PRECISION THIN FILM CHIP ARRAYS
RESISTORSMCAPACITORSMCOILSMDELAY LINES
56.5-41-5
FEATURES
H
H
H
H
H
RoHS
Exceptional performance & stability!
TC to 5ppm, TC tracking to 2ppm, low noise
Tolerance to 0.1%,matching to 0.02%
4 resistors per array reduces mounting costs
Custom schematics and multiple values available
SPECIFICATIONS
Resi stance Range
Absolute T lerance
o
Matchi ng/ Rati o T lerance
o
Absolute TC
Tracki ng TC
Indi vi dual Power Rati ng
Package Power Rati ng
100
Ω
to 24K
Ω
(extended range avai lable)
±0.1% (std), 0.25%, 0.5%, 1%
Avai lable to 0.02%
+/-5ppm/ deg C (std), 10ppm, 25ppm
Avai lable to 2ppm
62mW
0.25W
1
→
P
←
↓
STF2020
←
L
→
↑
W
↓
T
↑
→
H
←
Config. A (custom circuits avail.)
R C D Type
STF2020
C onfig
A
Wattage per
R esis.Element
62mW
Working
Voltage
80V
L ±.01
[.25]
.197 [5]
W±.008
[.2]
.197 [5]
P±.008
[.2]
.050 [1.27]]
H
Max
.039 [1]
T typ.
.032 [0.8]
POWER DERATING
(derate from full rated power at 70°C to zero
power at 125 °C)
SUGGESTED PAD LAYOUT (mm)
75
50
25
0
-65
25
50
-----------
% OF 70°C RATING
100
4
↑
↓
↑
0.8
100
125
150
175 200
↓
75
70
→
←
→
←
AMBIENT TEMPERATURE (°C)
0.635
0.635
TYPICAL PERFORMANCE CHARACTERISTICS
Operating Temp. Range
Short time Overload (2.5X rated W, 5 sec)
Resistance to Solder Heat (260°C, 10 sec)
Moisture Res. (90-95% RH, 40°C,100 hrs)
Temp. Cycling (-65 to +125°C, 5 cycles)
Load Life (1000 hrs at rated W
25
)
Insulation Resistance
-65°C to +125°C
±0.05%
±0.05%
±0.1%
±0.1%
±0.1%
10,000 Megohm
P/N DESIGNATION:
STF2020 A
RCD Type
Config:
A
Option
(leave blank if standard)
Res.Code
3 sig. figures & multiplier
(1000=100Ω, 1001=1KΩ, 1002 = 10KΩ, etc)
- 1002 - B Q 52 W T
Tolerance Code:
B= 0.1%,C=.25%,D=.5%,F=1%
Ratio Tolerance
: Q=0.02%, A=0.05%, Z=0.1%
(leave blank if not required)
TC
: 25=25ppm, 205=25ppm abs/5ppm track, 10=10ppm, 105=10ppm abs/
5ppm track, 102=10ppm abs/2ppm track, 5=5ppm, 52=5ppm abs/2ppm track
Termination:
W= RoHS (Tin plated Ni)
Packaging:
B = Bulk, T = Tape & Reel
RCD Components Inc.,
520 E. Industrial Park Dr., Manchester, NH, USA 03109
Tel: (603) 669-0054 Fax:(603) 669-5455 E-mail:sales@rcdcomponents.com
www.rcdcomponents.com
FA115
Sale of this product is in accordance with GF-061. Specifications subject to change without notice.
