SMT Power Inductor

SISH85 Type

Features

RoHS compliant.

Low profile (5.2mm max. height) SMD type.

Unshielded.

Self-leads, suitable for high density mounting.

High energy storage and low DCR.

Provided with embossed carrier tape packing.

Idel for power source circuits, DC-DC converter, DC-AC inverters

inductor applications.

In addition to the standard versions shown here, customized inductors

are available to meet your exact requirements.

Mechanical Dimension:

RECOMMENDED PAD PA

TTERNS

3.5

14.0

7.0

UNIT:mm/inch

A = 12.94 / 00.510 Max.

B = 9.4 / 0.370 Max.

C = 5.2 / 0.205 Max.

D = 7.9 0.2 / 0.303 0.008

E = 2.5 0.2 / 0.098 0.008

F = 2.5 0.2 / 0.098 0.008

Electrical Characteristics:

25 C: 100KHz, 0.1V

PART NO.

SISH85 - R33

SISH85 - R68

SISH85 - 1R0

SISH85 - 1R5

SISH85 - 2R2

SISH85 - 2R7

SISH85 - 3R3

SISH85 - 4R7

SISH85 - 6R8

SISH85 - 100

SISH85 - 150

SISH85 - 220

SISH85 - 330

SISH85 - 470

SISH85 - 680

SISH85 - 101

SISH85 - 151

SISH85 - 221

SISH85 - 331

SISH85 - 471

SISH85 - 681

SISH85 - 102

(uH)

0.33

0.68

1.00

1.50

2.20

2.70

3.30

4.70

6.80

10.00

15.00

22.00

33.00

47.00

68.00

100.00

150.00

220.00

330.00

470.00

680.00

1000.00

DCR

(m )MAX

2.0

5.0

6.0

8.0

11.0

12.0

14.0

18.0

27.0

38.0

46.0

85.0

100.0

140.0

200.0

280.0

400.0

610.0

1020.0

1270.0

2020.0

3000.0

Isat

(Adc)

20.0

13.0

11.0

9.0

7.8

7.0

6.4

5.4

4.6

3.8

3.0

2.6

2.0

1.6

1.4

1.2

1.0

0.8

0.6

0.5

0.4

0.3

(Adc)

16.0

12.0

10.0

9.0

7.4

6.6

5.9

4.8

4.4

3.9

3.1

2.7

2.1

1.8

1.5

1.3

1.0

0.8

0.6

0.5

0.4

0.3

0.10

1.00

10.00

100.00

R33

1.00

100.00

1000.00

102

681

471

331

221

151

101

680

470

330

220

150

100

6R8

4R7

3R3

2R7

2R2

1R5

1R0

R68

INDUCTANCE (uH)

10.00

CURRENT (A)

1. Tolerance of inductance: 20%.

2. Isat is the DC current which cause the inductance drop less than 10% of its nominal inductance without current.

3. Ir is the DC current which cause the surface temperature of the part increase less than 45

4. Operating temperature : -20

C to 105

C (including self-temperature rise)

DELTA ELECTRONICS, INC.

(TAOYUAN PLANT CPBG)

252, SAN YING ROAD, KUEISAN INDUSTRIAL ZONE, TAOYUAN SHIEN, 333, TAIWAN, R.O.C.

TEL: 886-3-3591968; FAX: 886-3-3591991

http://www.deltaww.com
