SBL6045CT
Power Schottky Rectifier - 60Amp 45Volt
□
Features
-Plastic package has Underwriters Laboratory Flammability Classifications 94V-0
-High Junction Temperature Capability
-Low forward voltage, high current capability
-High surge capacity
-Low power loss, high efficiency
TO-220AB
L
B
C
D
K
A
E
M
□
Application
-Switching-Mode Power Supply
□
Absolute maximum ratings
Symbol
Ratings
60
45
500
0.44
-50 to +150
-65 to +150
Unit
A
V
A
V
ºC
ºC
Conditions
Average Forward Current
Repetitive Peak Reverse
Voltage
Peak Forward Surge Current
Forward Voltage Drop
Operating Temperature
Storage Temperature
H
A1
F
O
I
J
G
I
F(AV)
V
RRM
I
FSM
V
F(max)
T
j
T
stg
H
N
K
A2
□
Electrical characteristics
Parameters
Maximum Instantaneous
Forward Voltage
Maximum Reverse Leakage
Current
Maximum Voltage Rate of
Change
Typical Thermal Resistance,
Junction to Case
Symbol
Ratings
0.60V
0.44V
1.0mA
Conditions
Tc = 25ºC
Tc = 125ºC
Tc = 25ºC
DIM
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
V
F
I
R
dv/dt
10,000 V/μs
Rated V
R
R
θ
(j-c)
2.2
ºC/W
Per diode
DIMENSIONS
INCHES
MM
MAX
MIN
MAX
MIN
.579
.606
14.70 15.40
.392
.411
9.95
10.45
.104
.116
2.65
2.95
.248
.272
6.30
6.90
.325
.350
8.25
8.90
.126
.157
3.20
4.00
.492
.551
12.50 14.00
.096
.108
2.45
2.75
.028
.039
0.70
1.00
.010
.022
0.25
0.55
.146
.157
3.70
4.00
.167
.187
4.25
4.75
.045
.057
1.15
1.45
.089
.114
2.25
2.90
.047
.055
1.20
1.40
NOTE
Note: Pulse Test : 380μs pulse width, 2% duty cycle
August 2008 / Rev.6.1
http:// www.sirectsemi.com
1
SBL6045CT
PEAK FORWARD SURGE CURRENT
AMPERES
80
500
400
300
200
150
100
0
1
2
5
10
20
50
100
8.3ms Single Half-Sine-Wave
(JEDEC METHOD)
AVERAGE FORWARD CURRENT
AMPERES
60
40
20
RESISTIVE OR
INDUCTIVE LOAD
0
25
50
75
100
125
150
175
CASE TEMPERATURE (ºC)
NUMBER OF CYCLES AT 60Hz
Figure 1. Forward Current Derating Curve
Figure 2. Maximum Non-repetitive Surge Current
100
INSTANTANEOUS REVERSE CURRENT, (mA)
100
INSTANTANEOUS FORWARD CURRENT, (A)
T
J
=150℃
10
10
T
J
=100℃
1.0
T
J
=25℃
1.0
0.1
T
J
=25℃
0.01
0
20
40
60
80
100
120
140
T
J
=25℃
PULSE WIDTH 300us
0.1
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
PERCENT OF RATED PEAK REVERSE VOLTAGE, (%)
INSTANTANEOUS FORWARD VOLTAGE, VOLTS
Figure 3. Typical Reverse Characteristics
10000
Figure 4. Typical Forward Characteristics
CAPACITANCE, (pF)
1000
T
J
=25℃
f =1MHz
100
0.1
1
4
10
100
REVERSE VOLTAGE, VOLTS
Figure 5. Typical Junction Capacitance
