SPECIFICATION FOR APPROVAL
REF : 20080801-A
PROD.
NAME
PAGE: 1
ABC'S DWG NO.
ABC'S ITEM NO.
SH3027□□□□L□-□□□
SHIELDED SMD
POWER INDUCTOR
Ⅰ﹒CONFIGURATION
& DIMENSIONS：
A
Marking
(Black)
A : 3.80
±0.30
B : 3.80
±0.30
C : 2.80
±0.20
D : 1.30 typ.
E : 1.20 typ.
G : 1.10 ref.
H : 4.30 ref.
I : 1.60 ref.
R : 1.40 ref.
H
I
m/m
m/m
m/m
m/m
m/m
m/m
m/m
m/m
m/m
100
C
B
R
D
E
( PCB Pattern Suggestion )
Ⅱ﹒SCHEMATIC
DIAGRAM：
LCR Meter
D
Ⅲ﹒MATERIALS：
a﹒Core：Ferrite DR core
b﹒Core：Ferrite RI core
c﹒Wire
：Enamelled
copper wire ( Class F & H)
d﹒Adhesive
：Epoxy
resin
e﹒Terminal：Ag/Ni/Sn
f﹒Remark：Products comply with RoHS'
requirements
Temperature (
℃
)
a
c
b
d
Peak Temp：260℃ max.
Max time above 230℃
：50sec
max.
Max time above 200℃
：70sec
max.
Temperature
Rising Area
+4.0
℃
/ sec max.
Preheat Area
150 ~ 200
℃
/ 60 ~ 120sec
Reflow Area
+2.0 ~ 4.0
℃
/ sec max.
I
e
Forced Cooling Area
-(1.0 ~ 5.0)
℃
/ sec max.
Peak Temperature:
260
℃
50sec max.
230
℃
250
200
150
70sec max.
Ⅳ﹒GENERAL
SPECIFICATION：
a﹒Temp. rise
：20℃
typ.
b﹒Storage temp.：-40℃ ----+125℃
c﹒Operating temp.：-40℃----+105℃
d﹒Resistance to solder heat：260℃.10 secs.
100
50
0
50
100
150
Time ( seconds )
G
200
250
AR-001A
SPECIFICATION FOR APPROVAL
REF : 20080801-A
PROD.
NAME
PAGE: 2
ABC'S DWG NO.
ABC'S ITEM NO.
SH3027□□□□L□-□□□
SHIELDED SMD
POWER INDUCTOR
Ⅴ﹒
ELECTRICAL CHARACTERISTICS：
DWG No.
SH30274R7YL□ -□□□
SH3027100YL□-□□□
SH3027150YL□ -□□□
SH3027220YL□ -□□□
SH3027330YL□ -□□□
SH3027470YL□ -□□□
SH3027680YL□ -□□□
SH3027101YL□ -□□□
SH3027121YL□ -□□□
SH3027151YL□ -□□□
SH3027221YL□ -□□□
1)﹒
2)﹒"-
Inductance
(
μH
)
4.7
±
30
％
10.0
±
30
％
15.0
±
30
％
22.0
±
30
％
33.0
±
30
％
47.0
±
30
％
68.0
±
30
％
100.0
±
30
％
120.0
±
30
％
150.0
±
30
％
220.0
±
30
％
Q
ref.
5
8
7
6
7
7
6
8
8
10
8
SRF
Test Freq.
( MHz )
( MHz )
typ.
7.96
2.52
2.52
2.52
2.52
2.52
2.52
0.796
0.796
0.796
0.796
50
30
25
22
18
16
11
9
8
7
6
Isat
RDC
( mA )
( mΩ )
typ.
typ.
max.
30
60
88
120
165
225
335
465
600
690
1050
40
78
115
156
215
280
420
580
750
860
1320
750
530
400
320
270
230
190
160
140
125
100
Irms
( mA )
typ.
2000
1600
1300
1100
920
820
660
600
520
480
380
□□□
":Reference code
：Packaging
Information... A
：Bulk
B
：Taping
Reel
3)﹒Inductance Test Freq.：100KHz / 0.1V
4)﹒Isat base on
△L
/ L0A=35% typ.
5)﹒Irms base on Temp. rise 20℃ typ.
@ Inductance VS. DC Currrent Curve
2
10 2
7
5
Inductance（uH）
470
3
2
10 1
7
5
3
2
10 0
7
5
10 1
2
3
5 7 10 2
2
3
5 7 10 3
2
3
5 7 104
220
100
4R7
DC Current (mA)
AR-001A
SPECIFICATION FOR APPROVAL
REF : 20080801-A
PROD.
NAME
PAGE: 3
ABC'S DWG NO.
ABC'S ITEM NO.
SH3027□□□□L□-□□□
SHIELDED SMD
POWER INDUCTOR
Ⅵ﹒PACKAGING
INFORMATION：
( 1 ) Configuration
T
Cover Tape
2.0±0.5
A
B
∮
C
∮
C
N
G
D
Embossed carrier
※
Carrier tape width : D
P:8 m/m
End
4 m/m
Start
100
100
100
100
Leader
no component
200 m/m min.
Components
User direction of feed
Trailer
no component
400 m/m min.
( 2 ) Dimensions
Style
07 - 12
A
178
B
21±0.8
C
13
D
12
G
14
+0
N
50
-0
Unit:m/m
T
16.5
( 3 ) Q'TY & G.W. Per package
Inner : Reel
Series
SH3027
Q'TY (pcs)
G.W. (gw)
Style
Q'TY (pcs)
Outer : Carton
G.W. (Kg)
Size (cm)
500
140
07 - 12
2,0000
8.0
42 x 41 x 24
AR-001A
SPECIFICATION FOR APPROVAL
REF : 20080801-A
PROD.
NAME
PAGE: 4
ABC'S DWG NO.
ABC'S ITEM NO.
SH3027□□□□L□-□□□
SHIELDED SMD
POWER INDUCTOR
Ⅶ﹒DWGING
NUMBER EXPRESSION：
S
H
3
0
2
7
Reference code
Appendix code 2 : Package
Appendix code 1 : Classification
Tolerance code
Electrical code
Dimension code
Type code
Appendix code 1：Product Classification
L：Lead Free Standard products comply with RoHS' requirements
1 ~ 9：Lead Free Special products comply with RoHS' requirements
Appendix code 2：Package Information
Code
A
B
Inner package
T.B.D.
T / R ( Reel package )
Inner package Q'TY
T.B.D.
500
pcs
Remark
AR-001A
SPECIFICATION FOR APPROVAL
REF : 20080801-A
PROD.
NAME
PAGE: 5
ABC'S DWG NO.
ABC'S ITEM NO.
SH3027□□□□L□-□□□
SHIELDED SMD
POWER INDUCTOR
Ⅷ﹒RELIABILITY
TEST：
Test item
Specification
Test condition
Preheat : 155
℃
/ 4 hours.
Solder : Sn96.5 / Ag3 / Cu0.5 or equivalent
Solder temp. : 235±5℃
Flux : Rosin
Dip time : 5±0.5 seconds
Solderability
More than 95% of the
terminal electrode
Shall be covered
With fresh solder.
Thermal shock test
( Temp. cycle )
Electrical oharacteristics shall
not change more
than
±20%
Room temp.
15 minutes
Room temp.
15 minutes
Total : 50 cycles
-40
℃
30 minutes
+105
℃
30 minutes
Humidity test
Temperature : 40±2℃
Humidity : 90±5%
Time : 1000 hours
High temp.
Resistance test
Temperature : 105±5℃
Applied current : Per spec.
Time : 96 hours
AR-001A
