All specifications are based on 25°C, Nominal Input Voltage, and Maximum Output Current unless otherwise noted.
We reserve the right to change specifications based on technological advances.
GENERAL SPECIFICATIONS
Efficiency
Switching Frequency
TEST CONDITIONS
Min
Typ
Max
Unit
kHz
kHz
VAC
VAC
VAC
VDC
VDC
VDC
GΩ
pF
Nominal input voltage and full load
24VDC & 48VDC nominal input models
110VDC nominal input models
1 minute (reinforced insulation)
110VDC nominal input models
1 minute (basic insulation)
24VDC & 48VDC nominal input models
500VDC
Standard models
“T” suffix models
“TF” suffix models
“TF1” suffix models
Standard models
“T” suffix models
“TF” suffix models
“TF1” suffix models
24VDC & 48VDC nominal input models
110VDC nominal input models
24VDC & 48VDC nominal input models
Isolation Voltage
Isolation Resistance
Isolation Capacitance
PHYSICAL SPECIFICATIONS
Weight
Input to Output
Input to Case
Output to Case
Input to Output
Input to Case
Output to Case
225
270
3000
1500
1500
2250
1600
1600
1
See Table
250
275
300
330
2500
Dimensions (L x W x H)
Case Material
Base Material
Potting Material
SAFETY & EMC CHARACTERISTICS
Safety Approvals
EMI (See Note 4)
ESD
Radiated Immunity
Fast Transient (See Note 5)
Surge (See Note 5)
Conducted Immunity
Power Frequency Magnetic Field
3.70oz (105g)
8.29oz (235g)
9.88oz (280g)
10.12oz (287g)
2.40 x 2.28 x 0.50 inches (61.0 x 57.9 x 12.7 mm)
3.35 x 2.40 x 1.27 inches (85.0 x 61.0 x 32.3 mm)
3.35 x 2.40 x 1.47 inches (85.0 x 61.0 x 37.3 mm)
3.35 x 2.40 x 1.53 inches (85.0 x 61.0 x 38.8 mm)
Metal
Aluminum base-plate with plastic case
FR4 PCB
Silicon (UL94-V0)
UL60950-1
(10)
, EN60950-1, EN50155
Class A, Class B
Perf. Criteria A
Perf. Criteria A
Perf. Criteria A
Perf. Criteria A
Perf. Criteria A
Perf. Criteria A
EN55011, EN55022
EN61000-4-2
Air ±8kV and Contact ±6kV
EN61000-4-3
20 V/m
EN61000-4-4
±2kV
EN61000-4-5
EN55024 ±2kV and EN50155 ±2kV
EN61000-4-6
10 Vrms
EN61000-4-8
100A/m Continuous; 1000A/m 1 Second
1. Input Source Impedance: These converters will operate under all listed specifications without external components assuming that the source voltage has
very low impedance and reasonable input voltage regulation. Highly inductive source impedances can affect the stability of the converter. Since real world
voltage sources have finite impedance, performance can be improved by adding an external filter capacitor.
- For 24VDC & 48VDC nominal input models, we recommend Nippon chemi-con KY series, 100μF/100V.
- For 110VDC nominal input models, we recommend Ruby-con BXF series, 68µF/200V.
2. Maximum output deviation is +10% inclusive of remote sense and trim. If remote sense is not being used the +SENSE should be connected to its
corresponding +OUTPUT and likewise the -SENSE should be connected to its corresponding –OUTPUT.
3. (1) Thermal test conditions for vertical direction are by natural convection (20LFM).
(2) The iron base-plate dimensions are 19” x 3.5” x 0.063” (the height is EIA standard 2U).
(3) Heat sink is optional. See the “Model Number Setup” table on page 8 for suffix options.
4. The DCHBW100 standard models (no assembly options) can meet EN55011, EN55022 Class A or Class B with additional external components.
5. An external input filter capacitor is required if the module has to meet EN61000-4-4, EN61000-4-5. For 24VDC & 48VDC nominal input models, we
recommend connecting two aluminum electrolytic capacitors (Nippon chemi-con KY series, 220μF/100V) in parallel. For 110VDC nominal input models, we
recommend connecting three aluminum electrolytic capacitors (Nippon chemi-con KXJ series, 150μF/200V) in parallel.
6. Output voltage is adjustable for 10% trim up or -20% trim down of nominal output voltage by connecting a single resistor between TRIM and +SENSE
pins for trim up or between TRIM and -SENSE pins for trim down. To calculate the value of the resistor R
U
and R
D
for a particular output voltage see page 6.
7. Measured by 20MHz bandwidth.
8. CASE GROUNDING: EMI can be reduced when you connect the four screw bolts to the shield plane.
9. This series comes with several different options: negative remote on/off control, heatsinks, case pin, sync pin, pin length, terminal block, and thru-hole
inserts. See the “Model Number Setup” table on page 8 for more ordering information.
10. This product is Listed to applicable standards and requirements by UL.
CAUTION:
This power converter is not internally fused. An input line fuse must always be used.
Due to advances in technology, specifications are subject to change without notice.
