1N5225 thru 1N5267
Zener Diodes
Zener Voltage Range:
3.0 to 75V
Power Dissipation:
500 mW
DO-204AH (DO-35 Glass)
Features
• Silicon Planar Power Zener Diodes.
• Standard Zener voltage tolerance is ±5% with a “B”
suffix. Other tolerances are available upon request.
• These diodes are also available in Mini-MELF
case with the type designation ZMM5225 ...
ZMM5267, SOT-23 case with the type designation
MMBZ5265 ... MMBZ5267 and SOD-23 case with
the types designation MMSZ5225 ... MMSZ5267
Mechanical Data
Case:
DO-35 Glass Case
Weight:
approx. 0.13 grams
Packaging codes/options:
D7/10K per 13” reel, (52mm tape), 20K/box
D8/10K per Ammo tape (52mm tape), 20K/box
Dimensions in inches and (millimeters)
Maximum Ratings and Thermal Characteristics
(T
Parameter
Zener Current (see Table “Characteristics”)
Power Dissipation at T
amb
= 75°C
Thermal Resistance Junction to Ambient Air
Maximum Junction Temperature
Storage Temperature Range
P
tot
R
ΘJA
T
j
T
S
Symbol
A
= 25°C unless otherwise noted)
Value
500
(1)
300
(1)
175
–65 to +175
Unit
mW
°C/W
°C
°C
Notes:
(1) Valid provided that leads at a distance of 10mm from case are kept at ambient temperature.
6/1/00
1N5225 thru 1N5267
Zener Diodes
Electrical Characteristics
Nominal Zener
Voltage
(3)
at I
ZT
V
Z
(V)
3.0
3.3
3.6
3.9
4.3
4.7
5.1
5.6
6.0
6.2
6.8
7.5
8.2
8.7
9.1
10
11
12
13
14
15
16
17
18
19
20
22
24
25
27
28
30
33
36
39
43
47
51
56
60
62
68
75
(T
J
= 25°C unless otherwise noted)
Maximum V
F
= 1.1V at I
F
= 200mA
Maximum Zener Impedance
Test Current
I
ZT
(mA)
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
9.5
9.0
8.5
7.8
7.4
7.0
6.6
6.2
5.6
5.2
5.0
4.6
4.5
4.2
3.8
3.4
3.2
3.0
2.7
2.5
2.2
2.1
2.0
1.8
1.7
(1)
Type
1N5225
1N5226
1N5227
1N5228
1N5229
1N5230
1N5231
1N5232
1N5233
1N5234
1N5235
1N5236
1N5237
1N5238
1N5239
1N5240
1N5241
1N5242
1N5243
1N5244
1N5245
1N5246
1N5247
1N5248
1N5249
1N5250
1N5251
1N5252
1N5253
1N5254
1N5255
1N5256
1N5257
1N5258
1N5259
1N5260
1N5261
1N5262
1N5263
1N5264
1N5265
1N5266
1N5267
at I
ZK
= 0.25mA
at I
ZT
Z
ZT
(Ω)
Z
ZK
(Ω)
29
28
24
23
22
19
17
11
7
7
5
6
8
8
10
17
22
30
13
15
16
17
19
21
23
25
29
33
35
41
44
49
58
70
80
93
105
125
150
170
185
230
270
1600
1600
1700
1900
2000
1900
1600
1600
1600
1000
750
500
500
600
600
600
600
600
600
600
600
600
600
600
600
600
600
600
600
600
600
600
700
700
800
900
1000
1100
1300
1400
1400
1600
1700
Typical
Temperature
Coefficient
α
VZ
(% / K)
– 0.075
–0.070
–0.065
–0.060
–0.055
±0.030
±0.030
+0.038
+0.038
+0.045
+0.050
+0.058
+0.062
+0.065
+0.068
+0.075
+0.076
+0.077
+0.079
+0.082
+0.082
+0.083
+0.084
+0.085
+0.086
+0.086
+0.087
+0.087
+0.089
+0.090
+0.091
+0.091
+0.092
+0.093
+0.094
+0.095
+0.095
+0.096
+0.096
+0.097
+0.097
+0.097
+0.098
Maximum Reverse
Leakage Current
Test Voltage Maximum Regulator
V
R
(V)
Current
(2)
I
ZM
(mA)
1.0
1.0
1.0
1.0
1.0
2.0
2.0
3.0
3.5
4.0
5.0
6.0
6.5
6.5
7.0
8.0
8.4
9.1
9.9
10
11
12
13
14
14
15
17
18
19
21
21
23
25
27
30
33
36
39
43
46
47
52
56
152
138
126
115
106
97
89
81
76
73
67
61
55
52
50
45
41
38
35
32
30
28
27
25
24
23
21
19.1
18.2
16.8
16.2
15.1
13.8
12.6
11.6
10.6
9.7
8.9
–
–
–
–
–
I
R
(µA)
50
25
15
10
5.0
5.0
5.0
5.0
5.0
5.0
3.0
3.0
3.0
3.0
3.0
3.0
2.0
1.0
0.5
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
Notes:
(1) The Zener impedance is derived from the 1 kHz AC voltage which results when an AC current having an RMS value equal to 10% of the Zener current (I
ZT
or
I
ZK
) is superimposed on I
ZT
or I
ZK
. Zener impedance is measured at two points to insure a sharp knee on the breakdown curve and to eliminate unstable units
(2) Valid provided that leads at a distance of 10 mm from case are kept at ambient temperature
(3) Measured with device junction in thermal equilibrium
