Crystal oscillator
Epson Toyocom
Product Number (please contact us)
CRYSTAL OSCILLATOR
SPXO
Q33710xx0xxxx00
SG - 710
series
•Frequency
range
•Supply
voltage
•Function
•Thickness
:
:
:
:
1.8 MHz to 125 MHz
3.3 V or 5.0 V
Output enable (OE) PTK,PHK
Standby (
ST
) ECK
1.3 mm Typ.
Actual size
Specifications (characteristics)
Item
Output frequency range
Supply voltage
Storage
temperature
Temperature
range
Operating
temperature
Frequency tolerance
Symbol
f
0
V
CC
T_stg
T_use
f_tol
Specifications
SG-710PTK
SG-710PHK
1.8 MHz to 50 MHz
1.8 MHz to 80 MHz
5.0 V
±0.5
V
-55
°C
to +125
°C
SG-710ECK
1.8 MHz to 125 MHz
3.3 V
±0.3
V
Remarks
Store as bare product after unpacking
-10
°C
to +70
°C,
-40
°C
to +85
°C
S:
±25 ×
10
-6
, B:
±50 ×
10
-6
, C:
±100 ×
10
-6
L:
±50 ×
10
-6
, M:
±100 ×
10
-6
13 mA Max.
15 mA Max.
8 mA Max.
24 mA Max.
26 mA Max.
15 mA Max.
-
34 mA Max.
18 mA Max.
-
40 mA Max.
22 mA Max.
-
-
30 mA Max.
6 mA Max.
5 mA Max.
-
12 mA Max.
10 mA Max.
-
-
13 mA Max.
-
-
16 mA Max.
-
-
-
13
μA
Max.
45 % to 55 %
-
45 % to 55 %
2.4 V Min.
0.4 V Max.
10 TTL Max.
15 pF Max.
2.0 V Min.
0.8 V Max.
-
5 ns Max.
45 % to 55 %
40 % to 60 %
40 % to 60 %
V
CC
-0.5 V Min.
0.5 V Max.
10 TTL Max.
50 pF Max.
2.0 V Min.
0.8 V Max.
5 ns Max.
-
10 ms Max.
±5 ×
10
-6
/ year Max.
-
90 % V
CC
Min.
10 % V
CC
Max.
-
15 pF Max.
70 % V
CC
Min.
30 % V
CC
Max.
6 ns Max.
-
-10
°C
to +70
°C
-40
°C
to +85
°C
f
0
≤
25 MHz,No load condition. (ECK:f
0
≤
32 MHz)
f
0
≤
50 MHz, No load condition
f
0
≤
67 MHz, No load condition
f
0
≤
80 MHz, No load condition
f
0
≤
125 MHz, No load condition
f
0
≤
25 MHz, OE=GND (PTK, PHK)
f
0
≤
50 MHz, OE=GND (PTK, PHK)
f
0
≤
67 MHz, OE=GND (PTK, PHK)
f
0
≤
80 MHz, OE=GND (PTK, PHK)
ST
=GND(ECK)
1.8 MHz
≤
f
0
≤
50 MHz,L_CMOS=15 pF(ECK),
50 % V
CC
50 MHz <
f
0
≤
125 MHz,L_CMOS=15 pF(ECK),
50 % V
CC
1.4 V level. L_TTL=10TTL
I
OH
=-16 mA(PTK,PHK),-2 mA(ECK)
I
OL
= 16 mA(PTK,PHK), 2 mA(ECK)
Current consumption
I
CC
Disable current
Stand-by current
I_dis
I_std
Symmetry
SYM
High output voltage
Low output voltage
Output load condition(TTL)
Output load condition(CMOS)
Output enable / disable
input voltage
Rise time / Fall time
Start-up time
Frequency aging
V
OH
V
OL
L_TTL
L_CMOS
V
IH
V
IL
t
r
/
t
f
t
_
str
f_aging
OE terminal (PTK, PHK)
ST
terminal (ECK)
CMOS load: 10 % V
CC
to 90 % V
CC
level
TTL load: 0.4 V to 2.4 V level
Time at minimum supply voltage to be 0 s
+25
°C,
V
CC
=5.0 V / 3.3 V, First year.
External dimensions
(Unit:mm)
Footprint (Recommended)
(Unit:mm)
#4
#3
#3
1.4
#4
4.8
±0.2
2.6
E 66.000
HC531A
#1
1.8
7.3
±0.2
#2
#2
#1
5.08
Pin map
Pin
Connection
1
OE or
ST
2
GND
3
OUT
4
V
CC
ST pin (ECK)
ST pin = HIGH or "open" : Specified frequency output.
ST pin = LOW : Output is high impedance;oscillation stops.
1.3
±0.1
4.2
5.08
Note.
OE pin (PTK, PHK)
OE pin = HIGH or "open" : Specified frequency output.
OE pin = LOW : Output is high impedance.
http://www.epsontoyocom.co.jp
2.0
