Multilayer Ceramic Chip Capacitors
FEATURES
• X7R, X5R AND Y5V DIELECTRICS
• HIGH CAPACITANCE DENSITY
• ULTRA LOW ESR & ESL
• EXCELLENT MECHANICAL STRENGTH
• NICKEL BARRIER TERMINATIONS
• RoHS COMPLIANT
• SAC SOLDER COMPATIBLE*
RoHS
Compliant
includes all homogeneous materials
NMC High CV Series
*See Part Number System for Details
Temperature Coefficient
X7R
X5R
Y5V
Capacitance Range
1.0µF ~ 22µF
1.0µF ~ 100µF
1.0µF ~ 100µF
Capacitance Tolerance
10% (K) & 20% (M)
10% (K) & 20% (M)
+80%/-20% (Z)
Operating Temperature Range
-55°C ~ +125°C
-55°C ~ +85°C
-30°C ~ +85°C
Temperature Characteristics
±15%
∆
Cap.
±15%
∆
Cap.
+22%, -82%
∆
Cap.
Rated Voltages
4Vdc, 6.3Vdc, 16Vdc, 25Vdc, 50Vdc & 100Vdc
Dissipation Factor
See Sizes & Values Tables
insulation Resistance
100Megohm/µF minimum @ +25°C
Dielectric Withstanding Voltage
250% of Rated Voltage for 5 ±1 sec., 50mA max.
150% of Rated Voltage for 5 ±1 sec., 50mA max.
Test Conditions (EIA-198-2E)
1KHz, 0.5V ±0.2Vrms (ALC on)
1KHz, 1.0V ±0.2Vrms (ALC on)
*Reflow soldering is recommended. Contact NIC regarding the use of other soldering methods.
PART NUMBER SYSTEM
NMC 0603 Y5V 105 Z 25 TRP or TRPLP 3K F
RoHS Compliant
Optional Reel Qty (3K = 3,000pcs)
Tape & Reel (Embossed Plastic Carrier)
Tape & Reel (Paper carrier)
Voltage (Vdc)
Capacitance Tolerance Code (see chart)
Capacitance Code, expressed in pF, first 2 digits are
significant, 3rd digit is no. of zeros
Temperature Characteristic (X7R, X5R OR Y5V)
Size Code (see chart)
Series
Typical ESR versus Frequency
Typical Capacitance versus Bias Voltage
®
NIC COMPONENTS CORP.
NMC-HC rev. 002
www.niccomp.com
www.lowESR.com
www.RFpassives.com
www.SMTmagnetics.com
11
Multilayer Ceramic Chip Capacitors
X7R HIGH CV CAPACITOR VALUES AND SIZES (mm)
EIA Case Size
Length (L)
Width (W)
Thickness max. (T)
Termination Width (P)
Capacitance
1.0µF
1.5µF
2.2µF
3.3µF
4.7µF
10µF
22µF
6.3V
0603
1.6 ± 0.15
0.8 ± 0.15
1.0
0.1 ~ 0.65
10
5%
16
5%
6.3
0805
2.0 ± 0.2
1.25 ± 0.2
1.35
0.25 ~ 0.75
Working Voltage (V)
10
16
25
6.3
5%
3.5%
5%
5%*
5%*
NMC High CV Series
1206
3.2±0.2
1.6±0.2
1.90
0.25 ~ 0.85
10
5%
5%
5%
5%
5%
16
5%
5%
5%
5%
3.5%**
25
3.5%
3.5%
3.5%
3.5%
35
50
3%
10%
10%*
10%*
10%*
10%
10%
* 1.45mm maximum thickness, **2.20mm maximum thickness
Percentages in the table represent the dissipation factor for that value.
X7R HIGH CV CAPACITOR VALUES AND SIZES (mm)
EIA Case Size
Length (L)
Width (W)
Thickness max. (T)
Termination Width (P)
Capacitance
1.0µF
1.5µF
2.2µF
3.3µF
4.7µF
10µF
10
5%
16
3.5%
1210
3.2±0.2
2.5±0.2
2.20
0.25 ~ 1.00
25
3.5%
35
50
3.5%
1812
4.5±0.4
3.2±0.3
1.8
0.25 ~ 1.5
Working Voltage (V)
100
10
16
25
50
2.5%**
5%
3.5%
3.5% 2.5%*
2225
5.7±0.4
6.35±0.25
2.20
0.25 ~ 1.02
100
2.5%
25
2.5%
2.5%
2.5%
50
2.5%
100
2.5%
5%
3.5%
3.5%
3.5%
5%
2.5%**
3.5%
5%**
5%** 3.5%**
*2.20mm maximum thickness, **2.80mm maximum thickness
Percentages in the table represent the dissipation factor for that value.
(CONSULT FACTORY
FOR CAPACITANCE
VALUES NOT LISTED)
W
H
P
L
100% Sn over Ni barrier
P
®
12
NIC COMPONENTS CORP.
www.niccomp.com
www.lowESR.com
www.RFpassives.com
www.SMTmagnetics.com
Multilayer Ceramic Chip Capacitors
X5R HIGH CV CAPACITOR VALUES AND SIZES (mm)
EIA Case Size
Length (L)
Width (W)
Thickness max. (T)
Termination Width (P)
Capacitance
1.0µF
1.5µF
2.2µF
3.3µF
4.7µF
6.8µF
10µF
22µF
4
0402
1.0 ± 0.05
0.5 ± 0.05
0.6
0.1 ~ 0.3
6.3
10%
10
15%
4
6.3
10%
10%
10%
10%
10%
10%
0603
1.6 ± 0.15
0.8 ± 0.15
1.0
0.1 ~ 0.65
Working Voltage (Vdc)
10
16
25
10%
5%
5%
10%
NMC High CV Series
0805
2.0 ± 0.2
1.25 ± 0.2
1.45
0.25 ~ 0.75
6.3
10%
10%
10%
10%
10%
15%
10
7.5%
10%
10%
10%
10%
16
5%
5%
5%
5%
25
5%
5%
10%
10%
Percentages in the table represent the dissipation factor for that value.
X5R HIGH CV CAPACITOR VALUES AND SIZES (mm)
EIA Case Size
Length (L)
Width (W)
Thickness max. (T)
Termination Width (P)
Capacitance
1.0µF
1.5µF
2.2µF
3.3µF
4.7µF
6.8µF
10µF
22µF
47µF
100µF
4
6.3
1206
3.2±0.2
1.6±0.2
1.90
0.25 ~ 0.85
10
16
5%
5%
5%
5%
5%
25
1210
3.2±0.2
2.5±0.2
2.2
0.25 ~ 1.0
Working Voltage (Vdc)
6.3
10
16
25
1812
4.5±0.4
3.2±0.3
2.8
0.25 ~ 1.5
35
6.3
10
16
25
10%
10%
10%
10%
10%
10%
10%
10%
7.5%
7.5%
7.5%
10%
10%
3.5%
3.5%
5%
5%
3.5%
10%
5%
3.5%
3.5%*
3.5%
5%
10%
5%
(CONSULT FACTORY
FOR CAPACITANCE
VALUES NOT LISTED)
10%
5%
5%
5%*
10%* 10%*
5%*
10%* 10%*
15%*
*2.8mm maximum thickness
Percentages in the table represent the dissipation factor for that value.
W
H
P
L
100% Sn over Ni barrier
®
P
NIC COMPONENTS CORP.
www.niccomp.com
www.lowESR.com
www.RFpassives.com
www.SMTmagnetics.com
13
Multilayer Ceramic Chip Capacitors
NMC High CV Series
Y5V HIGH CV CAPACITOR VALUES AND SIZES (mm)
EIA Case Size
0402
Length (L)
1.0 ± 0.05
Width (W)
0.5 ± 0.05
Thickness max. (T)
0.6
Termination Width (P) 0.1 ~ 0.3
Capacitance
1.0µF
1.5µF
2.2µF
3.3µF
4.7µF
6.8µF
10µF
22µF
6.3
20%
6.3
0603
1.6 ± 0.15
0.8 ± 0.15
1.0
0.1 ~ 0.65
10
16%
16%
12.5%
16
16%
16%
Working Voltage (Vdc)
25
6.3
9%
16%
16%
16%
16%
16%
20%
20%
10
12.5%
12.5%
12.5%
12.5%
12.5%
16%
30%
0805
2.0 ± 0.2
1.25 ± 0.2
1.45
0.25 ~ 0.75
16
9%
9%
9%
9%
12.5%
25
9%
9%
50
9%
20%
20%
*2.5mm maximum thickness
Percentages in the table represent the dissipation factor for that value.
Y5V HIGH CV CAPACITOR VALUES AND SIZES (mm)
EIA Case Size
Length (L)
Width (W)
Thickness max. (T)
Termination Width (P)
Capacitance
1.0µF
1.5µF
2.2µF
3.3µF
4.7µF
6.8µF
10µF
22µF
33µF
47µF
100µF
10
12.5%
12.5%
12.5%
12.5%
12.5%
16%
20% 16%
20% 16%
6.3
1206
3.2±0.2
1.6±0.2
1.90
0.25 ~ 0.85
16
12.5%
12.5%
12.5%
12.5%
12.5%
12.5%
12.5%
25
7%
9%
9%
9%
9%
9%
35
50
7%
9%
7%
9%
10
12.5%
12.5%
12.5%
12.5%
20% 12.5%
12.5%
16%
20% 16%
6.3
1210
3.2±0.2
2.5±0.2
2.2
0.25 ~ 1.0
16
12.5%
12.5%
12.5%
12.5%
12.5%
12.5%
12.5%
16%
25
9%
9%
9%
9%
9%
9%
9%
35
50
7%
7%
7%
7%
6.3
1812
4.5±0.4
3.2±0.3
2.8
0.25 ~ 1.5
10
12.5%
12.5%
12.5%
12.5%
12.5%
12.5%
12.5%
16
9%
9%
9%
9%
9%
9%
9%
25
5%
5%
5%
5%
5%
5%
5%
5%
50
5%
5%
5%
5%
5%
5%
5%
(CONSULT FACTORY
FOR CAPACITANCE
VALUES NOT LISTED)
20% 16%
20%*
20%
*2.5mm maximum thickness
Percentages in the table represent the dissipation factor for that value.
16%
16%
9%
W
H
P
L
100% Sn over Ni barrier
P
®
