The TPC1XGKZRxG is an enhanced small form factor pluggable (SFP+) fiber
optic transceiver with digital diagnostics monitoring functionality (DDM).
Supporting Ethernet and Fiber Channel standards makes it ideally suited
for high capacity data-com and storage area network applications. DDM
functionality (alarm and warning features) is integrated into the design via an
I
2
C serial interface per the Multi-Source Agreement (MSA) SFF-8472, Rev. 10.4.
Each transceiver utilizes an electro absorption modulator integrated laser
(EML) with an operating wavelength with selectable to ITU-T standards
covering CWDM grid wavelengths. The transceiver supports data rates
ranging from 11.3Gbps down to 8Gbps. It provides an excellent solution
for data transmission at CWDM wavelength over up to 70km single mode
fiber. The low power consumption and excellent EMI performance enable
system design with high port density. The product is RoHS compliant and
is designed and tested in accordance with industry safety standards. The
transceiver is Class I Laser product per U.S. FDA/CDRH and international IEC-
60825 standards.
The TPC1XGKZRxG transceiver connects to standard 20-pad SFP+ connectors
for hot plug capability. This allows the system designer to make configuration
changes or maintenance by simply plugging in different transceivers without
removing the power supply from the host system. The transmitter and
receiver DATA interfaces are internally AC-coupled. LV-TTL Transmitter Disable
control input and Loss of Signal (LOS) output interfaces are also provided. The
transceiver has bail-type latch, which offers an easy and convenient way to
release the modules.
The transceiver operates from a single +3.3V power supply over an operating
case temperature range of 5°C to +70°C (commercial), or -5°C to +85°C
(extended) or -40°C to +85°C (industrial). The housing is made of metal for
EMI immunity.
Pb
Features
Temperature-stablized CWDM EML transmitter
Transmission distance up to 70km (SM Fiber)
Low power consumption
Wide case operating temperature range
Compliant with SFP+ Electrical MSA SFF-8431
Compliant with SFP+ Mechanical MSA SFF-8432
Compliant with 10GBASE-E specifications
Digital Diagnostics Monitoring (DDM) through
Serial Interface comply with SFF-8472, Rev. 10.4
RoHS 6/6 Compliant
Laser Class 1 IEC/CDRH compliant
Absolute Maximum Ratings
Parameter
Storage Temperature Range
“Commercial”
Operating Case Temperature
1
Operating Relative Humidity
2
Supply Voltage Range
Input Optical Power (Damage Threshold)
1
2
Symbol
T
ST
Extended
Industrial
RH
V
CC
P
in,damage
T
OP
Minimum
- 40
-5
-5
- 40
0
- 0.5
-
Maximum
+ 85
+ 70
+ 85
+ 85
85
+ 3.6
0
Units
°C
°C
%
V
dBm
Measured on top side of SFP+ module at the front center vent hole of the cage.
Non condensing
S0260 Rev.02. (web) 2014-01-08
TPC1XGKZRxG
Transmitter Performance Characteristics
(Over Operating Case Temperature. V
CC
= 3.13 to 3.47V)
Parameter
Data Rate
Center Wavelength
1
Center Wavelength Tolerance
Average Optical Output Power
Extinction Ratio
Relative Intensity Noise
Side Mode Suppression Ratio
Optical Return Loss Tolerance
Optical Output Eye
Symbol
B
λ
C
-
Minimum
-
- 6.5
0
8.2
-
30
-
Typical
10.3125
Maximum
-
+ 6.5
+4
-
- 128
-
- 21
Units
Gb/s
nm
nm
dBm
dB
dB/Hz
dB
dB
See Ordering Information Table
-
-
-
-
-
-
Compliant with IEEE 802.3ae
P
Avg
ER
RIN
SMSR
-
Receiver Performance Characteristics
(Over Operating Case Temperature. V
CC
= 3.13 to 3.47V)
Parameter
Data Rate
Wavelength of Operation
Receiver Sensitivity
@ 10.3125Gb/s
Receiver Sensitivity with
70km fiber @ 10.3125Gb/s
Receiver Reflectance
LOS Hysteresis
LOS Thresholds
Increasing Light Input
Decreasing Light Input
1471~1551nm
1571~1611nm
1471~1551nm
1571~1611nm
Symbol
B
λ
P
min BB
P
min Fiber
P
max
-
-
P
los+
P
los-
Minimum
-
1450
-
-
-
-
-8
-
0.5
-
- 38
Typical
10.3125
-
-
-
-
-
-
-
-
-
-
Maximum
-
1620
- 23.0
- 21.0
- 20.0
- 18.0
-
- 27
-
- 25
-
Units
Gb/s
nm
dBm
dBm
dBm
dB
dB
dBm
Maximum Input Power (10
-12
BER)
Note: The specified characteristics are met within the recommended range of operation. Unless otherwise noted typical data are quoted at nominal voltage and
+25°C ambient temperature.
Laser Safety:
All transceivers are Class I Laser products per
FDA/CDRH and IEC-60825 standards. They
must be operated under specified operating
conditions.
Oplink Communications, Inc.
DATE OF MANUFACTURE:
This product complies with
21 CFR 1040.10 and 1040.11
Meets Class I Laser Safety Requirements
Oplink Communications, Inc
2
S0260 Rev.02. (web) 2014-01-08
TPC1XGKZRxG
Transmitter Electrical Characteristics
Parameter
Differential Input Impedance
Differential Input Voltage Swing
Input HIGH Voltage (TX Disable)
1
Input LOW Voltage (TX Disable)
1
Output HIGH Voltage (TX Fault)
2
Output LOW Voltage (TX Fault)
2
1
2
(Over Operating Case Temperature. V
CC
= 3.13 to 3.47V)
Minimum
-
180
2.0
0
2.0
0
Typical
100
-
-
-
-
-
Maximum
-
700
V
CC
0.8
V
CC
+ 0.3
0.8
Units
Ω
mV
V
V
V
V
Symbol
Z
d
V
PP-DIFF
V
IH
V
IL
V
OH
V
OL
There is an internal 4.7kΩ to 10kΩ pull-up resistor to VccT.
Open collector compatible, 4.7kΩ to 10kΩ pull-up resistor to Vcc (Host Supply Voltage).
Receiver Electrical Interface
(Over Operating Case Temperature. V
CC
= 3.13 to 3.47V)
Parameter
Differential Output Impedance
Differential Output Swing
Output Rise and Fall time (20% to 80%)
Output HIGH Voltage (LOS)
Output LOW Voltage (LOS)
1
Symbol
Z
d
V
PP-DIFF
t
RH
, t
FH
V
OH
V
OL
Minimum
-
300
28
V
CC
- 1.3
0
Typical
100
-
-
-
-
Maximum
-
850
-
V
CC
+ 0.3
0.8
Units
Ω
mV
ps
V
V
1
1
Open collector compatible, 4.7kΩ to 10kΩ pull-up resistor to Vcc (Host Supply Voltage).
Electrical Power Supply Characteristics
(Over Operating Case Temperature. V
CC
= 3.13 to 3.47V)
Parameter
Power Supply Voltage
DC Common Mode Voltage
Supply Current
Power Consumption
Symbol
V
CC
V
CM
I
VCC
P
W
Minimum
3.13
0
-
-
Typical
3.30
-
365
1.2
Maximum
3.47
3.6
-
-
Units
V
V
mA
W
Note: The specified characteristics are met within the recommended range of operation. Unless otherwise noted typical data are quoted at nominal voltage and
+25°C ambient temperature.
Connector Pin-out
V
EE
R
10
9
8
7
6
5
4
3
2
1
11
12
13
14
15
V
EE
R
RD-
RD+
V
EE
R
V
CC
R
V
CC
T
V
EE
T
TD+
TD-
V
EE
T
RS1
RX_LOS
RS0
MOD-ABS
SCL
SDA
TX_D
ISABLE
TX_F
AULT
V
EE
T
T
OWARD
H
OST
16
17
18
19
20
T
OWARD
B
EZEL
Oplink Communications, Inc
3
S0260 Rev.02. (web) 2014-01-08
TPC1XGKZRxG
Module Pin Description
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Logic
-
LVTTL-O
LVTTL-I
LVTTL-I/O
LVTTL-I/O
-
LVTTL-I
LVTTL-O
LVTTL-I
-
-
CML-O
CML-O
-
-
-
-
CML-I
CML-I
-
Symbol
VeeT
TX_Fault
TX_Disable
SDA
SCL
MOD-ABS
RS0
RX_LOS
RS1
VeeR
VeeR
RD-
RD+
VeeR
VccR
VccT
VeeT
TD+
TD-
VeeT
Description
Module Transmitter Ground
Module Transmitter Fault
Transmitter Disable; Turns off transmitter laser output
2-Wire Serial Interface Data Line
2-Wire Serial Interface Clock
Module Definition, Grounded in the module
No function implemented
Receiver Loss of Signal Indication
No function implemented
Module Receiver Ground
Module Receiver Ground
Receiver Inverted Data Output
Receiver Non-Inverted Data Output
Module Receiver Ground
Module Receiver 3.3V Supply
Module Transmitter 3.3V Supply
Module Transmitter Ground
Transmitter Non-Inverted Data Input
Transmitter Inverted Data Input
Module Transmitter Ground
Application Notes
Electrical Interface:
All signal interfaces are compliant with
the SFP+ MSA specification. The high speed DATA interface
is differential AC-coupled internally and can be directly
connected to a 3.3V SERDES IC. All low speed control and
sense output signals are open collector TTL compatible and
should be pulled up with a 4.7k
Ω
- 10k
Ω
resistor on the host
board.
Loss of Signal (LOS):
The Loss of Signal circuit monitors the
level of the incoming optical signal and generates logic HIGH
when an insufficient photocurrent is produced.
TX_Fault:
The output indicates LOW when the transmitter
is operating normally and HIGH with a laser fault including
laser end-of-life. TX Fault is an open collector/drain output
and should be pulled up with a 4.7k
Ω
- 10k
Ω
resistor on the
host board.
TX_Disable:
When the TX Disable pin is at logic HIGH,
the transmitter optical output is disabled. The laser is also
disabled if this line is left floating, as it is pulled high inside
the transceiver.
Serial Identification and Monitoring:
The module definition
of SFP is indicated by the MOD_ABS pin and the 2-wrie serial
interface. Upon power up, the 2-wrie interface appears as NC
(no connection), and MOD_ABS is TTL LOW. When the host
system detects this condition, it activates the serial protocol
(standard two-wire I
2
C serial interface) and generates the
serial clock signal (SCL). The positive edge clocks data into the
EEPROM segments of the device that are not write protected,
and the negative edge clocks data from the device. The serial
data signal (SDA) is for serial data transfer. The host uses SDA
in conjunction with SCL to mark the start and end of serial
protocol activation. The supported monitoring functions
are temperature, voltage, bias current, transmitter power,
average receiver signal, all alarms and warnings, and software
monitoring of TX Fault/LOS. The device is internally calibrated.
The data transfer protocol and the details of the mandatory
and vendor specific data structures are defined in the SFP
MSA, and SFF-8472, Rev. 10.4.
Power Supply and Grounding:
The power supply line
should be well-filtered. All power supply bypass capacitors
should be as close to the transceiver module as possible.
Oplink Communications, Inc
4
S0260 Rev.02. (web) 2014-01-08
TPC1XGKZRxG
Interfacing the Transceivers
Communication is via a serial 2-wire serial interface. As described in the document SFF-8472 (REV. 10.4) there are two distinct address spaces:
Base Address A0(hex)
Byte Address
Content
Byte Address
Base Address A2(hex)
Content
0 – 95
96 – 127
128 – 255
Serial Transceiver ID as defined in SFP MSA
OPLINK Specific
Reserved
0 - 55
56 - 95
96 – 119
120 – 127
128 – 247
248 - 255
Alarm & Warnings thresholds & limits
External calibration constants (not used)
Values from real time diagnostic monitoring
Not used
Customer specific, writable area
Not used
Application Schematics
Recommended electrical connections to transceiver are shown below.
TD+
50 line
50 line
50 line
50 line
ASIC/
SerDes
+3.3V
R
+3.3V
R
+3.3V
R
4.7µH
+3.3V
0.1µF
+
22µF
0.1µF
VccR
TD-
RD+
4.7µH
+3.3V
0.1µF
+
22µF
0.1µF
VccT
RD-
SFP+
SCL, SDA, MOD_ABS
TX_Fault
RX_LOS
VeeT, VeeR
R: 4.7k to 10k
ESD & Electromagnetic Compatibility
Requirements
Standard
Status
Electro Static Discharge to the Electrical Pins (ESD)
Does anyone have any small projects suitable for beginners? I want to learn through practice and make up for whatever I lack. What I want is a small project with a bunch of original parts and solderin...
The integration of the RF front end of GSM mobile phones has been continuously developing, from front-end modules (FEMs) to radio frequency (RF) transceiver modules. In fact, the front-end integration...
1. Introduction----With the rapid development of economic level and science and technology, people have higher and higher requirements for security precautions, and enterprises as the main body of soc...
[align=left][font=微软雅黑]Nowadays, when we design electronic products, we often use lithium batteries for power supply. Just like mobile phones or tablets use lithium batteries for power supply, it may ...
I am a novice, and I am currently working on a switching power supply with an input of 300V and an output of 30~400V. I have seen many diagrams online and checked many chip data, but I still can't mak...
We are entering a new era where people are increasingly affordably equipped with more electronic gadgets. Electronics have become essential to our lives. For example, the average consumer now owns ...[Details]
Amidst the wave of intelligent automotive transformation, advanced driver assistance is gradually emerging from cutting-edge technology into the mainstream, becoming a new frontier of industry comp...[Details]
When discussing autonomous driving technology, there are often two extremes: on the one hand, there's the vision of "fully autonomous driving," while on the other, there's concern about potential s...[Details]
Have you ever heard stories about "crazy appliances"? Think of microwaves that turn on automatically or ovens that preheat without any human input? With radios and electromagnetic interfaces ubiqui...[Details]
The complexity of the integrated circuits (ICs) used in electronic systems in vehicles is increasing. They aim to execute artificial intelligence (AI) algorithms to control autonomous driving funct...[Details]
Charging is a familiar process for new energy vehicles, and as a source of battery energy, charging piles are crucial. New energy vehicle charging can be divided into fast charging and slow chargin...[Details]
During daily operation of an R-type power transformer, the voltage used varies as the equipment being used adjusts. This raises the question: can the transformer change voltage at this point? The a...[Details]
Preface
Low-voltage motors are widely used in nonferrous metallurgical plants. Their abnormal operation not only impacts normal production but can also threaten human life. Therefore, providin...[Details]
Plug-in hybrid vehicles (PHEVs) utilize two powertrains. Their pure electric range is typically inferior to that of pure electric vehicles, often reaching less than half that. Currently, mainstream...[Details]
0 Introduction
DVI (Digital Visual Interface) is a hot topic in current digital display research and application. Video processing technologies for DVI output not only address issues such as h...[Details]
summary
Modern cars strive to provide the same comfort and entertainment features found in the home, resulting in explosive growth in demand for electronic control units (ECUs). Howe...[Details]
Recently, I received a request to use OK1028A-C to output PWM square wave. However, I found that there was no relevant instructions on the OK1028 platform, so I started writing this article.
A...[Details]
On August 19, Huawei's Executive Director and Chairman of the Device BG, Richard Yu, shared a Weibo post about a conversation he had with a Zunjie S800 owner. The owner had driven over 5,000 kilome...[Details]
This new standardized, pre-integrated computing platform is designed to accelerate chip development, reduce development costs, and provide scalable software to power the AI-defined car.
...[Details]
The electric motor is one of the most widely used power equipment and plays a vital role in the national economy. However, its high failure rate causes huge economic losses to industrial and agricu...[Details]
51mcu
京公网安备 11010802033920号
EEWORLD
