SIHFD420-E3 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> The transistor> SIHFD420-E3

SIHFD420-E3: Description0.37 A, 500 V, 3 ohm, N-CHANNEL, Si, POWER, MOSFET; CategoryDiscrete semiconductor The transistor; File Size1MB，9 Pages; ManufacturerVishay; Websitehttp://www.vishay.com; Environmental Compliance

Download Datasheet Parametric Compare View All

SIHFD420-E3 Overview

0.37 A, 500 V, 3 ohm, N-CHANNEL, Si, POWER, MOSFET

SIHFD420-E3 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Vishay
Parts packaging code	DIP
package instruction	IN-LINE, R-PDIP-T3
Contacts	4
Reach Compliance Code	unknow
ECCN code	EAR99
Avalanche Energy Efficiency Rating (Eas)	51 mJ
Configuration	SINGLE WITH BUILT-IN DIODE
Minimum drain-source breakdown voltage	500 V
Maximum drain current (Abs) (ID)	0.37 A
Maximum drain current (ID)	0.37 A
Maximum drain-source on-resistance	3 Ω
FET technology	METAL-OXIDE SEMICONDUCTOR
JESD-30 code	R-PDIP-T3
JESD-609 code	e3
Humidity sensitivity level	1
Number of components	1
Number of terminals	3
Operating mode	ENHANCEMENT MODE
Maximum operating temperature	150 °C
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	IN-LINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Polarity/channel type	N-CHANNEL
Maximum power dissipation(Abs)	1 W
Maximum pulsed drain current (IDM)	3 A
Certification status	Not Qualified
surface mount	NO
Terminal surface	Matte Tin (Sn)
Terminal form	THROUGH-HOLE
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
transistor applications	SWITCHING
Transistor component materials	SILICON

Preview

Download Datasheet

View All

IRFD420, SiHFD420

Vishay Siliconix

Power MOSFET

PRODUCT SUMMARY

(V)

DS(on)

()

(Max.) (nC)

(nC)

Configuration

= 10 V

3.3

Single

FEATURES

• Dynamic dV/dt Rating

500

3.0

• Repetitive Avalanche Rated

• For Automatic Insertion

• End Stackable

• Fast Switching

• Ease of Paralleling

• Simple Drive Requirements

• Compliant to RoHS Directive 2002/95/EC

Available

RoHS*

COMPLIANT

HVMDIP

DESCRIPTION

N-Channel MOSFET

Third generation Power MOSFETs from Vishay provide the

designer with the best combination of fast switching,

ruggedized device design, low on-resistance and

cost-effectiveness.

The 4 pin DIP package is a low cost machine-insertable

case style which can be stacked in multiple combinations on

standard 0.1 inch pin centers. The dual drain serves as a

thermal link to the mounting surface for power dissipation

levels up to 1 W.

ORDERING INFORMATION

Package

Lead (Pb)-free

SnPb

HVMDIP

IRFD420PbF

SiHFD420-E3

IRFD420

SiHFD420

ABSOLUTE MAXIMUM RATINGS

= 25 °C, unless otherwise noted)

PARAMETER

Drain-Source Voltage

Gate-Source Voltage

Continuous Drain Current

Pulsed Drain Current

Linear Derating Factor

Single Pulse Avalanche

Repetitive Avalanche

Energy

= 25 °C

dV/dt

, T

stg

for 10 s

Repetitive Avalanche Current

Energy

Maximum Power Dissipation

Peak Diode Recovery dV/dt

Operating Junction and Storage Temperature Range

Soldering Recommendations (Peak Temperature)

Notes

a. Repetitive rating; pulse width limited by maximum junction temperature.

b. V

= 50 V, starting T

= 25 °C, L = 40 mH, R

= 25

,

= 1.5 A.

c. I



4.4 A, dI/dt



90 A/μs, V



, T



150 °C.

d. 1.6 mm from case.

at 10 V

= 25 °C

= 100 °C

SYMBOL

LIMIT

500

± 20

0.37

0.23

3.0

0.0083

0.37

0.10

1.0

3.5

- 55 to + 150

300

W/°C

V/ns

°C

UNIT

* Pb containing terminations are not RoHS compliant, exemptions may apply

Document Number: 91135

S10-2463-Rev. C, 08-Nov-10

www.vishay.com
