PUD-1205

Description
DC-DC Converter UNIT 1W UNREGULATED DC-DC CONVERTER
File Size309KB,9 Pages
ManufacturerPower Systems GmbH & Co. KG
Websitehttp://www.power-systems.de
Download Datasheet View All

PUD-1205 Overview

DC-DC Converter UNIT 1W UNREGULATED DC-DC CONVERTER

DC-DC Converter UNIT
PU Series
( 1W UNREGULATED DC-DC CONVERTER)
FEATURES
1000VDC-3000VDC ISOLATION
EFFICIENCY UP TO 83%
INTERNAL SMD TECHNOLOGY
LOW COST
NO HEATSINK REQUIRED
1W UNREGULATED OUTPUT
POWER
SINGLE IN LINE PACKAGE
100% BURNED IN
MTBF > 2,000,000 HOURS
OUTPUT SPECIFICATIONS
Voltage Setpoint Accuracy
Temperature Coefficient
Ripple & Noise (20MHz
BW)
Line Regulation
1
Load Regulation
2
Short Circuit Protection
+/-1.2% max
+/-8% max
Momentary
+/-2% max
+/-0.03%/
O
C
100mVp-p max
INPUT SPECIFICATIONS
Input Voltage Range
Input Filter
+/-10% max
Capacitor Type
GENERAL SPECIFICATIONS
Efficiency
Isolation Voltage
3
70%-83%
1000-3000 VDC min
9
10 ohms min
100 KHz min
80pF max
2,000,000 Hours
2.1g Typ
Non-Conductive Plastic
19.6mm*6.1mm*10.2mm
19.6mm*7.1mm*10.2mm
ENVIRONMENTAL SPECIFICATIONS
Operating Temperature
Storage Temperature
Cooling
-25
O
C to +71
O
C
-55
O
C to +125
O
C
Free-Air Convection
Isolation Resistance
Switching Frequency
Isolation Capacitance
MTBF
Weight
ALL SPECIFICATIONS TYPICAL AT NOMINAL
LINE,
FULL
LOAD
,
AND
25
O
Case Material
Case Size
C
UNLESS
OTHERWISE NOTED.
1
2
3
Line Regulation is for a 1.0% change in input Voltage.
Load Regulation is for output load current change from 20% to 100%.
For 10 seconds
www.Power-Systems.de
Page: 1 / 9
Version: 4-Oct-02
