3%
+3%
Max Power
Conv.
66W
100W
100W
100W
100W
100W
100W
(2)
100W
(2)
100W
(2)
100W
(2)
6W
30CFM
99W
150W
150W
150W
150W
150W
150W
(2)
150W
(2)
150W
(2)
150W
(2)
12W
(1) Measured at full load by using a 12in. twisted pair terminated with a 10mfd capacitor and a 0.1mfd ceramic in parallel.
(2) Combined power of both outputs must not exceed maximum rating.
PSF151 Characteristics
INPUT:
AC Input Voltage
90-264VAC
AC Input Frequency
47 to 63Hz
AC Input Current
4Arms (120VAC)
2Arms (230VAC)
AC Inrush Current (Cold Start)
35A max., at 120VAC
70A max., at 240VAC
AC Power Factor
EN 61000-3-2
Efficiency
80% Typical
OUTPUT:
Hold-up Time
12msec. typical, 120VAC
(10msec. for PSF151-050C)
Overshoot on Turn-On
<5%
Overvoltage Protection
>120% of Normal
on Main Output
Overcurrent Protection
Auto restart
Short Circuit
ENVIRONMENTAL:
Operation Temperature (Convection)
0 to 50
o
C Derated to 70
o
C
Storage Temperature
-20
o
C to +85
o
C
Humidity
10 to 90% RH (Non-condensing)
Emissions
FCC Class B
EN 55022B
Immunity
EN 50082-1: 1997
61000-4-2, Level 3
61000-4-3, Level 2
61000-4-4, Level 2
61000-4-5, Level 3
61000-4-6, Level 2
61000-4-11
Power Factor Correction
>0.9 @ full load
Meet EN 61000-3-2
GENERAL:
Leakage Current
Less than 2mA (254VAC)
Dielectric Withstand
Input to Chassis Ground
1500VAC, 1 min., 10mA
Switching Frequency
70KHz (typical)
MTBF (Full load, 25
o
C)
100K hrs.
(MIL-HDBK-217F)
AC Input Mating Connector
Molex 09-50-3051
DC Output Mating Connector
Terminal Strip, M4 Screw
Fan Mating Connector
Molex 09-50-3041
WWW.PHIHONG.COM
POWER SUPPLY
Dimension Diagram Unit: mm (inch)
PSF151/0405
