STM8S105S6B3C: Description8-BIT, FLASH, 16 MHz, MICROCONTROLLER, PQFP48; Categorysemiconductor The embedded processor and controller; File Size2MB，121 Pages; ManufacturerSTMicroelectronics; Websitehttp://www.st.com/

Download Datasheet Parametric View All

STM8S105S6B3C Overview

8-BIT, FLASH, 16 MHz, MICROCONTROLLER, PQFP48

STM8S105S6B3C Parametric

Parameter Name	Attribute value
External data bus width	0.0
Number of input and output buses	38
Number of terminals	48
Minimum operating temperature	-40 Cel
Maximum operating temperature	125 Cel
Line speed	16 MHz
Processing package description	7 X 7 MM, ROHS COMPLIANT, LQFP-48
each_compli	Yes
EU RoHS regulations	Yes
state	Active
microprocessor_microcontroller_peripheral_ic_type	MICROCONTROLLER
ADC channel	YES
Address bus width	0.0
Number of digits	8
clock_frequency_max	16 MHz
DAC channel	NO
DMA channel	NO
jesd_30_code	S-PQFP-G48
jesd_609_code	e4
moisture_sensitivity_level	3
Packaging Materials	PLASTIC/EPOXY
ckage_code	LFQFP
ckage_equivalence_code	QFP48,.35SQ,20
packaging shape	SQUARE
Package Size	FLATPACK, LOW PROFILE, FINE PITCH
eak_reflow_temperature__cel_	260
wer_supplies	3.3/5
PWM channel	YES
qualification_status	COMMERCIAL
m__bytes_	2048
ROM programming	FLASH
m__words_	16384
seated_height_max	1.6 mm
sub_category	Microcontrollers
Rated supply voltage	3.3 V
Minimum supply voltage	2.95 V
Maximum supply voltage	5.5 V
surface mount	YES
Temperature level	AUTOMOTIVE
terminal coating	NICKEL PALLADIUM GOLD
Terminal form	GULL WING
Terminal spacing	0.5000 mm
Terminal location	QUAD
ime_peak_reflow_temperature_max__s_	NOT SPECIFIED
length	7 mm
width	7 mm

Preview

Download Datasheet

View All

STM8S105C4/6 STM8S105K4/6

STM8S105S4/6

Access line, 16 MHz STM8S 8-bit MCU, up to 32 Kbyte Flash,

integrated EEPROM, 10-bit ADC, timers, UART, SPI, I²C

Datasheet

production data

Features

Core



16 MHz advanced STM8 core with Harvard

architecture and 3-stage pipeline



Extended instruction set

LQFP48 (7x7 mm)

LQFP44 (10x10 mm)

LQFP32 (7x7 mm)

Memories



Program memory: up to 32 Kbyte Flash; data

retention 20 years at 55 °C after 10 kcycle



Data memory: up to 1 Kbyte true data

EEPROM; endurance 300 kcycle



RAM: up to 2 Kbyte

UFQFPN32 (5x5 mm)

SDIP32 400ml



2x16-bit general purpose timer, with 2+3

CAPCOM channels (IC, OC or PWM)



8-bit basic timer with 8-bit prescaler



Auto wake-up timer



Window watchdog and independent watchdog

timers

Clock, reset and supply management



2.95 to 5.5 V operating voltage



Flexible clock control, 4 master clock sources

– Low power crystal resonator oscillator

– External clock input

– Internal, user-trimmable 16 MHz RC

– Internal low-power 128 kHz RC



Clock security system with clock monitor



Power management:

– Low-power modes (wait, active-halt, halt)

– Switch-off peripheral clocks individually



Permanently active, low-consumption power-

on and power-down reset

Communication interfaces



UART with clock output for synchronous

operation, SmartCard, IrDA, LIN master mode



SPI interface up to 8 Mbit/s



I2C interface up to 400 kbit/s

Analog to digital converter (ADC)



10-bit, ±1 LSB ADC with up to 10 multiplexed

channels, scan mode and analog watchdog

Interrupt management



Nested interrupt controller with 32 interrupts



Up to 37 external interrupts on 6 vectors

I/Os



Up to 38 I/Os on a 48-pin package including



16 high sink outputs



Highly robust I/O design, immune against

current injection

Timers



Advanced control timer: 16-bit, 4 CAPCOM

channels, 3 complementary outputs, dead-time

insertion and flexible synchronization

Unique ID



96-bit unique key for each device

September 2015

This is information on a product in full production.

DocID14771 Rev 15

1/121

www.st.com

Contents

STM8S105x4/6

Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Block diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Product overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

4.1

4.2

4.3

4.4

4.5

4.6

4.7

4.8

4.9

4.10

4.11

4.12

4.13

4.14

Central processing unit STM8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Single wire interface module (SWIM) and debug module (DM) . . . . . . . . 14

Interrupt controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Flash program and data EEPROM memory . . . . . . . . . . . . . . . . . . . . . . . 14

Clock controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Power management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Watchdog timers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Auto wakeup counter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Beeper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

TIM1 - 16-bit advanced control timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

TIM2, TIM3 - 16-bit general purpose timers . . . . . . . . . . . . . . . . . . . . . . . 18

TIM4 - 8-bit basic timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Analog-to-digital converter (ADC1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Communication interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

4.14.1

4.14.2

4.14.3

UART2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

SPI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Pinout and pin description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

5.1

Alternate function remapping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Memory and register map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

6.1

6.2

Memory map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

6.2.1

6.2.2

I/O port hardware register map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

General hardware register map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
