T95
Vishay Sprague
Solid Tantalum Chip Capacitors
T
ANTAMOUNT
®
Hi-Rel COTS, Conformal Coated Case
FEATURES
•
High reliability; Weibull grading available
•
Surge Current Testing per MIL-PRF-55365
options available
•
Standard and Low ESR options
•
Terminations: SnPb, Standard. 100 % Tin
available
Pb-free
Available
RoHS*
COMPLIANT
PERFORMANCE/ELECTRICAL CHARACTERISTICS
Operating Temperature:
- 55 °C to + 85 °C
(To + 125 °C with voltage derating)
Capacitance Range:
0.1 µF to 680 µF
Capacitance Tolerance:
± 20 %, ± 10 % standard
Voltage Rating:
4 WVDC to 50 WVDC
ORDERING INFORMATION
T95
D
TYPE CASE
CODE
See
Ratings
and
Case
Codes
Table.
107
CAPACITANCE
This is expressed
in picofarads. The
first two digits are
the significant
figures. The third is
the number of
zeros to follow.
K
CAPACITANCE
TOLERANCE
K = ± 10 %
M = ± 20 %
010
DC VOLTAGE
RATING AT + 85 °C
This is expressed in
volts. To complete the
three-digit block, zeros
precede the voltage
rating. A decimal point
is indicated by an “R”
(6R3 = 6.3 V).
E
TERMINATION AND
PACKAGING
E: Sn/Pb Solder/7"
(178 mm) reels
L: Sn/Pb Solder/7"
(178 mm) ½ reel
C: 100 % Tin/7"
(178 mm) reels
H: 100 % Tin/7"
(178 mm) ½ reel
A
RELIABILITY
LEVEL
A = 1.0 %
Weibull
B = 0.1 %
Weibull
(2)
S = Hi-Rel
Standard
Burn-in
Z = Non-
Established
Reliability
A
SURGE CURRENT
A = 10 cycles at
+ 25 °C
B = 10 cycles at
- 55 °C/+ 85 °C
S = 3 cycles at
+ 25 °C
S
ESR
S = Std
L = Low
Note:
(2) Weibull 0.1 % may not be available on all ratings. See detailed notes in ratings table or contact marketing for availability
DIMENSIONS
in inches [millimeters]
Tantalum Wire
Nib Identifies
Anode (+)
Terminal
J
MAX.
H
W
L
MAX.
D
REF.
A
B
J
MAX.
L (MAX.)
W
H
A
0.158
0.110 + 0.012 - 0.016 0.075 + 0.012 - 0.024
0.031 ± 0.012
B
[4.0]
[2.8 + 0.3 - 0.4]
[1.9 + 0.3 - 0.6]
[0.80 ± 0.30]
0.281
0.126 ± 0.012
0.098 ± 0.012
0.051 ± 0.012
C
[7.1]
[3.2 ± 0.3]
[2.5 ± 0.3]
[1.3 ± 0.30]
0.293
0.170 ± 0.012
0.110 ± 0.012
0.051 ± 0.012
D
[7.5]
[4.3 ± 0.3]
[2.8 ± 0.3]
[1.3 ± 0.30]
0.283
0.235 + 0.012/- 0.024
0.136 ± 0.012
0.051 ± 0.012
R
[7.2]
[6.0 + 0.3/- 0.6]
[3.5 ± 0.3]
[1.3 ± 0.30]
0.143
0.072 ± 0.008
0.048 ± 0.008
0.023 ± 0.010
S
[3.63]
[1.83 ± 0.2]
[1.22 ± 0.2]
[0.58 ± 0.25]
0.143
0.104 ± 0.010
0.051 ± 0.010
0.023 ± 0.010
V
[3.63]
[2.65 ± 0.25]
[1.3 ± 0.25]
[0.58 ± 0.25]
0.285
0.104 ± 0.010
0.051 ± 0.010
0.040 ± 0.020
X
[7.24]
[2.65 ± 0.25]
[1.3 ± 0.25]
[1.0 ± 0.5]
0.285
0.104 ± 0.010
0.069 ± 0.010
0.040 ± 0.020
Y
[7.24]
[2.65 ± 0.25]
[1.75 ± 0.25]
[1.0 ± 0.5]
0.285
0.104 ± 0.010
0.104 ± 0.010
0.040 ± 0.020
Z
[7.24]
[2.65 ± 0.25]
[2.65 ± 0.25]
[1.0 ± 0.5]
Note:
The anode termination (D less B) will be a minimum of 0.010" (0.25 mm)
* Pb containing terminations are not RoHS compliant, exemptions may apply
Document Number: 40081
Revision: 23-Jan-08
CASE
CODE
B
0.097 ± 0.016
[2.5 ± 0.4]
0.180 ± 0.024
[4.6 ± 0.6]
0.180 ± 0.024
[4.6 ± 0.6]
0.180 ± 0.024
[4.6 ± 0.6]
0.085 ± 0.015
[2.16 ± 0.37]
0.085 ± 0.015
[2.16 ± 0.37]
0.200 ± 0.027
[5.08 ± 0.69]
0.200 ± 0.027
[5.08 ± 0.69]
0.200 ± 0.027
[5.08 ± 0.69]
D (REF.)
0.138
[3.5]
0.236
[6.0]
0.253
[6.4]
0.243
[6.2]
0.115
[2.9]
0.115
[2.9]
0.243
[6.2]
0.243
[6.2]
0.243
[6.2]
J (MAX.)
0.004
[0.1]
0.004
[0.1]
0.004
[0.1]
0.004
[0.1]
0.004
[0.1]
0.004
[0.1]
0.004
[0.1]
0.004
[0.1]
0.004
[0.1]
For technical questions, contact: tantalum@vishay.com
www.vishay.com
149
T95
Vishay Sprague
Solid Tantalum Chip Capacitors
T
ANTAMOUNT
®
Hi-Rel COTS, Conformal Coated Case
RATINGS AND CASE CODES
µF
0.10
0.15
0.22
0.33
0.47
0.68
1.0
1.5
2.2
3.3
4.7
6.8
10
15
22
33
47
68
100
120
150
180
220
270
330
390
470
680
D
R
R
D
R
R
R
R
R
R
D/R
S
S
V
X
X
Y
Y
Z
Z
R
R
D/R
D
R
R
Y
S
S
V
X
X
S
S
V
X
X
Y
Z
Z
R
C/D
R
R
R
S
S
V
A/X
X
B/Y
Z
Z
R
R
R
S
S
V
X
X
Y
Z
Z
D/R
S
S
S
V
X
X
Y
C/Y
Z
4V
6.3 V
10 V
16 V
20 V
25 V
35 V
S
S
S
S
S
S
S
V
X
Y
Z
Z
Z
D/R
R
R
C
D
R
R
R
50 V
www.vishay.com
150
For technical questions, contact: tantalum@vishay.com
Document Number: 40081
Revision: 23-Jan-08
T95
Solid Tantalum Chip Capacitors
Vishay Sprague
®
Hi-Rel COTS, Conformal Coated Case
T
ANTAMOUNT
STANDARD/EXTENDED RATINGS
CAPACITANCE
(µF)
CASE CODE
PART NUMBER
MAX. DC
LEAKAGE
AT + 25 °C
(µA)
MAX. DF
AT + 25 °C
120 Hz
(%)
STD.(S)
MAX. ESR
AT + 25 °C
100 kHz (Ω)
LOW (L)
MAX. ESR
AT + 25 °C
100 kHz
(Ω)
2.000
2.000
1.500
1.000
1.000
0.600
0.600
0.400
0.060
0.080
2.000
2.000
1.500
1.000
1.000
0.600
0.400
0.080
0.080
0.045
0.060
0.045
2.500
2.000
2.000
1.500
1.000
0.600
0.400
0.400
0.075
0.070
0.075
0.065
0.065
0.055
0.055
N/A
6.8
10
15
22
33
47
68
100
270
330
4.7
6.8
10
15
22
47
100
180
220
390
470
680
3.3
4.7
6.8
10
15
22
33
47
100
120
150
150
220
220
330
680
S
S
V
X
X
Y
Y
Z
D
R
S
S
V
X
X
Y
Z
R
R
R
D
R
S
S
V
X
X
Y
Z
Z
R
R
D
R
D
R
R
R
4 WVDC AT + 85 °C, SURGE = 5.2 V . . . 2.7 WVDC AT + 125 °C, SURGE = 3.4 V
T95S685(1)004(2)(3)(4)L
0.5
6
N/A
T95S106(1)004(2)(3)(4)L
0.5
6
N/A
T95V156(1)004(2)(3)(4)L
0.6
6
N/A
T95X226(1)004(2)(3)(4)L
0.9
6
N/A
T95X336(1)004(2)(3)(4)L
1.3
6
N/A
T95Y476(1)004(2)(3)(4)L
1.9
6
N/A
T95Y686(1)004(2)(3)(4)L
2.7
6
N/A
T95Z107(1)004(2)(3)(4)L
4.0
6
N/A
T95D277(1)004(2)(3)(4)(5)
10.8
8
0.130
T95R337(1)004(2)(3)(4)(5)
13.2
8
0.130
6.3 WVDC AT + 85 °C, SURGE = 8 V . . . 4 WVDC AT 125 °C, SURGE = 5 V
T95S475(1)6R3(2)(3)(4)L
0.5
6
N/A
T95S685(1)6R3(2)(3)(4)L
0.5
6
N/A
T95V106(1)6R3(2)(3)(4)L
0.6
6
N/A
T95X156(1)6R3(2)(3)(4)L
0.9
6
N/A
T95X226(1)6R3(2)(3)(4)L
1.4
6
N/A
T95Y476(1)6R3(2)(3)(4)L
2.8
6
N/A
T95Z107(1)6R3(2)(3)(4)L
6.0
6
N/A
T95R187(1)6R3(2)(3)(4)(5)
10.8
8
0.130
T95R227(1)6R3(2)(3)(4)(5)
13.2
8
0.130
T95R397(1)6R3(2)(3)(4)(5)
23.4
8
0.130
T95D477(1)6R3(2)(3)(4)(5)
28.2
10
0.130
T95R687(1)6R3(2)(3)(4)(5)
40.8
12
0.090
10 WVDC AT + 85 °C, SURGE = 13 V . . . 7 WVDC AT 125 °C, SURGE = 8 V
T95S335(1)010(2)(3)(4)L
0.5
6
N/A
T95S475(1)010(2)(3)(4)L
0.5
6
N/A
T95V685(1)010(2)(3)(4)L
0.7
6
N/A
T95X106(1)010(2)(3)(4)L
1.0
6
N/A
T95X156(1)010(2)(3)(4)L
1.5
6
N/A
T95Y226(1)010(2)(3)(4)L
2.2
6
N/A
T95Z336(1)010(2)(3)(4)L
3.3
6
N/A
T95Z476(1)010(2)(3)(4)L
4.7
6
N/A
T95R107(1)010(2)(3)(4)(5)
10.0
8
0.140
T95R127(1)010(2)(3)(4)(5)
12.0
8
0.140
T95D157(1)010(2)(3)(4)(5)
15.0
8
0.140
T95R157(1)010(2)(3)(4)(5)
15.0
8
0.130
T95D227(1)010(2)(3)(4)(5)
22.0
8
0.140
T95R227(1)010(2)(3)(4)(5)
22.0
8
0.130
T95R337(1)010(2)(3)(4)(5)
33.0
8
0.130
T95R687(1)010(2)(3)(4)S
68.0
14
0.090
Notes:
(1) Capacitance Tolerance: K, M
(2) Termination and Packaging: C, E, H, L
(3) Reliability Level: A, S, Z
(4) Surge Current: A, B, S
(5) ESR: L, S
(6) Reliability Level: A, B, S, Z
Document Number: 40081
Revision: 23-Jan-08
For technical questions, contact: tantalum@vishay.com
www.vishay.com
151
T95
Vishay Sprague
Solid Tantalum Chip Capacitors
T
ANTAMOUNT
®
Hi-Rel COTS, Conformal Coated Case
STANDARD/EXTENDED RATINGS
CAPACITANCE
(µF)
CASE CODE
PART NUMBER
MAX. DC
LEAKAGE
AT + 25 °C
(µA)
MAX. DF
AT + 25 °C
120 Hz
(%)
STD.(S)
MAX. ESR
AT + 25 °C
100 kHz (Ω)
LOW (L)
MAX. ESR
AT + 25 °C
100 kHz
(Ω)
3.500
2.500
2.000
1.500
1.330
1.500
0.550
0.600
0.400
0.400
0.095
0.090
0.080
0.085
0.055
0.055
0.055
3.500
3.500
3.000
1.500
1.500
1.000
0.600
0.400
0.095
0.110
N/A
0.080
0.075
5.000
3.500
3.500
2.000
1.500
1.500
1.000
0.280
1.000
0.600
0.130
0.130
0.150
0.095
0.090
2.2
3.3
4.7
6.8
6.8
10
15
15
22
33
68
100
100
150
180
220
330
1.5
2.2
3.3
4.7
6.8
10
15
22
47
47
100
120
150
0.68
1
1.5
2.2
3.3
4.7
6.8
10
10
15
33
33
68
68
100
S
S
V
X
A
X
B
Y
Z
Z
R
C
D
D
R
R
R
S
S
V
X
X
Y
Z
Z
D
R
R
R
R
S
S
S
V
X
X
Y
C
Y
Z
D
R
D
R
R
16 WVDC AT + 85 °C, SURGE = 20 V . . . 10 WVDC AT + 125 °C, SURGE = 12 V
T95S225(1)016(2)(3)(4)L
0.5
6
N/A
T95S335(1)016(2)(3)(4)L
0.5
6
N/A
T95V475(1)016(2)(3)(4)L
0.8
6
N/A
T95X685(1)016(2)(3)(4)L
1.1
6
N/A
T95A685(1)016(2)(6)(4)(5)
1.1
6
2.800
T95X106(1)016(2)(3)(4)L
1.6
6
N/A
T95B156(1)016(2)(3)(4)(5)
2.4
6
0.750
T95Y156(1)016(2)(3)(4)L
2.4
6
N/A
T95Z226(1)016(2)(3)(4)L
3.5
6
N/A
T95Z336(1)016(2)(3)(4)L
5.3
6
N/A
T95R686(1)016(2)(3)(4)(5)
10.9
6
0.600
T95C107(1)016(2)(3)(4)(5)
16.0
8
0.600
T95D107(1)016(2)(6)(4)(5)
16.0
8
0.140
T95D157(1)016(2)(3)(4)(5)
24.0
8
0.140
T95R187(1)016(2)(3)(4)(5)
28.8
8
0.130
T95R227(1)016(2)(3)(4)(5)
35.2
8
0.120
T95R337(1)016(2)(6)(4)(5)
52.8
14
0.110
20 WVDC AT + 85 °C, SURGE = 26 V . . . 13 WVDC AT + 125 °C, SURGE = 16 V
T95S155(1)020(2)(3)(4)L
0.5
6
N/A
T95S225(1)020(2)(3)(4)L
0.5
6
N/A
T95V335(1)020(2)(3)(4)L
0.7
6
N/A
T95X475(1)020(2)(3)(4)L
0.9
6
N/A
T95X685(1)020(2)(3)(4)L
1.4
6
N/A
T95Y106(1)020(2)(3)(4)L
2.0
6
N/A
T95Z156(1)020(2)(3)(4)L
3.0
6
N/A
T95Z226(1)020(2)(3)(4)L
4.4
6
N/A
T95D476(1)020(2)(6)(4)(5)
9.4
6
0.190
T95R476(1)020(2)(3)(4)L
9.4
6
0.200
T95R107(1)020(2)(6)(4)S
20.0
8
0.140
T95R127(1)020(2)(3)(4)(5)
24.0
8
0.140
T95R157(1)020(2)(3)(4)(5)
30.0
8
0.140
25 WVDC AT + 85 °C, SURGE = 32 V . . . 17 WVDC AT + 125 °C, SURGE = 20 V
T95S684(1)025(2)(3)(4)L
0.5
4
N/A
T95S105(1)025(2)(3)(4)L
0.5
4
N/A
T95S155(1)025(2)(3)(4)L
0.5
6
N/A
T95V225(1)025(2)(3)(4)L
0.6
6
N/A
T95X335(1)025(2)(3)(4)L
0.8
6
N/A
T95X475(1)025(2)(3)(4)L
1.2
6
N/A
T95Y685(1)025(2)(3)(4)L
1.7
6
N/A
T95C106(1)025(2)(3)(4)(5)
2.5
6
0.570
T95Y106(1)025(2)(3)(4)L
2.5
6
N/A
T95Z156(1)025(2)(3)(4)L
3.8
6
N/A
T95D336(1)025(2)(3)(4)(5)
8.3
6
0.260
T95R336(1)025(2)(3)(4)(5)
8.3
6
0.250
T95D686(1)025(2)(6)(4)(5)
17.0
6
0.260
T95R686(1)025(2)(3)(4)(5)
17.0
6
0.200
T95R107(1)025(2)(3)(4)S
25
8
0.200
Notes:
(1) Capacitance Tolerance: K, M
(2) Termination and Packaging: C, E, H, L
(3) Reliability Level: A, S, Z
(4) Surge Current: A, B, S
(5) ESR: L, S
(6) Reliability Level: A, B, S, Z
www.vishay.com
152
For technical questions, contact: tantalum@vishay.com
Document Number: 40081
Revision: 23-Jan-08
T95
Solid Tantalum Chip Capacitors
Vishay Sprague
®
Hi-Rel COTS, Conformal Coated Case
T
ANTAMOUNT
STANDARD/EXTENDED RATINGS
CAPACITANCE
(µF)
CASE CODE
PART NUMBER
MAX. DC
LEAKAGE
AT + 25 °C
(µA)
MAX. DF
AT + 25 °C
120 Hz
(%)
STD.(S)
MAX. ESR
AT + 25 °C
100 kHz (Ω)
LOW (L)
MAX. ESR
AT + 25 °C
100 kHz
(Ω)
20.000
18.000
15.000
12.000
9.000
5.000
3.500
3.000
2.000
1.500
0.800
0.800
0.600
0.270
0.190
0.240
0.200
1.0
0.450
0.500
0.350
0.300
35 WVDC AT + 85 °C, SURGE = 46 V . . . 23 WVDC AT + 125 °C, SURGE = 28 V
0.10
0.15
0.22
0.33
0.47
0.68
1
1.5
2.2
3.3
4.7
6.8
10
15
15
22
33
4.7
6.8
10
15
22
S
S
S
S
S
S
S
V
X
Y
Z
Z
Z
D
R
R
R
C
D
R
R
R
T95S104(1)035(2)(3)(4)L
T95S104(1)035(2)(3)(4)L
T95S224(1)035(2)(3)(4)L
T95S334(1)035(2)(3)(4)L
T95S474(1)035(2)(3)(4)L
T95S684(1)035(2)(3)(4)L
T95S105(1)035(2)(3)(4)L
T95V155(1)035(2)(3)(4)L
T95X225(1)035(2)(3)(4)L
T95Y335(1)035(2)(3)(4)L
T95Z475(1)035(2)(3)(4)L
T95Z685(1)035(2)(3)(4)L
T95Z106(1)035(2)(3)(4)L
T95D156(1)035(2)(3)(4)(5)
T95R156(1)035(2)(3)(4)(5)
T95R226(1)035(2)(3)(4)(5)
T95R336(1)035(2)(3)(4)(5)
T95C475(1)050(2)(3)(4)(5)
T95D685(1)050(2)(3)(4)(5)
T95R106(1)050(2)(3)(4)(5)
T95R156(1)050(2)(3)(4)(5)
T95R226(1)050(2)(3)(4)(5)
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.8
1.2
1.6
2.4
3.5
5.3
5.3
7.7
11.6
2.4
3.4
5.0
7.5
11.0
4
4
4
4
4
4
4
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
0.410
0.380
0.280
0.280
1.4
0.820
0.650
0.400
0.390
50 WVDC AT + 85 °C, SURGE = 65 V . . . 33 WVDC AT + 125 °C, SURGE = 40 V
Notes:
(1) Capacitance Tolerance: K, M
(2) Termination and Packaging: C, E, H, L
(3) Reliability Level: A, S, Z
(4) Surge Current: A, B, S
(5) ESR: L, S
(6) Reliability Level: A, B, S, Z
Document Number: 40081
Revision: 23-Jan-08
For technical questions, contact: tantalum@vishay.com
www.vishay.com
153
京公网安备 11010802033920号
EEWORLD
