SUD15N15-95
Vishay Siliconix
N-Channel 150-V (D-S) 175_C MOSFET
PRODUCT SUMMARY
V
DS
(V)
150
FEATURES
I
D
(A)
15
15
r
DS(on)
(W)
0.095 @ V
GS
= 10 V
0.100 @ V
GS
= 6 V
D
TrenchFETr Power MOSFETS
D
175_C Junction Temperature
D
100% R
g
Tested
APPLICATIONS
D
Primary Side Switch
D
TO-252
Drain Connected to Tab
G
D
S
G
Top View
Ordering Information: SUD15N15-95
S
N-Channel MOSFET
ABSOLUTE MAXIMUM RATINGS (T
C
= 25_C UNLESS OTHERWISE NOTED)
Parameter
Drain-Source Voltage
Gate-Source Voltage
Continuous Drain Current (T
J
= 175_C)
b
Pulsed Drain Current
Continuous Source Current (Diode Conduction)
Avalanche Current
Repetitive Avalanche Energy (Duty Cycle
v
1%)
Maximum Power Dissipation
Operating Junction and Storage Temperature Range
L = 0.1 mH
T
C
= 25_C
T
A
= 25_C
T
C
= 25_C
T
C
= 125_C
Symbol
V
DS
V
GS
I
D
I
DM
I
S
I
AR
E
AR
P
D
T
J
, T
stg
Limit
150
"20
15
8.7
25
15
15
11.3
62
b
2.7a
- 55 to 175
Unit
V
A
mJ
W
_C
THERMAL RESISTANCE RATINGS
Parameter
Junction-to-Ambient
a
J
ti t A bi t
Junction-to-Case
Notes
a. Surface Mounted on 1” x1” FR4 Board.
b. See SOA curve for voltage derating.
Document Number: 71641
S-31724—Rev. B, 18-Aug-03
www.vishay.com
t
v
10 sec
Steady State
Symbol
R
thJA
R
thJC
Typical
16
45
2
Maximum
20
55
2.4
Unit
_C/W
C/W
1
SUD15N15-95
Vishay Siliconix
SPECIFICATIONS (T
J
= 25_C UNLESS OTHERWISE NOTED)
Parameter
Static
Drain-Source Breakdown Voltage
Gate Threshold Voltage
Gate-Body Leakage
V
(BR)DSS
V
GS(th)
I
GSS
V
GS
= 0 V, I
D
= 250
mA
V
DS
= V
GS
, I
D
= 250
mA
V
DS
= 0 V, V
GS
=
"20
V
V
DS
= 120 V, V
GS
= 0 V
Zero Gate Voltage Drain Current
g
On-State Drain Current
b
I
DSS
I
D(on)
V
DS
= 120 V, V
GS
= 0 V, T
J
= 125_C
V
DS
= 120 V, V
GS
= 0 V, T
J
= 175_C
V
DS
= 5 V, V
GS
= 10 V
V
GS
= 10 V, I
D
= 15 A
Drain-Source On-State
Drain Source On State Resistance
b
r
DS( )
DS(on)
V
GS
= 10 V, I
D
= 15 A, T
J
= 125_C
V
GS
= 10 V, I
D
= 15 A, T
J
= 175_C
V
GS
= 6 V, I
D
= 10 A
Forward Transconductance
b
g
fs
V
DS
= 15 V, I
D
= 15 A
0.081
25
25
0.077
0.095
0.190
0.250
0.100
S
W
150
2
"100
1
50
250
A
m
mA
V
nA
Symbol
Test Condition
Min
Typ
a
Max
Unit
Dynamic
a
Input Capacitance
Output Capacitance
Reverse Transfer Capacitance
Total Gate Charge
c
Gate-Source Charge
c
Gate-Drain Charge
c
Gate Resistance
Turn-On Delay Time
c
Rise Time
c
Turn-Off Delay Time
c
Fall Time
c
C
iss
C
oss
C
rss
Q
g
Q
gs
Q
gd
R
g
t
d(on)
t
r
t
d(off)
t
f
V
DD
= 75 V, R
L
= 5
W
I
D
^
15 A, V
GEN
= 10 V, R
G
= 2.5
W
1
8
35
17
30
V
DS
= 75 V, V
GS
= 10 V, I
D
= 15 A
,
,
V
GS
= 0 V, V
DS
= 25 V, f = 1 MHz
900
115
70
20
5.5
7
3.2
12
55
25
45
ns
W
25
nC
pF
Source-Drain Diode Ratings and Characteristic (T
C
= 25_C)
Pulsed Current
Diode Forward Voltage
b
Source-Drain Reverse Recovery Time
I
SM
V
SD
t
rr
I
F
= 15 A, V
GS
= 0 V
I
F
= 15 A, di/dt = 100 A/ms
0.9
55
25
1.5
85
A
V
ns
Notes
a. Guaranteed by design, not subject to production testing.
b. Pulse test; pulse width
v
300
ms,
duty cycle
v
2%.
c. Independent of operating temperature.
www.vishay.com
2
Document Number: 71641
S-31724—Rev. B, 18-Aug-03
SUD15N15-95
Vishay Siliconix
TYPICAL CHARACTERISTICS (25_C UNLESS NOTED)
Output Characteristics
25
V
GS
= 10 thru 6 V
25
Transfer Characteristics
20
I D - Drain Current (A)
20
I D - Drain Current (A)
15
5V
10
15
10
T
C
= 125_C
5
25_C
- 55_C
0
5
3V
0
0
2
4
6
8
10
V
DS
- Drain-to-Source Voltage (V)
4V
0
1
2
3
4
5
6
V
GS
- Gate-to-Source Voltage (V)
Transconductance
40
T
C
= - 55_C
0.12
r DS(on)- On-Resistance (
W
)
32
g fs - Transconductance (S)
25_C
0.10
0.14
On-Resistance vs. Drain Current
24
V
GS
= 6 V
0.08
0.06
0.04
0.02
0.00
V
GS
= 10 V
125_C
16
8
0
0
5
10
15
20
25
0
5
10
15
20
25
I
D
- Drain Current (A)
1500
I
D
- Drain Current (A)
20
V
DS
= 75 V
I
D
= 15 A
Capacitance
Gate Charge
1200
C - Capacitance (pF)
C
iss
V GS - Gate-to-Source Voltage (V)
16
900
12
600
8
300
C
rss
4
C
oss
0
0
20
40
60
80
100
V
DS
- Drain-to-Source Voltage (V)
0
0
8
16
24
32
40
Q
g
- Total Gate Charge (nC)
Document Number: 71641
S-31724—Rev. B, 18-Aug-03
www.vishay.com
3
SUD15N15-95
Vishay Siliconix
TYPICAL CHARACTERISTICS (25_C UNLESS NOTED)
On-Resistance vs. Junction Temperature
2.8
2.4
r DS(on)- On-Resistance (
W
)
(Normalized)
2.0
1.6
1.2
0.8
0.4
0.0
- 50
1
0
0.3
0.6
0.9
1.2
V
SD
- Source-to-Drain Voltage (V)
V
GS
= 10 V
I
D
= 15 A
I S - Source Current (A)
100
Source-Drain Diode Forward Voltage
T
J
= 150_C
10
T
J
= 25_C
- 25
0
25
50
75
100
125
150
175
T
J
- Junction Temperature (_C)
THERMAL RATINGS
Maximum Avalanche Drain Current
vs. Case Temperature
20
100
Safe Operating Area
15
I D - Drain Current (A)
I D - Drain Current (A)
10
Limited by r
DS(on)
10
ms
100
ms
10
1
T
C
= 25_C
Single Pulse
1 ms
10 ms
100 ms
1 s, dc
5
0
0
25
50
75
100
125
150
175
T
C
- Case Temperature (_C)
0.1
0.1
1
10
100
1000
V
DS
- Drain-to-Source Voltage (V)
2
1
Normalized Effective Transient
Thermal Impedance
Duty Cycle = 0.5
0.2
0.1
0.1
0.02
0.05
Single Pulse
Normalized Thermal Transient Impedance, Junction-to-Case
0.01
10
-4
10
-3
10
-2
10
-1
1
10
Square Wave Pulse Duration (sec)
www.vishay.com
Document Number: 71641
S-31724—Rev. B, 18-Aug-03
4
