PECL OSCILLATORS
HPL614 PECL OSCILLATORS
6 Pin Package
FEATURES
·
·
·
·
Phase Lock Loop technique
Low-cost PECL output package
Jitter 15ps RMS for non jitter-sensitive applications
Standard 14 pin DIL, 6 pin package
OUTLINES & DIMENSIONS
GENERAL SPECIFICATION
Output Waveform:
Frequency Range:
Frequency Stability:
Input Voltage Vcc
Output Voltage HIGH ‘1’ V
OH
:
LOW ‘0’ V
OL
:
Current Consumption:
Load:
Rise/Fall Times:
Duty Cycle:
Jitter
RMS:
1 Sigma:
SSB Phase noise:
15ps
20ps typical (clock period jitter)
(77.760MHz 5.0V example)
-60dBc @ 10Hz offset
-90dBc @ 100Hz offset
-105dBc @ 1kHz offset
-110dBc @ 10kHz offset
-110dBc @ 100kHz offset
10ms max.
±2ppm/year max.
-55° to +100°C
Disables both outputs when ‘LOW’
Internal pull-up.
PECL 10K square wave
PLL based
19.440MHz to 200MHz
See table
LVPECL
PECL
+3.3V±5%
+5.0V±5%
See note
See note
See table and note
50W into Vcc-2V
or Thevenin equivalent*
2ns max (20%~80%Vcc)
50±2% typ., 50±5% max.
(both outputs)
CURRENT CONSUMPTION
Current Consumption (mA)
+3.3
+5.0
75mA max excluding load current
95mA max excluding load current
Note: Total current consumption is is determined by the
user’s terminating scheme and internal pull-up resistors.
Start-up Time:
Ageing:
Storage Temperature:
Tri-state Option:
* Terminating resistors required on all outputs.)
NOTES
OUTPUT VOLTAGE
Output voltage can be to custom specification or standard at
2.25V min. for +3.3V supply or 3.95V min. for 5.0V supply.
To achieve necessary logic levels provide terminating scheme
information when ordering or use terminating resistors
recommended by Euroquartz.
ORDER CODE
Supply
Voltage
HPL614
Stability Code
(A to F)
Nominal
Frequency
Nominal
Frequency
Options
FREQUENCY STABILITY
Stability
(ppm)
±25
±50
±100
Temperature Range Order Code
0°~+70°C
A
B
C
-40°~+85°C
D
E
F
‘3’ for +3.3V Package Stability Code
A to F or
‘5’ for +5.0V Style
Cxx or Ixx
EXAMPLE:
Options
See table
5HPL614-A-125.0-1T
This describes HPL614 package PECL, +5.0Volt supply, ±25ppm over
0°to +70°C, at frequency of 125.0MHz with Tristate option.
Note: For non-standard frequency stability for commercial temperature
range use the Code’C’ followed by the stability, example ‘C20’ for
±20ppm over 0° to +70°C. For industrial temperature range use ‘I’
and the stability, example ‘I20’ for ±20ppm over -40° to +85°C.
MODEL OPTIONS
Pt. No.
Suffix
-1T
-3T
Pin 1
Tristate
No Connection
Pin 3
Pin 7
Pin 8
Pin 12
Complimentary
PECL Output
Complimentary
PECL Output
Pin 14
Supply Voltage
Supply Voltage
No Connection Case Ground PECL Output
Tristate
Case Ground PECL Output
EUROQUARTZ LIMITED Blacknell Lane CREWKERNE Somerset UK TA18 7HE
Tel: +44 1460 230000 Fax: +44 1460 230001 email: info@euroquartz.co.uk web: www.euroquartz.co.uk
