593D
Vishay Sprague
Solid Tantalum Chip Capacitors
Tantamount
®
Commercial, Surface Mount
for Switch Mode Power Supplies and Converters
FEATURES
•
•
•
•
•
•
Terminations: 100 % Tin, Standard. SnPb
available.
Molded case available in five case codes.
Compatible with "High Volume" automatic pick
and place equipment.
High Ripple Current carrying capability.
Low ESR.
Meets EIA 535BAAE and IEC Specification
QC300801/US0001.
Pb-free
Available
RoHS*
COMPLIANT
PERFORMANCE/ELECTRICAL CHARACTERISTICS
Operating Temperature:
- 55 °C to + 85 °C.
(To + 125 °C with voltage derating.)
Capacitance Range:
0.47 µF to 680 µF.
Capacitance Tolerance:
± 20 %, ± 10 % standard.
Voltage Rating:
4 WVDC to 50 WVDC.
Compliant Terminations
100 % Surge Current Tested (B, C, D & E Case Sizes).
ORDERING INFORMATION
593D
TYPE
107
CAPACITANCE
This is expressed in
picofarads. The first
two digits are the
significant figures.
The third is the
number of zeros to
follow.
X9
CAPACITANCE
TOLERANCE
X0 =
±
20 %
X9 =
±
10 %
X5 =
±
5 %
(Special Order)
010
DC VOLTAGE RATING
AT + 85 °C
This is expressed in volts.
To complete the three-digit
block, zeros precede the
voltage rating. A decimal
point is indicated by an "R"
(6R3 = 6.3 volts).
D
CASE CODE
See Ratings
and Case
Codes Table.
2WE3
TERMINATION AND
PACKAGING
2T: Solderable Coating, 7" (178 mm) reels
2W: Solderable Coating, 13" (330 mm) reel
2TE3: 100 % tin terminations, 7" (178 mm) reel
2WE3: 100% tin terminations, 13" (330mm) reel
8T: 90/10 SnPb Solder Plate terminations,
7" (178 mm) reel
8W: 90/10 SnPb Solder Plate terminations,
13" (330 mm) reel
Note:
Preferred Tolerance and reel sizes are in bold.
We reserve the right to supply higher voltage ratings and tighter capacitance tolerance capacitors in the same case size.
Voltage substitutions will be marked with the higher voltage rating.
DIMENSIONS
in inches [millimeters]
L
TW
H
TH Min.
W
P
CASE CODE
A
B
C
D
E
EIA SIZE
3216-18
3528-21
6032-28
7343-31
7343-43
L
0.126 ± 0.008
[3.2 ± 0.20]
0.138 ± 0.008
[3.5 ± 0.20]
0.236 ± 0.012
[6.0 ± 0.30]
0.287 ± 0.012
[7.3 ± 0.30]
0.287 ± 0.012
[7.3 ± 0.30]
W
0.063 ± 0.008
[1.6 ± 0.20]
0.110 ± 0.008
[2.8 ± 0.20]
0.126 ± 0.012
[3.2 ± 0.30]
0.170 ± 0.012
[4.3 ± 0.30]
0.170 ± 0.012
[4.3 ± 0.30
H
0.063 ± 0.008
[1.6 ± 0.20]
0.075 ± 0.008
[1.9 ± 0.20]
0.098 ± 0.012
[2.5 ± 0.30]
0.110 ± 0.012
[2.8 ± 0.30]
0.158 ± 0.012
[4.0 ± 0.30]
P
0.031 ± 0.012
[0.80 ± 0.30]
0.031 ± 0.012
[0.80 ± 0.30]
0.051 ± 0.012
[1.3 ± 0.30]
0.051 ± 0.012
[1.3 ± 0.30]
0.051 ± 0.012
[1.3 ± 0.30]
T
W
0.047 ± 0.004
[1.2 ± 0.10]
0.087 ± 0.004
[2.2 ± 0.10]
0.087 ± 0.004
[2.2 ± 0.10]
0.095 ± 0.004
[2.4 ± 0.10]
0.095 ± 0.004
[2.4 ± 0.10]
T
H
(Min.)
0.028
[0.70]
0.028
[0.70]
0.039
[1.0]
0.039
[1.0]
0.039
[1.0]
* Pb containing terminations are not RoHS compliant, exemptions may apply
www.vishay.com
1
For technical questions, contact: tantalum@vishay.com
Document Number: 40005
Revision: 18-Aug-05
593D
Solid Tantalum Chip Capacitors
Tantamount® Commercial, Surface Mount
for Switch Mode Power Supplies and Converters
RATINGS AND CASE CODES
µF
0.47
0.68
1.0
1.5
2.2
3.3
4.7
6.8
10
15
22
33
47
68
100
150
220
330
470
680
D
A
A
A/B
A/B
B/C
B/C
B/C
C/D
D
D/E
E
D
E
A
A
A/B
A/B
B/C
B/C
B/C
C/D
C*/D/E
D/E
E
D
D
C
A
A
A
A/B
A/B
B/C
B/C
B*/C
C/D
D/E
D/E
E
D
D
C
C
A
B
A
A
A/B
B
B/C
B/C
C
D
D/E
D*/E
D
D
C
B
A
A
A
B
B
B/C
C
C
D/E
D/E
E
D
C
C
C
C
D
D/E
E
B
A
A
A
A
B
B
D
D
B
C
C
C
C
C
C
D
D/E
E*
4V
Std.
Ext.
6.3 V
Std.
Ext.
10 V
Std.
Ext.
16 V
Std.
Ext.
20 V
Std.
Ext.
25 V
Std.
Ext.
35 V
Std.
Ext.
A
A
A
B
B
C
C
D
D
D
B
B
C
C
E
D/E
E
50 V
Std.
Ext.
Vishay Sprague
*Preliminary values, contact factory for availability.
CONSTRUCTION AND MARKING
CONSTRUCTION
MARKING
Capacitance Code,
pF
Indicates
Lead
(Pb)-free
Voltage
Capacitance
µF
Polarity
Band
Indicates
Lead
(Pb)-free
V 104L
22
XX
10L
2
Vishay
Sprague
Logo
Cathode
Termination (-)
Polarity
Stripe (+)
Epoxy Case
Polarity Band
A Case
Voltage
Code
Data Code
B, C, D, E Case
Tantalum
Capacitor
Element
Anode Weld
Positive
Termination
Volts
4.0
6.3
10
16
20
25
35
50
Code
G
J
A
C
D
E
V
T
Marking:
Capacitor marking includes an anode (+) polarity band, capacitance in
microfarads and the voltage rating of + 85 °C. 'A' Case capacitors use a letter
code for the voltage and EIA capacitance code.
The Sprague
®
trademark will be included if space permits. Capacitors keep
rated at 6.3 V shall be marked 6 V.
A manufacturing date code is marked on all capacitors.
Call the factory for further explanation.
Document Number: 40005
Revision: 18-Aug-05
For technical questions, contact: tantalum@vishay.com
www.vishay.com
2
593D
Vishay Sprague
Solid Tantalum Chip Capacitors
Tantamount® Commercial, Surface Mount
for Switch Mode Power Supplies and Converters
Max. DC
Max. DF
Max. ESR
Leakage
AT + 25 °C
AT + 25 °C
AT + 25 °C
120 Hz
100 kHz
(µA)
(%)
(Ohms)
4 WVDC AT + 85 °C, SURGE = 5.2 V . .2.7 WVDC AT + 125 °C, SURGE = 3.4 V
593D156X_004A2_E3
0.6
6
1.500
593D226X_004A2_E3
0.9
6
1.500
593D336X_004A2_E3
1.3
6
1.500
593D336X_004B2_E3
1.3
6
0.500
593D476X_004A2_E3
1.9
14
0.800
593D476X_004B2_E3
1.9
6
0.500
593D686X_004B2_E3
2.7
6
0.500
593D686X_004C2_E3
2.7
6
0.275
593D107X_004B2_E3
4.0
6
0.450
593D107X_004C2_E3
4.0
6
0.225
593D157X_004B2_E3
6.0
14
0.500
593D157X_004C2_E3
6.0
8
0.250
593D157X_004D2_E3
6.0
8
0.150
593D227X_004C2_E3
8.8
8
0.200
593D227X_004D2_E3
8.8
8
0.150
593D337X_004D2_E3
13.2
8
0.150
593D477X_004D2_E3
18.8
10
0.125
593D477X_004E2_E3
18.8
10
0.100
593D687X_004E2_E3
27.2
12
0.100
6.3 WVDC AT + 85 °C, SURGE = 8 V .. . 4 WVDC AT 125 °C, SURGE = 5 V
593D106X_6R3A2_E3
0.6
6
2.000
593D156X_6R3A2_E3
0.9
6
2.000
593D226X_6R3A2_E3
1.3
6
2.000
593D226X_6R3B2_E3
1.3
6
0.600
593D336X_6R3A2_E3
2.0
14
0.800
593D336X_6R3B2_E3
2.0
6
0.600
593D476X_6R3B2_E3
2.8
6
0.550
593D476X_6R3C2_E3
2.8
6
0.300
593D686X_6R3B2_E3
4.1
6
0.550
593D686X_6R3C2_E3
4.1
6
0.275
593D107X_6R3B2_E3
6.0
15
0.500
593D107X_6R3C2_E3
6.0
6
0.250
593D107X_6R3D2_E3
6.0
6
0.140
593D157X_6R3C2_E3
9.0
8
0.200
593D157X_6R3D2_E3
9.0
8
0.125
593D157X_6R3E2_E3
9.0
8
0.100
593D227X_6R3D2_E3
13.2
8
0.100
593D227X_6R3E2_E3
13.2
8
0.100
593D337X_6R3D2_E3
19.8
8
0.125
593D337X_6R3E2_E3
19.8
8
0.100
593D477X_6R3E2_E3
28.2
10
0.100
10 WVDC AT + 85 °C, SURGE = 13 V .. . 7 WVDC AT 125 °C, SURGE = 8 V
593D475X_010A2_E3
0.5
6
3.000
593D685X_010A2_E3
0.7
6
3.000
593D106X_010A2_E3
1.0
6
2.000
593D156X_010A2_E3
1.5
6
2.000
593D156X_010B2_E3
1.5
6
0.700
593D226X_010A2_E3
2.2
8
1.500
593D226X_010B2_E3
2.2
6
0.700
593D226X_010C2_E3
2.2
6
0.345
593D336X_010B2_E3
3.3
6
0.600
593D336X_010C2_E3
3.3
6
0.300
PART NUMBER
Max. RIPPLE
100 kHz
Irms
(Amps)
0.22
0.22
0.22
0.41
0.31
0.41
0.41
0.63
0.43
0.66
0.41
0.66
1.00
0.74
1.00
1.00
1.10
1.28
1.28
0.19
0.19
0.19
0.38
0.31
0.38
0.39
0.61
0.39
0.63
0.41
0.66
1.04
0.74
1.10
1.28
1.22
1.28
1.10
1.28
1.28
0.16
0.16
0.19
0.19
0.35
0.22
0.35
0.56
0.38
0.61
STANDARD/EXTENDED RATINGS
CAPACITANCE
(µF)
CASE CODE
15
22
33
33
47
47
68
68
100
100
150
150
150
220
220
330
470
470
680
10
15
22
22
33
33
47
47
68
68
100
100
100
150
150
150
220
220
330
330
470
4.7
6.8
10
15
15
22
22
22
33
33
A
A
A
B
A
B
B
C
B
C
B
C
D
C
D
D
D
E
E
A
A
A
B
A
B
B
C
B
C
B
C
D
C
D
E
D
E
D
E
E
A
A
A
A
B
A
B
C
B
C
For 10 % tolerance, specify “9”; for 20 % tolerance, change to “0”.
Extended Ratings in bold print.
www.vishay.com
3
For technical questions, contact: tantalum@vishay.com
Document Number: 40005
Revision: 18-Aug-05
593D
Solid Tantalum Chip Capacitors
Tantamount® Commercial, Surface Mount
for Switch Mode Power Supplies and Converters
STANDARD/EXTENDED RATINGS
CAPACITANCE
(µF)
47
47
47
68
68
100
100
150
150
220
220
330
3.3
4.7
4.7
6.8
10
10
10
15
15
22
22
33
33
33
47
47
68
100
100
150
1.0
2.2
3.3
4.7
4.7
6.8
10
10
15
15
22
22
33
33
47
47
68
68
100
CASE CODE
Max. DC
Max. DF
Max. ESR
Leakage
AT + 25 °C
AT + 25 °C
AT + 25 °C
120 Hz
100 kHz
(µA)
(%)
(Ohms)
10 WVDC AT + 85 °C, SURGE = 13 V .. . 7 WVDC AT 125 °C, SURGE = 8 V
593D476X_010B2_E3
4.7
6
0.600
593D476X_010C2_E3
4.7
6
0.300
593D476X_010D2_E3
4.7
6
0.200
593D686X_010C2_E3
6.8
6
0.275
593D686X_010D2_E3
6.8
6
0.150
593D107X_010C2_E3
10.0
8
0.200
593D107X_010D2_E3
10.0
6
0.080
593D157X_010D2_E3
15.0
8
0.100
593D157X_010E2_E3
15.0
8
0.100
593D227X_010D2_E3
22.0
8
0.125
593D227X_010E2_E3
22.0
8
0.100
593D337X_010E2_E3
33.0
10
0.100
16 WVDC AT + 85 °C, SURGE = 20 V . . .10 WVDC AT + 125 °C, SURGE = 12 V
593D335X_016A2_E3
0.5
6
3.500
593D475X_016A2_E3
0.8
6
2.500
593D475X_016B2_E3
0.8
6
1.500
593D685X_016A2_E3
1.1
6
3.000
593D106X_016A2_E3
1.6
6
1.700
593D106X_016B2_E3
1.6
6
0.800
593D106X_016C2_E3
1.6
6
0.450
593D156X_016B2_E3
2.4
6
0.800
593D156X_016C2_E3
2.4
6
0.400
593D226X_016B2_E3
3.5
6
0.700
593D226X_016C2_E3
3.5
6
0.350
593D336X0016B2_E3
5.3
6
0.700
593D336X_016C2_E3
5.3
6
0.300
593D336X_016D2_E3
4.2
4
0.225
593D476X_016C2_E3
7.5
6
0.300
593D476X_016D2_E3
7.5
6
0.150
593D686X_016D2_E3
10.9
6
0.150
593D107X_016D2_E3
16.0
8
0.125
593D107X_016E2_E3
16.0
8
0.100
593D157X_016E2_E3
24.0
8
0.100
20 WVDC AT + 85 °C, SURGE = 26 V . . . 13 WVDC AT + 125 °C, SURGE = 16 V
593D105X_020A2_E3
0.5
4
5.500
593D225X_020A2_E3
0.5
6
4.000
593D335X_020A2_E3
0.7
6
4.000
593D475X_020A2_E3
0.9
6
3.500
593D475X_020B2_E3
0.9
6
1.000
593D685X_020B2_E3
1.4
6
1.000
593D106X_020B2_E3
2.0
6
1.000
593D106X_020C2_E3
2.0
6
0.450
593D156X_020B2_E3
3.0
6
1.000
593D156X_020C2_E3
3.0
6
0.400
593D226X_020C2_E3
4.4
6
0.375
593D226X_020D2_E3
3.5
4
0.225
593D336X_020C2_E3
6.6
6
0.350
593D336X_020D2_E3
6.6
6
0.200
593D476X_020D2_E3
9.4
6
0.200
593D476X_020E2_E3
7.5
4
0.150
593D686X_020D2_E3
13.6
6
0.175
593D686X_020E2_E3
13.6
6
0.150
593D107X_020E2_E3
20.0
8
0.150
PART NUMBER
Max. RIPPLE
100 kHz
Irms
(Amps)
0.38
0.61
0.87
0.63
1.00
0.74
1.37
1.22
1.28
1.10
1.28
1.28
0.15
0.17
0.24
0.16
0.21
0.33
0.49
0.33
0.52
0.35
0.56
0.35
0.61
0.82
0.61
1.00
1.00
1.10
1.28
1.28
0.12
0.14
0.14
0.15
0.29
0.29
0.29
0.49
0.29
0.52
0.54
0.82
0.56
0.87
0.87
1.05
0.93
1.05
1.05
Vishay Sprague
B
C
D
C
D
C
D
D
E
D
E
E
A
A
B
A
A
B
C
B
C
B
C
B
C
D
C
D
D
D
E
E
A
A
A
A
B
B
B
C
B
C
C
D
C
D
D
E
D
E
E
For 10 % tolerance, specify “9”; for 20 % tolerance, change to “0”.
Extended Ratings in bold print.
Document Number: 40005
Revision: 18-Aug-05
For technical questions, contact: tantalum@vishay.com
www.vishay.com
4
593D
Vishay Sprague
Solid Tantalum Chip Capacitors
Tantamount® Commercial, Surface Mount
for Switch Mode Power Supplies and Converters
STANDARD/EXTENDED RATINGS
CAPACITANCE
(µF)
Max. DC
Max. DF
Max. ESR
Leakage
AT + 25 °C
AT + 25 °C
CASE CODE
PART NUMBER
AT + 25 °C
120 Hz
100 kHz
(µA)
(%)
(Ohms)
25 WVDC @ + 85 °C, SURGE = 32 V . . . 17 WVDC @ + 125 °C, SURGE = 20 V
A
593D105X_025A2_E3
0.5
4
4.000
A
593D155X_025A2_E3
0.5
6
4.000
A
593D225X_025A2_E3
0.5
6
4.000
B
593D225X_025B2_E3
0.6
6
1.500
B
593D335X_025B2_E3
0.8
6
1.500
B
593D475X_025B2_E3
1.2
6
1.500
C
593D475X_025C2_E3
1.2
6
0.525
C
593D685X_025C2_E3
1.7
6
0.500
C
593D106X_025C2_E3
2.5
6
0.450
C
593D156X_025C2_E3
3.8
6
0.425
D
593D156X_025D2_E3
3.8
6
0.250
D
593D226X_025D2_E3
5.5
6
0.200
D
593D336X_025D2_E3
8.3
6
0.200
E
593D336X_025E2_E3
8.3
6
0.200
E
593D476X_025E2_E3
11.8
6
0.200
35 WVDC AT + 85 °C, SURGE = 46 V . . . 23 WVDC AT + 125 °C, SURGE = 28 V
A
593D474X_035A2_E3
0.5
4
4.000
A
593D684X_035A2_E3
0.5
4
4.000
A
593D105X_035A2_E3
0.5
4
4.000
B
593D105X_035B2_E3
0.5
4
2.000
B
593D155X_035B2_E3
0.5
6
2.000
C
593D155X_035C2_E3
0.5
6
0.900
B
593D225X_035B2_E3
0.8
6
2.000
C
593D225X_035C2_E3
0.8
6
0.900
C
593D335X_035C2_E3
1.2
6
0.700
C
593D475X_035C2_E3
1.6
6
0.500
C
593D685X_035C2_E3
2.4
6
0.475
D
593D685X_035D2_E3
2.4
6
0.300
C
593D106X_035C2_E3
3.5
6
0.350
D
593D106X_035D2_E3
3.5
6
0.300
D
593D156X_035D2_E3
5.3
6
0.300
D
593D226X_035D2_E3
7.7
6
0.300
E
593D226X_035E2_E3
7.7
6
0.275
50 WVDC AT + 85 °C, SURGE = 65 V . . . 33 WVDC AT + 125 °C, SURGE = 40 V
B
593D105X_050B2_E3
0.5
4
2.000
C
593D105X_050C2_E3
0.5
4
1.500
B
593D155X_050B2_E3
0.8
6
2.000
C
593D155X_050C2_E3
0.8
6
1.500
C
593D225X_050C2_E3
1.1
6
1.500
D
593D225X_050D2_E3
1.1
6
0.800
C
593D335X_050C2_E3
1.7
6
1.500
D
593D335X_050D2_E3
1.7
6
0.800
D
593D475X_050D2_E3
2.4
6
0.600
E
593D475X_050E2_E3
2.4
6
0.600
D
593D685X_050D2_E3
3.4
6
0.600
E
593D685X_050E2_E3
3.4
6
0.550
E
593D106X_050E2_E3
5.0
6
0.550
Max. RIPPLE
100 kHz
Irms
(Amps)
0.14
0.14
0.14
0.24
0.24
0.24
0.46
0.47
0.49
0.51
0.77
0.87
0.87
0.91
0.91
0.14
0.14
0.14
0.21
0.21
0.35
0.21
0.40
0.45
0.47
0.48
0.71
0.65
0.71
0.71
0.71
0.77
0.21
0.27
0.21
0.27
0.27
0.43
0.27
0.43
0.50
0.50
0.50
0.55
0.55
1.0
1.5
2.2
2.2
3.3
4.7
4.7
6.8
10
15
15
22
33
33
47
0.47
0.68
1.0
1.0
1.5
1.5
2.2
2.2
3.3
4.7
6.8
6.8
10
10
15
22
22
1.0
1.0
1.5
1.5
2.2
2.2
3.3
3.3
4.7
4.7
6.8
6.8
10
For 10 % tolerance, specify “9”; for 20 % tolerance, change to “0”.
Extended Ratings in bold print.
www.vishay.com
5
For technical questions, contact: tantalum@vishay.com
Document Number: 40005
Revision: 18-Aug-05
京公网安备 11010802033920号
EEWORLD
