DPD-25-00-C3-HT datasheet, PDF

Datasheet> All Categories > The connector> The connector> DPD-25-00-C3-HT

DPD-25-00-C3-HT: DescriptionD Type Connector, 25+25 Contact(s), Female, 0.109 inch Pitch, Solder Terminal, #4-40, Receptacle; CategoryThe connector The connector; File Size131KB，1 Pages; ManufacturerAdam Tech

Download Datasheet Parametric Compare View All

DPD-25-00-C3-HT Overview

D Type Connector, 25+25 Contact(s), Female, 0.109 inch Pitch, Solder Terminal, #4-40, Receptacle

DPD-25-00-C3-HT Parametric

Parameter Name	Attribute value
Reach Compliance Code	compliant
ECCN code	EAR99
Other features	ROHS COMPLIANT
body width	1.119 inch
subject depth	0.768 inch
body length	2.088 inch
Body/casing type	RECEPTACLE
Contact to complete cooperation	AU ON NI
Contact completed and terminated	GOLD OVER NICKEL
Contact point gender	FEMALE
Contact material	PHOSPHOR BRONZE
contact mode	STAGGERED
Contact resistance	20 mΩ
Contact style	RND PIN-SKT
Dielectric withstand voltage	1000VAC V
Insulation resistance	5000000000 Ω
Insulator color	BLACK
Manufacturer's serial number	DPD
Plug contact pitch	0.109 inch
Installation option 1	#4-40
Installation option 2	THREADED
Installation method	RIGHT ANGLE
Installation type	BOARD
PCB row number	2+2
Number of rows loaded	2+2
Maximum operating temperature	125 °C
Minimum operating temperature	-65 °C
PCB contact pattern	STAGGERED
Plating thickness	FLASH inch
Rated current (signal)	5 A
Guideline	UL, CSA
reliability	COMMERCIAL
Shell surface	ZINC
Shell material	STEEL
Terminal length	0.125 inch
Terminal pitch	2.7686 mm
Termination type	SOLDER
Total number of contacts	50

Preview

Download Datasheet

View All

DPD-25-00-C3-HT Related Products

	DPD-25-00-C3-HT	DPD-25-00-A3-HT	DPD-25-00-B3-HT
Description	D Type Connector, 25+25 Contact(s), Female, 0.109 inch Pitch, Solder Terminal, #4-40, Receptacle	D Type Connector, 25+25 Contact(s), Female, 0.109 inch Pitch, Solder Terminal, #4-40, Receptacle	D Type Connector, 25+25 Contact(s), Female, 0.109 inch Pitch, Solder Terminal, #4-40, Receptacle
Reach Compliance Code	compliant	compli	compli
Other features	ROHS COMPLIANT	ROHS COMPLIANT	ROHS COMPLIANT
body width	1.119 inch	1.394 inch	1.244 inch
subject depth	0.768 inch	0.768 inch	0.768 inch
body length	2.088 inch	2.088 inch	2.088 inch
Body/casing type	RECEPTACLE	RECEPTACLE	RECEPTACLE
Contact to complete cooperation	AU ON NI	AU ON NI	AU ON NI
Contact completed and terminated	GOLD OVER NICKEL	GOLD OVER NICKEL	GOLD OVER NICKEL
Contact point gender	FEMALE	FEMALE	FEMALE
Contact material	PHOSPHOR BRONZE	PHOSPHOR BRONZE	PHOSPHOR BRONZE
contact mode	STAGGERED	STAGGERED	STAGGERED
Contact resistance	20 mΩ	20 mΩ	20 mΩ
Contact style	RND PIN-SKT	RND PIN-SKT	RND PIN-SKT
Dielectric withstand voltage	1000VAC V	1000VAC V	1000VAC V
Insulation resistance	5000000000 Ω	5000000000 Ω	5000000000 Ω
Insulator color	BLACK	BLACK	BLACK
Manufacturer's serial number	DPD	DPD	DPD
Plug contact pitch	0.109 inch	0.109 inch	0.109 inch
Installation option 1	#4-40	#4-40	#4-40
Installation option 2	THREADED	THREADED	THREADED
Installation method	RIGHT ANGLE	RIGHT ANGLE	RIGHT ANGLE
Installation type	BOARD	BOARD	BOARD
PCB row number	2+2	2+2	2+2
Number of rows loaded	2+2	2+2	2+2
Maximum operating temperature	125 °C	125 °C	125 °C
Minimum operating temperature	-65 °C	-65 °C	-65 °C
PCB contact pattern	STAGGERED	STAGGERED	STAGGERED
Plating thickness	FLASH inch	FLASH inch	FLASH inch
Rated current (signal)	5 A	5 A	5 A
Guideline	UL, CSA	UL, CSA	UL, CSA
reliability	COMMERCIAL	COMMERCIAL	COMMERCIAL
Shell surface	ZINC	ZINC	ZINC
Shell material	STEEL	STEEL	STEEL
Terminal length	0.125 inch	0.125 inch	0.125 inch
Terminal pitch	2.7686 mm	2.7686 mm	2.7686 mm
Termination type	SOLDER	SOLDER	SOLDER
Total number of contacts	50	50	50
