CWR11 Series
MIL-PRF-55365/8
Fully qualified to MIL-PRF-55365/8, the CWR11 is the military version of EIA-
535BAAC, the commercial industry standard. It comprises four case sizes (A
through D). This series also offers molded body/compliant termination
construction, polarity, capacitance and JAN brand marking. The molded
construction is compatible with a wide range of SMT board assembly processes
including wave or reflow solder, conductive epoxy or compression bonding
techniques. There are three termination finishes available: fused solder plated
(“K” per MIL-PRF-55365), hot solder dipped (“C”) and gold plated (“B”).
HOW TO ORDER
CWR11
Type
J
Voltage
Code
C = 4Vdc
D = 6Vdc
F = 10Vdc
H = 15Vdc
J = 20Vdc
K = 25Vdc
M = 35Vdc
N = 50Vdc
B
Termination
Finish
K = Fused Solder
Plated
C = Hot Solder
Dipped
B = Gold Plated
225
Capacitance
Code
pF code:
1st two digits
represent
significant
figures 3rd digit
represents
multiplier
(number of zeros
to follow)
*
Capacitance
Tolerance
M = ±20%
K = ±10%
J = ±5%
@
Reliability
Grade
Weibull:
B = 0.1%/1000 hrs,
90% conf.
C = 0.01%/1000 hrs,
90% conf.
D = 0.001%/1000 hrs,
90% conf.
Comm: Z = Non ER
+
Surge Test
Option
A = 10 cycles, +25°C
B = 10 cycles, -55°C
& +85°C
C = 10 cycles, -55°C
& +85°C before
Weibull
Z = None (required
for CWR19 &
CWR29 only)
Packaging
Bulk = Standard
\TR = 7" T&R
\TR13 = 13" T&R
\W = Waffle
CAPACITANCE AND RATED VOLTAGE, V
R
(VOLTAGE CODE) RANGE
(LETTER DENOTES CASE SIZE)
Capacitance
µF
Code
0.10
104
0.15
154
0.22
224
0.33
334
0.47
474
0.68
684
1.0
105
1.5
155
2.2
225
3.3
335
4.7
475
6.8
685
10
106
15
156
22
226
33
336
47
476
68
686
100
107
150
157
220
227
330
337
4V (C)
6V (D)
10V (F)
Rated voltage DC (V
R
) to 85ºC
16V (H)
20V (J)
25V (K)
35V (M)
A
A
A
A
B
B
B
C
C
C
D
D
50V (N)
A
B
B
B
C
C
C
D
D
D
D
A
A
B
B
B
C
D
D
A
A
A
B
B
B
C
C
D
D
A
A
A
B
B
B
C
D
D
A
A
A
B
B
B
C
D
D
A
A
A
B
B
B
C
C
D
D
A
A
B
B
B
C
C
C
D
D
D
