High-power-density, an industrial temperature range of -40°C to +85°C and extra features like Remote-On-Off-
control are just some of the characteristics of this converter, ideal for highly sophisticated industrial-designs. The RSO
series is available with isolation of 2kV or 3kV by chosing option "/H2" or "/H3" in which case it is also ideal for medical
applications which additionally require EN-60601-1 certification. The “Z” version features 4:1 input voltage range, while
the standard version offers 2:1 input voltage range and includes a low voltage input range down to 4.5V.
Selection Guide
Part Number
SIP8
RSO-xx3.3S (H2/H3)
RSO-xx05S (H2/H3)
RSO-xx09S (H2/H3)
RSO-xx12S (H2/H3)
RSO-xx15S (H2/H3)
RSO-xx3.3D (H2/H3)
RSO-xx05D (H2/H3)
RSO-xx09D (H2/H3)
RSO-xx12D (H2/H3)
RSO-xx15D (H2/H3)
RSO-xx3.3SZ (H2/H3)
RSO-xx05SZ (H2/H3)
RSO-xx09SZ (H2/H3)
RSO-xx12SZ (H2/H3)
RSO-xx15SZ (H2/H3)
RSO-xx3.3DZ (H2/H3)
RSO-xx05DZ (H2/H3)
RSO-xx09DZ (H2/H3)
RSO-xx12DZ (H2/H3)
RSO-xx15DZ (H2/H3)
Input
Voltage Range
(VDC)
4.5-9, 9-18
18-36, 36-72
4.5-9, 9-18
18-36, 36-72
4.5-9, 9-18
18-36, 36-72
4.5-9, 9-18
18-36, 36-72
4.5-9, 9-18
18-36, 36-72
4.5-9, 9-18
18-36, 36-72
4.5-9, 9-18
18-36, 36-72
4.5-9, 9-18
18-36, 36-72
4.5-9, 9-18
18-36, 36-72
4.5-9, 9-18
18-36, 36-72
9-36
18-72
9-36
18-72
9-36
18-72
9-36
18-72
9-36
18-72
9-36
18-72
9-36
18-72
9-36
18-72
9-36
18-72
9-36
18-72
Rated Output
Voltage
(VDC)
3.3
5
9
12
15
±3.3
±5
±9
±12
±15
3.3
5
9
12
15
±3.3
±5
±9
±12
±15
Output Current
(mA)
300
200
111
83
67
±150
±100
±56
±42
±34
300
200
111
83
67
±150
±100
±56
±42
±34
Efficiency
typ.
(%)
68-72
70
73-75
75-78
74-78
78-81
75-80
80-83
75-80
80-83
68-72
70
73-75
75-76
74-78
78
75-79
79-80
75-79
79-80
70
70
78
75
81
78
83
80
83
80
74
70
77
75
78
78
80
80
80
80
Capacitive
Load max.
470µF
470µF
220µF
100µF
47µF
±220µF
±220µF
±100µF
±47µF
±22µF
470µF
470µF
220µF
100µF
47µF
±220µF
±220µF
±100µF
±47µF
±22µF
1 Watt
SIP8 Isolated
Single
&
Dual
Output
2002/95/EC
6/6
RoHS
EN-60950-1 Certified
EN-60601-1 Certified
(Suffix H2/H3)
RSO
2:1 Input
(RS0-S/D)
xx = 4.5-9Vin = 05
xx = 9-18Vin = 12
xx = 18-36Vin = 24
xx = 36-72Vin = 48
4:1 Input
(RSO-SZ/DZ)
xx = 9-36Vin = 24
xx = 18-72Vin = 48
Refer to Application Notes
E-81
www.recom-international.com
REV:0/2010
ECONOLINE
DC/DC-Converter
Input Voltage Range
Output Voltage Accuracy
Line Voltage Regulation
Load Voltage Regulation
(10% to 100% full load)
Output Ripple and Noise (20MHz limited)
Operating Frequency
Efficiency at Full Load
Quiescent Current
Nominal input Voltage
(Standard, /H2 and /H3)
CTRL Pin drive current /see Notes)
2:1
4:1
2:1
4:1
2:1
4:1
RS-05xxS_D
RS-12xxS_D
RS-24xxS_D, SZ_DZ
RS-48xxS_D, SZ_DZ
2:1 and 4:1
±2% typ.
±0.2% max.
±0.5% max.
±0.4% max.
±0.5% typ.
50mVp-p max.
200kHz min. / 500kHz max.
100kHz min. / 300kHz max.
See Selection Guide
40mA typ.
32mA typ.
25mA typ.
15mA typ.
3mA typ, 6mA max.
RSO-S_D(Z)
Series
Derating-Graph
(Ambient Temperature)
RSO-S_D
100
80
Specifications
(Core Operating Area)
measured at TA = 25°C, nominal input voltage, full load and after warm-up time unless otherwise specified
Output Power (%)
60
40
30
20
0
Safe Operating Area
Output Power (%)
Quiescent Input Current when Converter is OFF
10mA max.
Isolation Voltage
(tested for 1 second)
1000VDC min.
H2
2000VDC min.
H3
3000VDC min.
Rated Working Voltage
(long term isolation)
see Application Notes
Isolation Capacitance (1kV version)
2:1 Single
10pF min. / 40pF typ. / 60pF max.
Isolation Capacitance (H2 and H3)
2:1 Single
5pF min. / 30pF typ. / 60pF max.
Isolation Capacitance (1kV version)
2:1 Dual
120pF min. / 170pF typ. / 250pF max.
Isolation Capacitance (H2 and H3)
2:1 Dual
5pF min. / 30pF typ. / 60pF max.
Isolation Capacitance (1kV version)
4:1 Single/Dual
200pF max.
Isolation Capacitance (H2 and H3)
4:1 Single/Dual
30pF max.
Isolation Resistance
>1GΩ min.
Short Circuit Protection
Operating Temperature Range (free air convection)
Continuous
-40°C to +85°C (see Graph)
-55°C to +125°C
95% RH
4.7g
22 pcs per Tube
Detailed Information see
Application Notes chapter "MTBF"
85
Operating Temperature °C
-40
0
50
100
150
RSO-SZ_DZ
100
80
60
40
30
20
0
Safe Operating Area
RS0
Storage Temperature Range
Relative Humidity
Package Weight
Packing Quantity
MTBF (+25°C)
(+85°C)
75
Operating Temperature °C
-40
0
50
100
150
}
using MIL-HDBK 217F
using MIL-HDBK 217F
1685 x 10
3
hours
254 x 10
3
hours
Typical Characteristics
RSO-24xxS
Efficiency / Load
100
80
60
40
RSO-all types
2
1.5
2412
2409
Output Power (W)
2405
2415
Efficiency %
20
0
1
0.75
0.5
0
0%
20%
40%
60%
80%
100%
4.5 5
6
7
8
9
Total Output current (%)
Input Voltage (V)
E-82
REV: 0/2010
www.recom-electronic.com
ECONOLINE
DC/DC-Converter
Package Style and Pinning (mm)
8 PIN SIP Package
RSO-S_D(Z)
Series
3rd angle
projection
9.20
11.10
3.80
Single Output
Dual Output
RECOM
RSO-xxxx
****
0.50±0.05
RECOM
RSO-xxxx
****
1 2 3
5 6 7 8
RECOM
RSO-xxxxD
****
1 2 3
5 6 7 8
0.50±0.05
XX.X ± 0.5 mm
XX.XX ± 0.25 mm
Recommended Footprint Details
1.0ø+0.15/0
Pin Connections
Pin #
1
2
3
Single
–Vin
+Vin
CTRL
NC
+Vout
–Vout
NC*
Dual
–Vin
+Vin
CTRL
NC
+Vout
Com
–Vout
21.80
0.32
Bottom View
2.54
3.20
2.0
2.54
Top View
5
6
7
8
NC = No Connection
NC* = NC, but no external Connection allowed.
Notes
Pin 8 (NC*)
This pin is used internally and must have no external connection.
Pin 5 (NC)
Not connected internally.
Pin 3 (CTRL)
This pin provides an Off function which puts the converter into a low power mode. When the pin is ‘high’ the converter is OFF and when the pin is high ‘Z’ the converter is ON.
There is no allowed low state for this pin.
RSO
Application Examples
TTL Remote CTRL Circuit
Control Pin Input Current:
10mA
+Vin
10 KW
(see text)
Ctrl
(TTL)
-Vin
4.7 KW
20 KW
-Vout
RSO/RS/RS3
+Vout
Voltage Set Point Accuracy
with external input/output
capacitors refer to
typ. ± 1%
recommended test circuit: max. ±2%
Control Pin (CTRL) Input
Current, control voltage
applied via 1K resistor,
output voltage must
reduce to 0V:
typ. 3mA
max. 6mA
Voltage to be applied via a limiting resistor with a
