VSYAVF-27.000

Description
HCMOS Output Clock Oscillator, 16MHz Min, 130MHz Max, 27MHz Nom
CategoryPassive components    oscillator
File Size54KB,3 Pages
ManufacturerRaltron
Websitehttp://www.raltron.com/
Environmental Compliance
Download Datasheet Parametric View All

VSYAVF-27.000 Overview

HCMOS Output Clock Oscillator, 16MHz Min, 130MHz Max, 27MHz Nom

VSYAVF-27.000 Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
package instructionDILCC6,.2
Reach Compliance Codecompliant
Other featuresTAPE AND REEL; ENABLE DISABLE
Maximum control voltage2.5 V
Minimum control voltage
maximum descent time3 ns
Frequency Adjustment - MechanicalNO
Frequency offset/pull rate32 ppm
JESD-609 codee4
Manufacturer's serial numberVSY
Installation featuresSURFACE MOUNT
Number of terminals6
Maximum operating frequency130 MHz
Minimum operating frequency16 MHz
Nominal operating frequency27 MHz
Maximum operating temperature85 °C
Minimum operating temperature-40 °C
Oscillator typeHCMOS
Output load15 pF
Package body materialPLASTIC/EPOXY
Encapsulate equivalent codeDILCC6,.2
physical size7mm x 5mm x 1.5mm
power supply2.5 V
Certification statusNot Qualified
longest rise time3 ns
Maximum slew rate4 mA
Nominal supply voltage2.5 V
surface mountYES
maximum symmetry60/40 %
Terminal surfaceGold (Au)
VCXO
Page 1 of 3
VSY SERIES: VCXO OSCILLATOR, HCMOS, +2.5 VDC, 7x5mm Package
DESCRIPTION: A crystal controlled, high frequency, highly stable, voltage controlled oscillator, adhering to HCMOS
Standards. The output can be Tri-stated to facilitate testing or combined multiple clocks. The device is contained in a sub-
miniature, very low profile, leadless ceramic SMD package with 6 gold contact pads. This miniature oscillator is ideal for
today's automated assembly environments.
APPLICATIONS AND FEATURES:
"
"
"
"
Common Frequencies: 16.384 MHz; 19.44 MHz; 27 MHz; 38.88 MHz; 51.84 MHz; 77.76MHz; 123.6MHz
+2.5 VDC HCMOS
Frequency Range from 16 to 130 MHz
Miniature Ceramic SMD Package Available on Tape and Reel
Lead Free and ROHS Compliant
"
$
ABSOLUTE MAXIMUM RATINGS:
PARAMETER
SYMBOL
Ta
T(stg)
Vcc
Vc
Vo
VALUE
-40…+85
-55…+90
-0.5…+4.6
-0.5…Vcc+0.5
-0.5…Vcc+0.5
UNIT
°C
°C
VDC
VDC
VDC
Operating temperature range
Storage temperature range
Supply voltage range
Maximum Control Voltage
Maximum Output Voltage
$
ELECTRICAL PARAMETERS:
PARAMETER
SYMBOL
fo
Vcc
Is
PsRR
Fo=27MHz
Fo=35MHz
Fo=78MHz
Fo=126MHz
Frequency Change with Vcc varied
±10%
Nominal Vcc,
Nominal Load,
+25
±3°C
Connected from output to ground
Voh
Vol
DC
tr / tf
J
Jp
Measured at 50% of Vcc
Measured at 20/80% and
Fo<27MHz
80/20% Vcc Levels
Fo>35MHz
RMS Period Jitter 1sigma 1000 samples
*4
RMS Phase Jitter integrated from 12KHz to 20MHz
∆f
=100Hz Offset
∆f
=1KHz Offset
∆f
=10KHz Offset
∆f
=100KHz Offset
∆f
=1MHz Offset
*6
TEST CONDITIONS
*1
VALUE
16.000 ~ 130.000
+2.5
±10%
4.0 MAX, 2.8 TYP
6.0 MAX, 4.2 TYP
9.0 MAX, 7.2 TYP
12 MAX 10 TYP
±1
MAX
HCMOS
15
0.9•Vcc MIN
0.1•Vcc MAX
40/60 to 60/40 or 45/55 to 55/45
3.0 MAX 2.4 TYP
2.5 MAX 2 TYP
2.5 TYP
0.6 TYP
-80
-110
-130
-138
-145
0 to +2.5
100 TYP
*3
UNIT
MHz
VDC
mA
ppm
pF
VDC
VDC
%
ns
ps
ps
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
VDC
ppm/V
ppm
VDC
MΩ
kHz
VDC
VDC
VDC
Nominal Frequency
Supply Voltage
Supply Current
Power supply rejection
Output Logic Type
Load
Output Voltage Levels
Duty Cycle
Rise / Fall Time
*2
Jitter
Phase Jitter
Phase Noise
£ (∆f)
Typical measured at
100MHz
*5
Control Voltage Range
Control Voltage sensitivity
Absolute Pull Range
Settability
Input Impedance
Modulation Bandwidth
ESD protection
Pin 2
Output Enabled
Output Disabled
VC
∆f/fc(∆Vc)
APR
Vfo
Zin
BW
En
Dis
Positive slope; 10% linearity MAX
Minimum guaranteed freq. pull over
∆f/fc
DC to 1KHz
-3 dB
Human Body Model
High Voltage or No Connect
Ground
See Part Numbering
+1.25
±
0.25
2 MIN
45 MIN
2000 MIN
0.7•Vcc MIN
0.3•Vcc MAX
RALTRON ELECTRONICS CORP.
!
10651 N.W . 19
th
St
!
Miami, Florida 33172
!
U.S.A.
phone: (305) 593-6033
!
fax: (305) 594-3973
!
e-mail: sales@raltron.com
!
WEB: http://www.raltron.com
