SMN
Vishay Foil Resistors
High Precision Surface Mount 4 Resistor Network
Dual-In-Line Package with TCR Tracking
≤
0.5 ppm/°C,
Tolerance Match of 0.01 % and Ratio Stability of 0.005 %
FEATURES
•
Temperature Coefficient of Resistance (TCR)
(- 55 °C to + 125 °C, + 25 °C Ref):
Pb-free
Absolute: ± 2 ppm/°C typical (see table 2)
Available
Tracking: 0.5 ppm/°C typical (see table 2)
RoHS*
•
Power Rating: at 70 °C
COMPLIANT
Entire Package: 0.4 W
Each Resistor: 0.1 W
•
Resistance Tolerance Match: 0.01 %
•
Ratio Stability: 0.005 % (0.1 W at 70 °C, 2000 hours)
•
Large Variety of Resistance Ratios
•
Electrostatic Discharge (ESD) above 25 000 Volts
•
Short Time Overload
≤
0.0025 %
•
Non Inductive, Non Capacitive Design
•
Rise Time: 1 ns without ringing
•
Current Noise: < - 40 dB
•
Thermal EMF: 0.05 µV/°C
•
Voltage Coefficient < 0.1 ppm/V
•
Non Inductive: < 0.08 µH
•
Non Hot Spot Design
•
Terminal Finishes available: Lead (Pb)-free
Tin/Lead Alloy
•
For better performances please contact us
•
Available with Z-Foil technology, please see SMNZ
datasheet
Any value and any ratio available within resistance range
INTRODUCTION
Bulk Metal
®
Foil (BMF) Technology outperforms all other
resistor technologies available today for applications that
require High Precision and High Stability.
This technology has been pioneered and developed by
Vishay, and products based on this technology are the most
suitable for a wide range of applications.
BMF technology allows us to produce Customer Orientated
products designed to satisfy challenging and specific
technical requirements.
Model SMN offers low TCR (absolute and tracking),
excellent load life stability, tight tolerance (absolute and
match), excellent ratio stability, low thermal EMF, low current
noise and low voltage coefficient -
all in the same resistor.
IM
PR
O
VE
D
The SMN Surface Mount Network is made up of 4
independent BMF resistors in a small standard molded
epoxy package with 50 MIL lead pitch (JEDEC MS-012
package).
The electrical specification of this integrated construction
offers improved performance and better real estate utilization
over discrete resistors and matched sets. The resistor may
be used independently or as divider pairs.
Our Application Engineering Department is available to
advise and make recommendations. For non-standard
technical requirements and special applications, please
contact us.
TABLE 1 - RESISTANCE VALUES AND
TOLERANCES
(Tighter performances are available)
RESISTANCE VALUES
100
Ω
- 10 kΩ per resistor
ABSOLUTE TOLERANCE
EACH RESISTOR
± 0.02 %, ± 0.05 %, ± 0.1 %
RESISTANCE TOLERANCE
MATCH
0.01 %, 0.02 %, 0.05 %
* Pb containing terminations are not RoHS compliant, exemptions may apply
www.foilresistors.com
1
For any questions, contact:
foil@vishaypg.com
Document Number: 63081
Revision: 25-Mar-10
PR
O
DU
CT
APPLICATIONS
•
•
•
•
•
•
•
Instrumentation Amplifiers
Bridge Networks
Differential Amplifiers
Ratio Arms in Bridge Circuits
Medical and Test Equipment
Military
Airborne etc.
R
2
R
1
V
1
V
2
-
R
1
R
2
+
SMN
V
out
FIGURE 1 - SCHEMATICS
1)
R1
R1
R1
R1
OPTION 1
FOUR RESISTORS, SAME OHMIC VALUE
SAME ABSOLUTE TOLERANCE
R1
R2
R2
R1
Note
1. Different schematics are available (R1, R2, R3, R4)
OPTION 2
TWO RESISTOR PAIRS
R1/R2; R2/R1
SMN
Vishay Foil Resistors
FIGURE 2 - POWER DERATING CURVE
110
100
90
80
70
60
50
40
30
20
10
0
- 60 - 40
55
FIGURE 4 -TYPICAL TCR CURVE
(For more details, see table 2)
+ 150
+ 100
Percent of Rated Wattage
- 20
0
20
40
60
70
80
100
120 140
125
Ambient Temperature (°C)
FIGURE 3 - DIMENSIONS AND IMPRINTING
EXAMPLE
in inches (millimeters)
RATIO
TOLERANCE CODE
VALUE
R1
VALUE
R2
0.028 ± 0.001
(0.71 ± 0.025)
0.008 ± 0.001
(0.20 ± 0.025)
0.050
(1.27)
0.0165 ± 0.0025
(0.42 ± 0.064)
SMN
0.157
(3.99)
IM
PR
O
VE
D
10K Q 5K0
V
B0219
0.239 ± 0.005
(6.07 ± 0.13)
DATE
CODE
0.197 ± 0.005
(5.00 ± 0.13)
2° - 6°
0.0075
±
0.0025
(0.191
±
0.064)
0.068 ± 0.005
(1.73 ± 0.13)
Seating
Plane
FIGURE 6 - LAND PATTERN
in inches (millimeters)
D
C
G Z
Y
MINIMUM
MAXIMUM
E
X
Document Number: 63081
Revision: 25-Mar-10
For any questions, contact:
foil@vishaypg.com
PR
O
DU
CT
∆
R
+ 50
0
R
(ppm)
- 50
- 100
- 150
- 200
± 2 ppm/°C (+ 25 °C reference)
0
+ 20
+ 50
+ 75
- 50
- 55
- 25
+ 100
+ 125
Ambient Temperature (°C)
FIGURE 5 - TRIMMING TO VALUES
(Conceptual Illustration)
Interloop Capacitance
Reduction in Series
Current Path
Before Trimming
Mutual Inductance
Reduction due
to Change in
Current Direction
Current Path
After Trimming
Trimming Process
Removes this Material
from Shorting Strip Area
Changing Current Path
and Increasing
Resistance
Note:
Foil shown in
black,
etched spaces in
white
Z
G
X
Y
C
D
E
0.283
(7.19)
0.291
(7.39)
0.102
(2.59)
0.110
(2.79)
0.024
(0.61)
0.032
(0.81)
0.095
(2.41)
0.197
(5.00)
0.150
(3.81)
0.050
(1.27)
REFERENCE
www.foilresistors.com
2
SMN
Vishay Foil Resistors
TABLE 2 - PERFORMANCE SPECIFICATIONS
(Per MIL-PRF 914 Test Methods)
SPECIFICATIONS
Power Rating
at + 70 °C
TYPICAL LIMITS
Each resistor: 0.1 watts
Entire package: 0.4 watts
(P x R)
½
Maximum Working Voltage
(each resistor)
TCR
- 55 °C to + 125 °C (25 °C reference)
Thermal Shock
25 x (- 65 °C to + 125 °C)
Thermal Shock
5 x (- 65 °C to + 125 °C) and
Power Conditioning
1.5 rated power at 25 °C, 100 hours
DWV Atm. Pressure
200 V (A.C), 1 minute
Insulation Resistance
100 V (D.C), 1 minute
Resistance to Soldering Heat
IM
PR
O
VE
D
Shock (Specified Pulse)
100G
Vibration, High Frequency
(10 Hz - 2000 Hz), 20G
High Temperature Exposure
100 hours at 125 °C
Low Temperature Storage
24 hours at - 65 °C
Load Life Stability
at 70 °C; 0.1 watt per resistor, 2000 hours
Short Time Overload
6.25 x Rated Power; 5 seconds
Weight
www.foilresistors.com
3
Moisture Resistance
+ 65 °C to - 10 °C; 90 % to 98 % RH; 0.1 x rated power; 240 hours
For any questions, contact:
foil@vishaypg.com
PR
O
DU
CT
Absolute (typical and max. spread):
Tracking (maximum):
For R1/R2 = 1
For 1 < R1/R2
≤
10
For 10 < R1/R2
≤
100
ΔR
= 0.01 % (100 ppm)
ΔRatio
= 0.01 % (100 ppm)
± 2 ± 3 ppm/°C
1.0 ppm/°C
2.0 ppm/°C
3.0 ppm/°C
ΔR
= 0.02 % (200 ppm)
ΔRatio
= 0.015 % (150 ppm)
Successfully passed
> 10
4
MΩ
ΔR
= 0.01 % (100 ppm)
ΔRatio
= 0.005 % (50 ppm)
ΔR
= 0.02 % (200 ppm)
ΔRatio
= 0.005 % (50 ppm)
ΔR
= 0.01 % (100 ppm)
ΔRatio
= 0.01 % (100 ppm)
ΔR
= 0.005 % (50 ppm)
ΔRatio
= 0.005 % (50 ppm)
ΔR
= 0.01 % (100 ppm)
ΔRatio
= 0.005 % (50 ppm)
ΔR
= 0.005 % (50 ppm)
ΔRatio
= 0.005 % (50 ppm)
ΔR
= 0.005 % (50 ppm)
ΔRatio
= 0.005 % (50 ppm)
ΔR
= 0.005 % (50 ppm)
ΔRatio
= 0.0025 % (25 ppm)
0.08 g
Document Number: 63081
Revision: 25-Mar-10
SMN
Vishay Foil Resistors
TABLE 3 - GLOBAL PART NUMBER INFORMATION
NEW GLOBAL PART NUMBER: Y1365V0204QT9W (preferred part number format)
DENOTES PRECISION
Y
VCODE
RESISTANCE
VALUE CODE
TOLERANCE MATCH
T
= 0.01 %
Q
= 0.02 %
A
= 0.05 %
PACKAGING
R
= Tape and Reel
W
= Waffle Pack
U
= ESD Tubes
Y
1
3
6
5
V
0
PRODUCT CODE
SMN
= 1365
ABSOLUTE TOLERANCE
Q
= ± 0.02 %
A
= ± 0.05 %
B
= ± 0.1 %
FOR EXAMPLE: ABOVE GLOBAL ORDER Y1365 V0204 Q T 9 W:
TYPE: SMN
VALUES: 10K/500R
ABSOLUTE TOLERANCE: ± 0.02 %
TOLERANCE MATCH: 0.01 %
TERMINATION: Lead (Pb)-free
PACKAGING: Waffle Pack
HISTORICAL PART NUMBER: SMN 10K/500R TCR2 Q T S W (will continue to be used)
SMN
MODEL
SMN
10K/500R
RESISTANCE
VALUE
R
1
= 10 kΩ
R
2
= 500
Ω
TCR2
ABSOLUTE TCR
TCR2
Q
T
ABSOLUTE
TOLERANCE
Q
= ± 0.02 %
A
= ± 0.05 %
B
= ± 0.1 %
IM
PR
O
VE
D
Note
* For non-standard requests, please contact Application Engineering.
TABLE 4 - RESISTANCE VALUE CODE LIST FOR POPULAR RATIOS
VCODES
V0201
V0202
V0197
V0203
V0198
V0204
V0193
V0205
V0194
V0187
V0200
V0195
V0188
V0184
V0196
V0181
R1/R2
RATIO
100
50
R1
R2
VCODES
V0189
V0185
V0207
V0175
V0190
V0182
V0179
V0186
V0178
V0180
V0183
V0023
V0191
V0176
V0019
V0008
R1/R2
RATIO
2.5
R1
1K
500R
10K
2K
1K
400R
200R
500R
100R
200R
400R
500R
1K
2K
5K
10K
R2
400R
200R
5K
1K
500R
200R
100R
400R
100R
200R
400R
500R
1K
2K
5K
10K
25
20
10
5
4
10K
10K
5K
10K
5K
10K
2K
10K
2K
1K
5K
2K
1K
500R
2K
400R
100R
200R
100R
400R
200R
500R
100R
1K
200R
100R
1K
400R
200R
100R
500R
100R
Note
• Other values available upon request.
Document Number: 63081
Revision: 25-Mar-10
For any questions, contact:
foil@vishaypg.com
PR
O
DU
CT
2
0
4
Q
T
9
W
AER*
0
= Standard
9
= Lead (Pb)-free
1 - 999
= Custom
S
W
TOLERANCE
MATCH
T
= 0.01 %
Q
= 0.02 %
A
= 0.05 %
TERMINATION
PACKAGING
S
= Lead (Pb)-free
B
= Tin/Lead
T
= Tape and Reel
W
= Waffle Pack
U
= ESD Tubes
2
1.25
1
www.foilresistors.com
4
Legal Disclaimer Notice
Vishay Precision Group
Disclaimer
All product specifications and data are subject to change without notice.
Vishay Precision Group, Inc., its affiliates, agents, and employees, and all persons acting on its or their behalf
(collectively, “Vishay Precision Group”), disclaim any and all liability for any errors, inaccuracies or incompleteness
contained herein or in any other disclosure relating to any product.
Vishay Precision Group disclaims any and all liability arising out of the use or application of any product described
herein or of any information provided herein to the maximum extent permitted by law. The product specifications do
not expand or otherwise modify Vishay Precision Group’s terms and conditions of purchase, including but not limited
to the warranty expressed therein, which apply to these products.
No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this
document or by any conduct of Vishay Precision Group.
The products shown herein are not designed for use in medical, life-saving, or life-sustaining applications unless
otherwise expressly indicated. Customers using or selling Vishay Precision Group products not expressly indicated
for use in such applications do so entirely at their own risk and agree to fully indemnify Vishay Precision Group for
any damages arising or resulting from such use or sale. Please contact authorized Vishay Precision Group
personnel to obtain written terms and conditions regarding products designed for such applications.
Product names and markings noted herein may be trademarks of their respective owners.
Document Number: 63999
Revision: 22-Feb-10
www.vishaypg.com
1
京公网安备 11010802033920号
EEWORLD
