TAJ Series
Standard Tantalum
•
•
•
•
General purpose SMT chip tantalum series
6 case sizes available
Low profile options available
CV range: 0.10-2200μF / 2.5-50V
LEAD-FREE COMPATIBLE
COMPONENT
SnPb termination option is not
RoHS compliant.
CASE DIMENSIONS:
Code
A
B
C
D
E
V
For part marking see page 132
EIA
Code
1206
1210
2312
2917
2917
2924
millimeters (inches)
W+0.20 (0.008) H+0.20 (0.008)
-0.10 (0.004)
-0.10 (0.004)
1.60 (0.063)
2.80 (0.110)
3.20 (0.126)
4.30 (0.169)
4.30 (0.169)
6.10 (0.240)
1.60 (0.063)
1.90 (0.075)
2.60 (0.102)
2.90 (0.114)
4.10 (0.162)
3.55 (0.140)
W
1
±0.20
(0.008)
1.20 (0.047)
2.20 (0.087)
2.20 (0.087)
2.40 (0.094)
2.40 (0.094)
3.10 (0.120)
A+0.30 (0.012)
-0.20 (0.008)
0.80 (0.031)
0.80 (0.031)
1.30 (0.051)
1.30 (0.051)
1.30 (0.051)
1.30 (0.051)
S Min.
1.10 (0.043)
1.40 (0.055)
2.90 (0.114)
4.40 (0.173)
4.40 (0.173)
4.40 (0.173)
EIA
Metric
3216-18
3528-21
6032-28
7343-31
7343-43
7361-38
L±0.20
(0.008)
3.20 (0.126)
3.50 (0.138)
6.00 (0.236)
7.30 (0.287)
7.30 (0.287)
7.30 (0.287)
W
1
dimension applies to the termination width for A dimensional area only.
HOW TO ORDER
TAJ
C
106
Type
Case Size
See table
above
Capacitance Code
pF code: 1st two
digits represent
significant figures
3rd digit represents
multiplier (number of
zeros to follow)
M
035
R
NJ
—
Tolerance
K=±10%
M=±20%
Rated DC Voltage
002=2.5Vdc
004=4Vdc
006=6.3Vdc
010=10Vdc
016=16Vdc
020=20Vdc
025=25Vdc
035=35Vdc
050=50Vdc
Packaging
R = Pure Tin 7" Reel
S = Pure Tin 13" Reel
A = Gold Plating 7" Reel
B = Gold Plating 13" Reel
H = Tin Lead 7" Reel
(Contact Manufacturer)
Specification
Suffix
NJ = Standard
Suffix
Additional
characters may be
added for special
requirements
V = Dry pack Option
(selected codes only)
K = Tin Lead 13" Reel
(Contact Manufacturer)
H, K = Non RoHS
TECHNICAL SPECIFICATIONS
Technical Data:
Capacitance Range:
Capacitance Tolerance:
Rated Voltage (V
R
)
Category Voltage (V
C
)
Surge Voltage (V
S
)
Surge Voltage (V
S
)
Temperature Range:
Reliability:
Qualification:
Termination Finished:
All technical data relate to an ambient temperature of +25°C
0.10 μF to 2200 μF
±10%; ±20%
2.5
4
6.3
10
16
20
25
35
1.7
2.7
4
7
10
13
17
23
3.3
5.2
8
13
20
26
32
46
2.2
3.4
5
8
13
16
20
28
-55°C to +125°C
1% per 1000 hours at 85°C, V
R
with 0.1Ω/V series impedance,
60% confidence level
CECC 30801 - 005 issue 2
EIA 535BAAC
Sn Plating (standard), Gold and SnPb Plating upon request
For AEC-Q200 availability, please contact AVX
+85°C:
+125°C:
+85°C:
+125°C:
50
33
65
40
6
TAJ Series
Standard Tantalum
CAPACITANCE AND RATED VOLTAGE, VR (VOLTAGE CODE) RANGE
(LETTER DENOTES CASE SIZE)
Capacitance
μF
Code
0.10
104
0.15
154
0.22
224
0.33
334
474
0.47
0.68
684
1.0
105
1.5
155
2.2
225
3.3
335
475
4.7
6.8
685
10
106
15
156
22
226
33
336
476
47
68
686
100
107
150
157
220
227
330
337
470
477
680
687
1000
108
1500
158
2200
228
2.5V (e)
4V (G)
6.3V (J)
Rated voltage DC (V
R
) to 85°C
10V (A)
16V (C)
20V (D)
25V (E)
35V (V)
A
A
A
A
A/B
A/B
A/B
A/B/C
A/B/C
B/C
B/C/D
C/D
C/D/E
C/D
D/E
D/E/V
E/V
V
50V (T)
A
A/B
A/B
A/B
A/B/C
A/B/C
A
(M)
/B/C
B/C/D
B/C/D
C/D
C/D
C/D
D/E/V
D/E/V
V
A
A
A
A/B
B
B/D
D
C/D
C/D/E
D
(M)
/E
D/E/V
(M)
V
(M)
A
A
A
A/B
A
A/B
A/B
A/B/C
A/B/C
B/C
B
(M)
/C/D
C/D/E
C/D/E
D/E
D/E/V
E/V
(M)
A
A
A
A/B
A/B
A/B
A/B/C
A/B/C
A/B/C/D
B/C/D
B/C/D
B
(M)
/C/D
C/D/E
C/D/E
D/E/V
E/V
(M)
E /V
(M)
A
A
A
A/B
A/B
A/B/C
A/B/C
A/B/C
A/B/C/D
B/C/D
B/C/D
B
(M)
/C/D/E
C/D/E
C/D/E
D/E/V
E/V
A
A
A/B
A/B
A/B
A/B/C
A/B/C
A
(M)
/B/C
B/C/D
B/C/D
C/D
C/D
C/D/E
D/E/V
E/V
E
(M)
A
A
A
A/B
A/B
A/B/C
A/B/C
A
(M)
*/B/C
B/C/D
B/C/D
C/D
C/D/E
C
(M)
/D/E
D/E/V
E/V
A
A
A
A/B
A/B
A/B/C
A/B/C
B/C
B/C/D
C/D
C/D
D/E
D/E
E/V
E
(M)
/V
V
(M)
Not recommended for new designs, higher voltage or smaller case size substitution are offered.
Released codes
(M tolerance only)
Engineering samples - please contact manufacturer
*Codes under development - subject to change
Note: Voltage ratings are minimum values. AVX reserves the right to supply
higher ratings in the same case size, to the same reliability standards.
7
